FIRST TIME INSTALLATION
•
Please read instructions carefully before installation.
•
Check the contents of kit. Contact your dealer if any parts appear to be missing or
damaged.
•
Clean your roof racks or platform prior to fitting the brackets.
KIT CONTENTS
Item Component
1
M8 Spring Nut Long
2
M8 T-Nut
3
Mounting Bracket
4
Allen Key 6mm
5
M8 Socket Head Capscrew 16mm
6
M8 Socket Head Capscrew 25mm
7
M8 Spring Washer
8
M8 Washer
9
Accessory Mounting Fastner Pack
9A M8 Socket Head Capscrew 25mm
9B M8 Nyloc Nut
9C M8 Slot Nut
9D M8 Washer
80-13-028-Rev2
ACCESSORY BRACKET KIT INSTRUCTIONS
1
Qty
4
4
2
1
4
4
4
4
4
1
8
4
4
8
6
7
•
For LockN'Load, Whispbar HD, Prorack HD, and other heavy
duty bars, follow Steps 1, 2, 7, 8, 9
•
For LockN'Load Platform, follow Steps 3, 4, 7, 8, 9
•
For Whispbar, Prorack S-Wing, and international T-Slot
crossbars, follow Steps 5, 6, 7, 8, 9
2
3
5
8
9
A
B
C
D
Page 1 of 4
Advertisement
Related Manuals for Yakima 8005028
Summary of Contents for Yakima 8005028
- Page 1 ACCESSORY BRACKET KIT INSTRUCTIONS • For LockN’Load, Whispbar HD, Prorack HD, and other heavy FIRST TIME INSTALLATION duty bars, follow Steps 1, 2, 7, 8, 9 • Please read instructions carefully before installation. • For LockN’Load Platform, follow Steps 3, 4, 7, 8, 9 •...
- Page 2 INSTALLATION OF MOUNTING BRACKETS ON LOCKN’LOAD, WHISPBAR HD, PRORACK HD, AND OTHER HEAVY DUTY CROSSBARS Insert 2 x M8 Spring Nuts at an equal distance from the ends of each crossbar. Push Referring to Figure 1, secure the 2 x Mounting Brackets to the M8 Spring Nuts in Spring Nuts down into the crossbar channels and twist to lock into place as pictured.
- Page 3 INSTALLATION OF BRACKETS TO WHISPBAR AND PRORACK S-WING BARS, AND INTERNATIONAL T-SLOT CROSSBARS Check crossbar spread is between 492mm to 892mm. Push rubber infill down and Referring to Figure 3, secure the 2 x Mounting Brackets to the M8 T-Nuts in the slide 2 x M8 T-Nuts into each crossbar channel at an equal distance from the ends crossbars.
- Page 4 Where you become aware of defects in materials or of workmanship, and wish to make a claim under this warranty you must do the following for the warranty to be honoured by your Prorack dealer or Yakima Australia Pty Ltd ABN 58 154...
