Please read instructions carefully before installation.
•
Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged.
•
Clean your Platform prior to fitting the LOCKN'LOAD Platform Corner Bracket.
•
Place these instructions in the vehicle's glove box after installation is complete.
PLATFORM SOLD SEPARATELY.
ESKY NOT INCLUDED.
ITEM COMPONENT
1.
Corner Bracket Left Bend
2.
Corner Bracket Right Bend
3.
Washer
4.
Eye Bolt
5.
Channel Nut
80-13-036-Rev1
®
PLATFORM CORNER BRACKET
FIRST TIME INSTALLATION
KIT CONTENTS
4
QTY
x2
x2
x4
x4
x4
3
LOCKN'LOAD
TM
1
2
1/2
