- Page 1 Electric Vehicle AC Charger APEX 10 – User Manual EVB-AC-J10 Intellectual property of EVBOLT, Inc...
-
Page 2: Table Of Contents
Tools and Materials Required ..........................11 Wall-mounted Bracket Installation ........................12 Operation Instructions ..............................14 Operating Procedures ............................14 Operating Steps (ONLINE MODE) ........................14 EVBOLT iOS/Android Application ......................14 8.2.1 EVBOLT WebApp ............................14 8.2.2 Operating Steps (OFFLINE MODE) ........................15 Error and Warning Message .......................... -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING – This manual contains important instructions for Models: APEX 10 series that shall be followed during installation, operation, and maintenance of the unit. • Read all the instructions before using this product • This device should be supervised when used around children •... - Page 4 To satisfy FCC RF exposure requirements, a separation distance of 20cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. Intellectual property of EVBOLT, Inc Page 2 of 19...
- Page 5 LED Light Indication SAE J1772 AC Charging Connector Rear Notch AC Power Inlet Charging Cable Inlet LAN Cable Inlet Intellectual property of EVBOLT, Inc Page 3 of 19...
-
Page 6: Dimensions
Dimensions 9.8″ 5.1″ 13.8″ 2.83″ 4-Φ0.35″ 4.8″ Intellectual property of EVBOLT, Inc Page 4 of 19... -
Page 7: Design Standards
UL 991: Tests for Safety-Related Controls Employing Solid-State Devices UL 1998: Software in Programmable Components NFPA 70 Article 625: National Electrical Code, Electric Vehicle Charging System UL 840 (Clearance and Creepage) Intellectual property of EVBOLT, Inc Page 5 of 19... -
Page 8: Specifications
802.11 b/g/n 3G/4G Function** LTE, GSM/GPRS Cable Length 18ft Protection Level Type 3 Installation Type Wall-Mounted ≤ 6561ft Altitude Status Indication Red, Green, Blue LED * Wi-Fi Version ** 4G Version Intellectual property of EVBOLT, Inc Page 6 of 19... -
Page 9: Status Description
CHARGE light is constantly lit. Charging - Green Light Flashing Fault - Red Light The red light is lit while fault. Please refer to "9.3 Error and Warning Messages" for detailed information. Intellectual property of EVBOLT, Inc Page 7 of 19... -
Page 10: Packing List
Packing list Electric Vehicle AC Charger APEX 10 – User Manual EVB-AC-J10 Product Name Quantity Notes AC Charger (With Charging Cable) User Manual Wall-Mounted Bracket M5 teeth screws M6 Hexagonal Expansion Screws RFID Card (RFID Version Only) Intellectual property of EVBOLT, Inc... -
Page 11: Installation Instructions
• Type B, C or D breaker with the rating current for table should be installed in the upstream AC distribution • Disconnect switch for each ungrounded conductor of AC input shall be provided by others in accordance with the National Electric Code, ANSI/NFPA 70 Intellectual property of EVBOLT, Inc Page 9 of 19... -
Page 12: Wiring
. Connect the L1 wire to the grid L1, connect the L2 wire to the grid L2, connect the PE wire to the grid PE (for all Version). Circuit Breaker Options Output Amperage (A) Circuit Breaker Options (A) Intellectual property of EVBOLT, Inc Page 10 of 19... -
Page 13: Tools And Materials Required
“This device shall be mounted at a sufficient height from grade such that the height of the storage means for the coupling device is located between 600 mm (24 inches) and 1.2 m (4 feet) from grade.” Intellectual property of EVBOLT, Inc Page 11 of 19... -
Page 14: Wall-Mounted Bracket Installation
• Use 4 sets expansion screw and M6 screw to fix the wall-mounted bracket on the wall. Step 2: Align the rear notch of charger into the wall-mounted bracket and fit the screw holes of the right and left side. Intellectual property of EVBOLT, Inc Page 12 of 19... - Page 15 Step 3: Fix two M5 screws to complete the installation. Overall outlook picture after installation Optional cable management Wall-mounted cable winding Intellectual property of EVBOLT, Inc Page 13 of 19...
-
Page 16: Operation Instructions
8.2 Operating Steps (ONLINE MODE) For commercial purposes, this product can be connected to internet via Wi-Fi or 4G LTE. This is the case for Public and Semi-Public chargers. The chargers can be accessed using EVBOLT Application or WebApp. 8.2.1 EVBOLT iOS/Android Application... -
Page 17: Operating Steps (Offline Mode)
Please plug the charging connector into the vehicle charging inlet. When you tap the RFID card first, it needs to complete the insertion of the charging connector within 120 seconds, otherwise you need to tap the RFID card again. Intellectual property of EVBOLT, Inc Page 15 of 19... - Page 18 If red light is still lit, please refer to "Error and Warning Messages". CHARGE Step 5 / Charging Finished When the charging is finished, the green light (CHARGE) is constantly lit, please press the button on connector. Intellectual property of EVBOLT, Inc Page 16 of 19...
-
Page 19: Error And Warning Message
Constantly Bright Contact Customer Service RCD Abnormal Stop Constantly Bright Contact Customer Service Charging Output OCP Stop Charging Constantly Bright Contact Customer Service OTP Stop Charging Constantly Bright Contact Customer Service Intellectual property of EVBOLT, Inc Page 17 of 19... -
Page 20: Maintenance And Repair
• This charger is equipped with maintenance spares for maintenance use during and over the warranty period. All warranty services and repairs shall be and performed by certified service technicians authorized by EVBOLT, Inc. For details, please contact your local EVBOLT, Inc. service partner or direct to our Customer Service... -
Page 21: Warranty And Maintenance
• The warranty period for this charger is three years • After the event of any repair or maintenance under the warranty period, if there is no purchase to extend the warranty service, EVBOLT shall provide a three-month warranty period for any subsequent paid repair work •... - Page 22 © 2023 EVBOLT INC. All Rights Reserved.
