- Page 1 Electric vehicle AC Charger MP Pedestal Installation Manual Intellectual property of EVBOLT, Inc.
-
Page 2: Table Of Contents
Table of Contents Packing List ................................1 Dimensions ................................2 Building a Concrete Pad ............................3 Installing the Pedestal ............................... 4 Installing the Charger ............................... 5 Intellectual property of EVBOLT, Inc. -
Page 3: Packing List
1. Packing List Product Name Notes Dual Pedestal Accessory Installation Manual Anchor Bolts M10*100 M5*12 Metal Cover 140*140 Intellectual property of EVBOLT, Inc. Page 1 of 5... -
Page 4: Dimensions
275(10.83") 2. Dimensions Primary Unit: mm 100(3.94") 190(7.48") Intellectual property of EVBOLT, Inc. Page 2 of 5... -
Page 5: Building A Concrete Pad
D raw one cable (two cables for dual chargers) from the center Pre-embedded 03.15" PVC pipe in concrete STEP 2 Drill 4 holes in the concrete pier (4-00.55") STEP Drive the expansion screw into the concrete pier Intellectual property of EVBOLT, Inc. Page 3 of 5... -
Page 6: Installing The Pedestal
Tighten the bolts / Secure the base cover Place the Cable management on top and secure using 4 screws STEP2 Close the lid and tighten the screws STEP 3 • Installation complete Intellectual property of EVBOLT, Inc. Page 4 of 5... -
Page 7: Installing The Charger
5. Installing the Charger Assemble the backplate on the pedestal install the charging equipment as explained. Intellectual property of EVBOLT, Inc. Page 5 of 5... - Page 8 © 2023 EVBOLT INC. All Rights Reserved.
