- Page 1 Controlmicro User manual V 1.2.2...
- Page 2 PNX13-10001, PNX13-10002 This user manual contains the most important information for operating the Controlmicro in a safe manner. Please study this manual carefully before working with the device. This applies to all persons who come into contact with the device.
-
Page 3: Warning Symbols And Signal Words Used In This Manual
Warning symbols and signal words used in this manual Warning symbols and signal words used in this manual Warning Obey warning to avoid death or serious injury Caution Obey instructions to avoid personal injury or damage to property Note Instructions and facts to be followed Additional, useful hints Important safety instructions, please read before installation! Warning... -
Page 4: Table Of Contents
5 Important safety and handling information 6 Installation and start-up 7 Initial commissioning and operation 7.1 Switching the Controlmicro on and off 7.2 Setting up the visualization 7.3 Control and query of the sensors and the ambient light via http 8 Maintenance 9. -
Page 5: Target Audience
9.3 Technical support. 2 Intended use Depending on the software used, the Controlmicro serves as control unit for the entire KNX installation across rooms. It thus also serves as a status display. The device must be operated within the scope of the technical data and instructions given in this manual. -
Page 6: Product Description
3 Product description 3 Product description The Controlmicro (short: panel) is a high-quality panel computer for wall mounting. It serves as a display and control unit for the KNX controlled components and installations of a building. 3.1 Software The panel can be operated both with the supplied YOUVI software and with other Windows- compatible software. -
Page 7: Operation With Third-Party Software
FAQs: www.peaknx.com/FAQ, topic “compatibility”. Further instructions such as for setting up the panel as a door station can be found in the PEAKnx download area: https://www.peaknx.com/de/downloads. 3.2 Product features ▪ LED backlit full color TFT display, 1200 x 1920 pixels ▪... -
Page 8: Device Components
3 Product description 3.3 Device components Position Description Panel with touchscreen Mounting plate; Suitable switch box for mounting: standard screw spacing 60 mm, depth min. 35 mm... -
Page 9: Touch Panel Elements
3 Product description 3.4 Touch panel elements Position Description Microphone Proximity sensor Brightness sensor Touchscreen MicroSD card slot Screw holes for fixing the panel USB 2.0 Type C Status LED: red: panel is shut down, green: panel is switched on... -
Page 10: Mounting Plate
A terminal of the following specification is used for the KNX connection: KNX WAGO 243 211, conductor diameter: 0.6 - 0.8 mm. Note: The KNX fieldbus can only be used with PEAKnx software. Note: The device cannot be used as a line coupler for KNX lines! 3.6.2 Power supply... -
Page 11: Ethernet Port
3 Product description PoE variant (PNX13-10002) Note: The Controlmicro requires at least PoE according to standard 802.3at (PoE+) or 802.3bt (PoE++). Full functionality in normal operation cannot be guaranteed with standard 802.3af. 3.6.3 Ethernet port 24 V variant (PNX13-10001) Note: A cable of category CAT5e is recommended for using the 100 Mbit LAN connection, cable cross section 0.08 mm²... -
Page 12: Controlmicro Panel Settings
Screws to secure the panel against theft, including tools ▪ Adapter cable from USB type C to USB type A Optionally included in scope of delivery: Controlmicro power supply unit for DIN rail (top hat) (24 V variant; PNX13-10001) ▪... -
Page 13: Important Safety And Handling Information
5 Important safety and handling information 5 Important safety and handling information Warning The Controlmicro may only be installed and commissioned by qualified electricians! Warning Observe the national regulations applicable in your country regarding installation, functional testing, repair and maintenance of electrical products! ▪... - Page 14 6 Installation and start-up Connect the network cable to the LAN board as shown in the picture on the left. Fasten the network cable to the white housing using a cable tie. − While doing this, pinch the shielding between the cable and the designated area on the board.
