ENFORCER SECO-LARM SLI SK-B941-PQ Manual

Bluetooth
Keypad / Proximity Reader
What's in
the Box:
Specifications
Operating voltage
Standby
Current
draw
Active (max.)
Form C
Outputs
Tamper alarm
Egress input
Door sensor input
Proximity reader
IP Rating
Housing
Material
Faceplate
Operating humidity
Operating temperature
Dimensions
Weight
IMPORTANT NOTES
*
To protect the relay, you must install the enclosed diode—with the cathode (striped end
the positive side—for DC powered locks or install the varistor (MOV,
electromagnetic locks unless your lock has a diode/MOV built in (all SECO-LARM electromagnetic locks
have built-in protection). Do not install both. Failure to install as directed will void the warranty. Download the
Installation Manual and Administrator Guide from
†
Use the N.O. terminal for fail-secure applications and the N.C. terminal for fail-safe applications.
Post-Mount
®
1x SK-B941-PQ ENFORCER Bluetooth
1x Eleven-Pin Removable Terminal Block
2x Keys* 1x Quick Installation/Setup Guide
*No replacement keys available. Please make extra copies for safekeeping.
9~25 VDC
52mA@12VDC, 30mA@24VDC
62mA@12VDC, 35mA@24VDC
2.0A@30VDC
100mA@30VDC (solid state N.C.)
N.O. Ground
N.C. Ground
EM 125kHz
IP65 Weather-resistant
/ " (2mm) Anodized steel,
5
64
powder paint
Stainless steel
0-95%, non-condensing
-4°~122° F (-20°~50° C)
5"x6 / "x3 / " (127x166x94 mm)
9 11
16 16
3-lb 3-oz (1.45kg)
Product Specifications
®
Sample Wiring Diagram
Power (+)
Power (–)
COM
N.O. fail-secure
N.C. fail-safe
RTE pair – to RTE button
DOOR pair – to door sensor
Alarm pair – to N.C. tamper
www.seco-larm.com for complete instructions.
SK-B941-PQ
Post-Mount Keypad / Reader
1x Diode
1x Additional Information
or †
+ Lock –
MOV
Diode
Cathode
Alarm
System
) for AC powered locks and for
SL Access
1x Varistor
*
*
– +
Power
Supply
12/24 VDC
) toward
