- Page 1 Electric vehicle AC Charger BNZO 22 – User Manual EVB- AC-B2XLLDHD Intellectual property of EVBOLT, Inc.
-
Page 2: Table Of Contents
Installation ..........................................26 9.6.4 Installing cable management (optional) ................................... 29 Operating Instructions ........................................30 10.1 Operating Steps (ONLINE) ......................................30 10.1.1 EVBOLT iOS/Android Application ..................................30 10.1.2 EVBOLT WebApp ........................................30 10.2 Operating Steps (OFFLINE)......................................31 10.2.1 Plug-n-Play ..........................................31 10.2.2... -
Page 3: Introduction
This not only reduces your carbon footprint but also helps you save on electricity costs in the long run. Experience the future of EV charging with our BNZO 22. Elevate your charging routine with dual ports for flexibility, a large 21.5" screen for cloud-based advertisement that put you in control. Join the electric revolution and make every charge a seamless and enjoyable part of your day. -
Page 4: Important Safety Instructions
When any fault occurs, the product is prohibited to use, the user is prohibited to repair, must be sent to the after-sales maintenance or call the after-sales service for help. Intellectual property of EVBOLT, Inc. Page 2 of 36... - Page 5 Quand n’importe quell défaut se produit, le produit est interdit pour employer, l’utilisateur est interdit pour réparer, doit être envoyé à l’entretien après-vente ou appeler le service après-vente pour l’aide. Intellectual property of EVBOLT, Inc. Page 3 of 36...
-
Page 6: Federal Communication Commission Interference Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Intellectual property of EVBOLT, Inc. Page 4 of 36... -
Page 7: Industry Canada Statement
As long as the 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. Intellectual property of EVBOLT, Inc. Page 5 of 36... - Page 8 IC ne peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera chargé de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une autorisation distincte au Canada. Intellectual property of EVBOLT, Inc. Page 6 of 36...
-
Page 9: Interface
REAR DOOR LATCH SAE J1772 CONNECTOR HOLDER • L... LED LIGHT (DECORATIVE) CHARGING CABLE OUTLET rr=--- · - ___ , .."" CHARGER BASE ALTERNATE INPUT CABLE FRONT VIEW SIDE VIEW Intellectual property of EVBOLT, Inc. Page 7 of 36... -
Page 10: Dimensions
6. Dimensions (With Cable Management) SIDE VIEW FRONT VIEW Intellectual property of EVBOLT, Inc. Page 8 of 36... - Page 11 2.8in [70mm] 1.6in [40mm] 1.6in [40mm] 2.8in [70mm] 20.9in [530mm] 29.5in [750mm] FRONT VIEW 18.9in [480mm] 20.9in [530mm] 26.8in [680mm] 6.2in [158mm] 7.2in [183mm] 7.2in [183mm] 6.2in [158mm] SIDE VIEW 14.4in [365mm] 26.8in [680mm] Intellectual property of EVBOLT, Inc. BOTTOM VIEW...
-
Page 12: Specifications
App, WebApp, ISO 15118, RFID (Optional), Credit Card Terminal (Optional) Backend Support OCPP 1.6 JSON (Upgradeable to 2.1) Advertisement Display 21.5-inch LED Screen Resolution TFT – LLCD Panel (1920 x RGB x 1080 pixels) Backend EVBOLT Cloud Intellectual property of EVBOLT, Inc. Page 10 of 36... - Page 13 Weight (typ.) < 224.8lbs. (102 kg), includes two charging cables AC Charging Connector 16.4ft Dual charging cable Cooling Fan cooling Ingression Protection IP54 NEMA 3R Anti-vandalism IK10, excluding LCD & RFID cover Intellectual property of EVBOLT, Inc. Page 11 of 36...
-
Page 14: Status Description
8. Status Description STANDBY Green light stays steady in standby mode. SCAN CARD PLEASE CHARGING Green Light Flashing SCAN CARD PLEASE FAULT Steady red light when fault occurs SCAN CARD PLEASE Intellectual property of EVBOLT, Inc. Page 12 of 36... -
Page 15: Installation Instructions
Report unsafe activities immediately to supervisors or the responsible person in control of the workplace, and o Report all accidents and dangerous occurrences to the supervisor immediately after they happen Intellectual property of EVBOLT, Inc. Page 13 of 36... - Page 16 • Set up cooling equipment, such as exhaust fans • Make water dispensers available • Provide suitable protective clothing such as hat, sunglasses and long sleeves to protect workers from heat stroke and UV rays Intellectual property of EVBOLT, Inc. Page 14 of 36...
- Page 17 • Fully open stepladders when in use • Do not overreach when working on a ladder • Beware of overload restrictions Country Standards ANSI A 14.1, ANSI A 14.2, ANSI A 14.5 Canada CSA Z11 M81 Intellectual property of EVBOLT, Inc. Page 15 of 36...
- Page 18 • Live electrical work permit (input terminals with HV after door open) • Use personal protective equipment (PPE) • Safe workplace conditions and space • Adhere to other occupational health, safety and security codes, such as those published by OSHA Intellectual property of EVBOLT, Inc. Page 16 of 36...
