Mitsubishi General-Purpose Programmable Controller
Renewal Tool Conversion Adapter
Model
ERNT-AQTX11
User's Manual
ERNT-AQTX11
ERNT-AQTX11
Model
ERNT-AQTX11
50CM-D180059-A (1007)MEE
HEAD OFFICE:NIHONJISHO-DAIICHI BLDG.1-13-5，KUDANKITA CHIYODA-KU，TOKYO 102-0073，JAPAN
NAGOYA ENGINEERING OFFICE:139 SHIMOYASHIKICHO-SHIMOYASHIKI，KASUGAI，AICHI 486-0906，JAPAN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mitsubishi Electric ERNT-AQTX11
Summary of Contents for Mitsubishi Electric ERNT-AQTX11
- Page 1 Mitsubishi General-Purpose Programmable Controller Renewal Tool Conversion Adapter Model ERNT-AQTX11 User’s Manual ERNT-AQTX11 ERNT-AQTX11 Model ERNT-AQTX11 50CM-D180059-A (1007)MEE HEAD OFFICE:NIHONJISHO-DAIICHI BLDG.1-13-5，KUDANKITA CHIYODA-KU，TOKYO 102-0073，JAPAN NAGOYA ENGINEERING OFFICE:139 SHIMOYASHIKICHO-SHIMOYASHIKI，KASUGAI，AICHI 486-0906，JAPAN...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS (Always read these precautions prior to use.) Before using this product, please read this manual carefully and pay full attention to safety to ensure that the product is used correctly. The precautions presented in this manual are concerned with this product only. For Programmable Controller system safety precautions, refer to the user’s manual of the MELSEC-Q series CPU module to be used. -
Page 3: Installation Precautions
Installation Precautions CAUTION Use the conversion adapter and conversion adapter anchor base in an environment of the general specifications defined in the MELSEC-Q series CPU module user’s manual. Failure to do so could lead to electric shock, fire, malfunction or product failure or deterioration. ... -
Page 4: Disposal Precautions
Startup and Maintenance Precautions DANGER Do not touch the terminals during energization. Doing so could result in electric shock or malfunction. Be sure to shut off all phases of the external power supply before cleaning and retightening the terminal screws. -
Page 5: Emc And Low Voltage Directives
Manufacturers who recognize their products are compliant to the EMC and Low Voltage Directives are required to declare that print a "CE mark" on their products. Authorized representative in Europe Authorized representative in Europe is shown below. Name: Mitsubishi Electric Europe B.V. (EMC C.C. Division) Address: Gothaer strasse 8, 40880 Ratingen, Germany... - Page 6 1. Overview This manual describes the Mitsubishi general-purpose Programmable Controller renewal tool conversion adapter (ERNT-AQTX11) and the conversion adapter anchor base (sold separately; ERNT-AQF12/-AQF8/-AQF5/-AQF3) that secures the bottom of the conversion adapter. The conversion adapter is a product that converts the differences in MELSEC-A series and MELSEC-Q series pin assignments.
- Page 7 2. Conversion Adapter Product Specifications Conversion Adapter A Series Q Series Module Conversion Adapter Model Module Model Model Weight (g) No. of modules ERNT-AQTX11 AX11 QX10 AX11EU Q Series Terminal No. Signal Name Terminal No. Signal Name Terminal Block Slot No.
- Page 8 <Input Module Specification Comparison Chart> Model MELSEC-A Series MELSEC-Q Series Specifications AX11 AX11EU QX10 No. of input 32 points 32 points 16 points points Isolation Photocoupler isolation Photocoupler isolation Photocoupler isolation method Rated input 100 to 120V AC 100 to 120V AC 100 to 120V AC voltage 50/60 Hz...
- Page 9 3. Products Required by the Conversion Adapter Conversion Adapter Anchor Base (Sold Separately) The conversion adapter anchor base secures the bottom of the conversion adapter and is required for conversion adapter use. One anchor base is required per base. Specifications Conversion Adapter Anchor Base Model Type...
-
Page 10: Mounting And Installation
4. Mounting and Installation 4.1 Handling Precautions Do not touch the terminals during energization. Doing so could result in electric shock or malfunction. Do not disassemble or modify the conversion adapter. Doing so could result in failure, malfunction, injury or fire. Do not come in direct contact with the conductive area of the conversion adapter. - Page 11 5. Part Names and Installation Method Q series module Mounting bracket (conversion adapter accessory) Mounting bracket fixing screw M3.5 x 6 (conversion adapter accessory) Conversion adapter installation screw MELSEC-A series M3 x 30 terminal block installation screw (M4) Conversion adapter anchor base Conversion adapter MELSEC-A series...
- Page 12 6. Conversion Adapter Anchor Base Installation Method To use the conversion adapter, a conversion adapter anchor base (ERNT-AQF12/-AQF8/-AQF5/-AQF3) is required. Q Base Unit Q312B Q38B Q35B Q33B Q612B Q68B Q65B Q63B Q55B Q52B Conversion Adapter Anchor Base ERNT-AQF12 ◎ × ×...
- Page 13 With Extension Base Unit Q612B, Q68B Q65B or Q63B Machine screw holes (M4 x 2 locations) in these locations for conversion adapter anchor base installation. Conversion Adapter ERNT-AQF** Anchor Base ERNT-AQF12 321.2 87.4±0.2 Ａ±0.2 ERNT-AQF8 ERNT-AQF5 126.6 ERNT-AQF3 With Extension Base Unit Q55B Machine screw holes (M4 x 2 locations) in...
- Page 14 With Extension Base Unit Q52B Machine screw holes (M4 x 2 locations) in these locations for conversion adapter anchor base installation. ERNT-AQF3 4±0.2 71±0.2 Tips Use of a base adapter (sold separately) eliminates the need for additional screw hole machining on the control panel.
-
Page 15: External Dimensions
7. External Dimensions 7.1 Conversion Adapter Mounting bracket 取付金 53.5 55.2 7.2 Conversion Adapter Anchor Base Ａ Ｂ 27.8 Ｃ Model ERNT-AQF12 305.8 321.2 335.8 224.6 194.6 ERNT-AQF8 111.2 126.6 ERNT-AQF5 141.2 55.6 ERNT-AQF3 85.6... - Page 16 Please confirm the following product warranty details prior to product use. Gratis Warranty Terms and Gratis Warranty Range If any fault or defect (hereinafter referred to as “Failure”) attributable to Mitsubishi Electric Engineering Company Limited (hereinafter referred to as “MEE”) should occur within the gratis warranty period, MEE shall repair the product free of charge via the distributor from whom you made your purchase.
