Panasonic KX-TG6541BXB Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Answering Machine
  5. KX-TG6541BXB
  6. Service manual
Panasonic KX-TG6541BXB Service Manual

Panasonic KX-TG6541BXB Service Manual

Expandable digital cordless answering system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Caller ID Compatible
KX-TGA652BXB
(Handset)
(Charger Unit)
Configuration for each model
Model No
Base Unit
KX-TG6541 1 (TG6541) 1 (TGA652)
KX-TG6542 1 (TG6541) 2 (TGA652)
KX-TG6541BXB
(Base Unit)
Handset
Charger Unit Expandable
Up to 6
1
Up to 6
Telephone Equipment
KX-TG6541BXB
Model No.
KX-TG6542BXB
KX-TGA652BXB
Expandable Digital Cordless Answering
System
B: Black Version
(for Middle Near East and Africa)
© Panasonic System Networks Co., Ltd. 2011
Unauthorized copying and distribution is a violation
of law.
ORDER NO. KM41108483CE