-
Page 19: Safety Requirements
In residential power supplies, check the bond between ground and neutral at the main panel. If connected to a step- down transformer, contact the transformer's manufacturer for direction on how to bond the ground connection Intellectual property of EVBOLT, Inc. Page 17 of 36... -
Page 20: Packing List
Packing List Electric vehicle AC Charger BNZO 22 – User Manual EVB- AC-B2XLLDHD Intellectual property of EVBOLT, Inc. Product Name Notes AC Charger (With Charging Cables) POS Fixing board User Manual Expansion Screw RFID Card (RFID Version Only) Torx/T30 L-Wrench Rubber Plug Intellectual property of EVBOLT, Inc. -
Page 21: Tools And Materials Required
Laptop or PC & CAT6 cable For Charger Configuration Wi-Fi /4G signal quality checker Recommended Wi-Fi /4G signal quality checker Recommended Philips Screwdriver No. 2 and 3 Socket Screwdriver No. 8, 10, 17 and 19 Intellectual property of EVBOLT, Inc. Page 19 of 36... -
Page 22: Unpacking The Charger
• Contact the supplier by mail or phone to address your findings. WARNING! Charger weight might be 224.8 lbs. (102 kg). Charger with package might be 283.2 lbs. (128.5 kg). Be careful during unpack process. Intellectual property of EVBOLT, Inc. Page 20 of 36... - Page 23 STEP 1 Remove the Surrounding boards STEP 2 Remove the carton and packing cushion and film Intellectual property of EVBOLT, Inc. Page 21 of 36...
- Page 24 STEP 3 Open the front and back plate to expose the M12 Screws Remove the 4 pcs of fixing M12 Screws Intellectual property of EVBOLT, Inc. Page 22 of 36...
-
Page 25: Installation Procedure
• Left and right side 13.8 inch (350 mm), in order to open left and right door. • Backside 23.6 inch (600 mm), in order to open the bracket door. (13.8") (13.8") (29.5") 1450 (57.09”) Intellectual property of EVBOLT, Inc. Page 23 of 36... -
Page 26: Built Concrete Base
• In order to meet this positioning requirement, it is recommended to use positioning wood fixture. Please make the fixture according to the following drawing. Intellectual property of EVBOLT, Inc. Page 24 of 36... - Page 27 Ethernet, at least 71” (1800mm) of the Ethernet cable must be exposed from the conduit. Drill 4 holes on concrete (4 – Ø 0.63”) Bury expansive screws (M12*150) in the concrete Intellectual property of EVBOLT, Inc. Page 25 of 36...
-
Page 28: Installation
8 pcs of M12 screw nuts and 4 pcs of M12 washers on 4 pcs of M12 screw of concrete base (2 nuts for each screw) to secure the charger. Then fix the base covers in the charger base. Intellectual property of EVBOLT, Inc. Page 26 of 36... - Page 29 This product must be connected to a grounded, metal, permanent wiring system, or an equipment-grounding conductor must be run with the circuit conductors and connected to the equipment grounding terminal or lead on the product. Intellectual property of EVBOLT, Inc. Page 27 of 36...
- Page 30 Turn on power source and be ready for operational testing. The poser supply of the Standalone AC Charger: BNZO 22 will be enabled and automatically turn on the screen within 30 seconds. A breaker over than or equal to 60A NFB B curve.
-
Page 31: Installing Cable Management (Optional)
9.6.4 Installing cable management (optional) Eyebolt Photocell Remove the eyebolts on top of the charger Open the cable management and install it Eyebolt Intellectual property of EVBOLT, Inc. Page 29 of 36... -
Page 32: Operating Instructions
Operating Steps (ONLINE) For commercial purposes, this product can be connected to internet via Wi-Fi or 4G LTE. This is the case for Public and Semi-Public chargers. The chargers can be accessed using EVBOLT Application or WebApp. EVBOLT iOS/Android Application 10.1.1... -
Page 33: Operating Steps (Offline)
The screen will display charging data once the charging starts Unplug the charger to stop charging and enter the settlement interface RFID Authentication 10.2.2 Tap the screen to select charging method Intellectual property of EVBOLT, Inc. Page 31 of 36... - Page 34 Tap “Swipe RFID Card” method Swipe RFID Card to initiate charging The screen will display charging data once the charging starts Swipe the RFID Card again to stop charging and enter the settlement interface Intellectual property of EVBOLT, Inc. Page 32 of 36...
-
Page 35: Password
Enter the password on the screen to start charging The screen will display charging data once the charging starts Enter the password on the screen to stop charging Unplug the charger to enter the settlement interface Intellectual property of EVBOLT, Inc. Page 33 of 36... -
Page 36: Error And Warning Message
RCD Self-Test Fail Constantly Bright Contact customer service Relay Self-Test Fail Constantly Bright Contact customer service RCD Abnormal Stop Charging Constantly Bright Auto recover Output OCP Stop Charging Constantly Bright Auto recover Intellectual property of EVBOLT, Inc. Page 34 of 36... -
Page 37: Maintenance And Repair
Please keep the charger clean and install it in a clean area with low humidity. Do not install it in an environment near the sea, with high levels of oil, humidity or dust. • BNZO 22 is cooled by forced air. Please keep the charger in a ventilated location and do not block the air vents of the charger. -
Page 38: Warranty And Maintenance
Malfunction and damage caused by improper use of the equipment, such as water or other solutions entering into the equipment. Malfunction and damage caused by the mains power supply and voltage which is not specified for use with the charger equipment. Intellectual property of EVBOLT, Inc. Page 36 of 36... - Page 39 © 2023 EVBOLT INC. All Rights Reserved.
