Using Your Ice Maker; Troubleshooting - HOMCOM HZB-12/C Manual

USING YOUR ICE MAKER

1. Open the cover, remove the ice basket and pour water into tank.
Keep water level below the water level mark.
2. Press "ON/OFF" button on the control panel to begin the ice making cycle.
3. Select the ice cube size by pressing the "Select" button. If the room temperature is
lower than 15℃, it is recommended to select small ice cube in order to avoid ice
sticking together.
4. The ice making cycle lasts approx. 6 to 13 minutes, depending on selection of ice cube
size and the room temperature. The recommended room temperature is 10℃ to
43℃.
5. If water pump can't inject water, the ice maker will stop automatically, and the "ADD
WATER" indicator will be on. Press "ON/OFF" button, fill water up to the max. water
level mark and press "ON/OFF" button again to turn on the unit again. Allow the
refrigerant liquid inside the compressor at least 3 minutes to settle before restarting.
6. The ice maker stops when the ice basket is full and the "ICE FULL" indicator will be
on. Warning: Direct sunlight or sunlight reflection may cause infrared sensor
malfunction. If the unit doesn't stop even ice cubes obstruct sensor, move the
unit where no sunlight.
7. Change water in the water reservoir every 24 hours to ensure a reasonable hygiene
level.If unit isn't to be used, drain all the water and dry the tank.
PROBLEM
POSSIBLE CAUSE
"ADD WATER"
Lack of Water.
indicator is on.
"ICE FULL"
Ice is full in basket.
indicator is
on.
The ice making cycle is
too long.
Ice cubes
stick together.
Water temperature in
inner tank is too low.
Room temperature or
water temperature in
inner tank is too high.
Ice making
cycle is
Refrigerant in cooling
normal but no
system leaks.
ice formed.
Pipe in the cooling
system is blocked.
SOLUTION
Stop the ice maker, fill water, and press
"ON/OFF" button again to restart the unit.
Remove ice from ice basket. Continuous press
"Select" button 5 seconds, the unit could
make ice 10 cycles even "Ice" indicator is on.
Stop the ice maker, and restart it when the ice
blocks melt. Select the small size ice cube
selection.
Replace the water. Temperature of water
recommended at 8-32℃
The room temperature should be 10-43℃, water
temperature should be 8-32℃
Verify by a qualified technician.
Verify by a qualified technician.
8