-
Page 15: Initial Commissioning And Operation
7.1 Switching the Controlmicro on and off Note: In the delivery state, the panel automatically logs on with the user name Controlmicro without a password. After the Login, additional users can be added at any time or further settings may be changed in the Windows Settings. -
Page 16: Setting Up The Visualization
Controlmicro. ▪ For “localhost” enter the IP address of the Controlmicro, e.g.: http://10.2.42.60:31521/swagger, if you access the page from a PC in the network. Under the heading “Panel” you will find all http commands for querying and controlling the ▪... -
Page 17: Maintenance
8 Maintenance Example: control the RGB light Click on the third “POST” command under the category “Panel” (/api/v1/panel/led/color Setting ▪ led color) The link area will expand. ▪ Click on “Try it out”. ▪ In the following “Color of led” field, enter the appropriate RGB value for the desired color: ▪... -
Page 18: Troubleshooting
Opening the unit invalidates the warranty. 9.1 Touch panel stops responding If the Controlmicro no longer reacts to input on the touchscreen (which may occur in rare cases following Windows updates), a reboot of the panel usually helps. If the operating system cannot... -
Page 19: Technical Support
9. Troubleshooting Select “PEAKnx Factory Reset”. ▪ The factory state will be restored. ▪ 9.3 Technical support If you experience problems with your Controlmicro, please contact our PEAKnx Support Team: − Mail: support@peaknx.com − Create a Support Ticket: support.peaknx.com −... -
Page 20: Technical Data
10 Technical data 10 Technical data Supply Power supply specification 24 V variant PNX13-10001: 24 V DC; 2.5 A PoE variant PNX13-10002: at least 802.3at (PoE+) or 802.3bt (PoE++) Connection terminal, 24 V variant; PNX13-10001: rigid: 0.14 mm² - 1.5 mm² conductor cross section flexible with wire end ferrule without plastic sleeve: 0.25 mm²... - Page 21 10 Technical data Display Type LED Backlit full color TFT display Size (diagonal) 8 inch Resolution 1200 x 1920 pixels Touch technology Projected-capacitive touch (PCAP) Periphery Speakers Broadband, stereo Microphone Room characteristics WLAN | Bluetooth (only Wi-Fi 5GHz; 2,4GHz IEEE 802.11 b/g/n/ac | 5.0 24 V variant;...
- Page 22 10 Technical data Environment 24 V variant; PNX13-10001: EU Directive 2011/65/EU (RoHS II), 2015/863/EU EMC: EN 55032:2016-02, EN 61000-4-2/3/4/5/6, DIN EN IEC 63044-5-1/2/3, RED: ETSI EN 300 328 V2.2.2, ETSI EN 301 893, ETSI EN 301 489-1, ETSI EN 303 446-1, ETSI EN 300 440 V2.1.1, ETSI EN 301 893 V2.1.1 PoE variant;...
-
Page 23: Subject To Change Without Notice
Subject to change without notice Subject to change without notice Content changes in this documentation, which serve the technical progress, are made without prior notice. This documentation has been prepared with great care and will be revised at regular intervals. Nevertheless, we cannot guarantee complete accuracy. All known errors are eliminated in new editions. -
Page 24: Declaration Of Conformity
Declaration of conformity EU Declaration of Conformity This declaration applies to the following product: Product name: Controlmicro Item number(s): PNX13-10001 Manufacturer: PEAKnx GmbH Otto-Roehm-Strasse 69 64293 Darmstadt Germany We declare under our sole responsibility that the mentioned product is in conformity with... - Page 25 Declaration of conformity EU Declaration of Conformity This declaration applies to the following product: Product name: Controlmicro, power supply: PoE Item number(s): PNX13-10002 Manufacturer: PEAKnx GmbH Otto-Roehm-Strasse 69 64293 Darmstadt Germany We declare under our sole responsibility that the mentioned product is in conformity with...
-
Page 26: About Peaknx
Great importance is attached to the longevity of the products and the qualitative interaction of design and functionality. As the newest division of the PEAK group headquartered in Darmstadt, Germany, PEAKnx can draw from more than 25 years of experience in hardware and software development. Through a broad network of certified partners, PEAKnx also offers the associated services –... - Page 27 www.peaknx.com...
