Indice 1. GATEWAY-CAREL PER INTERFACCIAMENTO VERSO SISTEMI CON PROTOCOLLO CAREL 999..2 1.1 Descrizione generale..............................2 1.2 Descrizione dei LED e dei tasti ..........................2 2. COLLEGAMENTI ..............................3 2.1 Alimentazione ...............................3 3. SUGGERIMENTI PER UNA CORRETTA INSTALLAZIONE.................4 3.1 Connessioni sul retro del Gateway..........................4 4.
• LED alarm2 (rosso) Se lampeggiante segnala la presenza di anomalie nella comunicazione tra il Gateway e le periferiche Carel. Probabile causa : incongruenze rispetto alla configurazione iniziale. Ad ogni riavvio del Gateway il LED alarm2 lampeggia 8 volte in 2 secondi prima di spegnersi. Tale procedura conferma una corretta partenza dell’applicazione.
− 3.1 Connessioni sul retro del Gateway I connettori presenti nel pannello posteriore permettono di realizzare le connessioni tra il Gateway, la rete Carel e il sistema di supervisione che colloquia con il protocollo Carel 999. Figura 3: Retro del Gateway modem Connettore maschio a 9 vie standard.
• 150 variabili intere • 200 variabili digitali A richiesta è disponibile il database di variabili utilizzate da ogni singolo controllore Carel. Questo database sarà di riferimento per chi fornisce il sistema di supervisione in modo da assegnare l’opportuno significato alle variabili stesse.
Page 8
F2 (copy) si copiano gli allarmi visualizzati nel buffer interno del PC, mentre usando il tasto funzione F3 (paste) si caricano gli allarmi dal buffer interno alla maschera di visualizzazione. Questa funzionalità è pratica per assegnare a più macchine la stessa configurazione di allarmi. Gateway 999 Cod. +030221130 rel.2.1 del 11/02/99...
5. Generalità sul protocollo Carel 999 Il protocollo Carel 999 a cui si fa riferimento qui di seguito è quello definito nelle specifiche ufficiali, versione 1.1 del 26/08/96. La configurazione è di tipo punto-punto in RS232. 5.1 Parametri di comunicazione I dati di comunicazione tra supervisore e Gateway, impostabili dall’utente, sono i seguenti:...
Page 10
Tabella 9 Si noti che, data la varietà di macchine Carel, non si fa distinzione tra variabili di ingresso (di sola lettura) e variabili di uscita (di lettura/ scrittura) così che la conoscenza del database e la gestione dello stesso è affidata al supervisore.
9 poli femmina 9 poli Figura 4 Lato Gateway: connettore Carel net. Prestare attenzione ai piedini 6 e 7 del connettore lato Gateway. Devono essere cortocircuitati come indicato in figura e cioè: • 6 cortocircuitato con 2 • 7 cortocircuitato con 3 6.1.2 Gateway - terminale di configurazione...
(assieme al jumper “A” in posizione 2-3) si abilita la comunicazione in RS422 in uscita alla porta RS422/485 “C” in posizione 1-2 abilita la comunicazione verso la rete di strumenti Carel (in uscita dalla porta carel net.) in modalità RS485 sì...
Di seguito vengono messe in evidenza le dimensioni della carpenteria del Gateway (in millimetri) 105.4 vista frontale prigionieri fori Figura 7 vista dall’alto Carel si riserva la possibilità di apportare modifiche o cambiamenti ai propri prodotti senza alcun preavviso. Gateway 999 Cod. +030221130 rel.2.1 del 11/02/99...
Page 15
Contents 1 CAREL-GATEWAY FOR INTERFACE TOWARDS SYSTEMS WITH CAREL 999 PROTOCOL....2 1.1 General description..............................2 1.2 LED and button description ...........................2 2 CONNECTIONS..............................3 2.1 Power supply................................3 3 HINTS FOR A CORRECT INSTALLATION ......................4 3.1 Connectors on the Gateway back..........................4 4 SOFTWARE ................................5 4.1 General characteristics............................5...
The Carel 999 protocol which we refer to in this manual is the one defined by the official specifications, version 1.1 dated from 26 August 1996. As for the description of the protocol, please refer to the paragraph “Generalities on the Carel 999 protocol”.
N.B. in general the fuse is of the delayed T type, rated voltage 250V, dimensions 5x20mm. the rated current is: Power supply Fuse rated current 240V~ 250mA 120V~ 250mA 24V~ transformer 240V~ 120V~ fuse 24V~ Power input Fig. 2 Gateway power supply Gateway 999 Cod.: +030221130 rel. 2.1 - 11/02/99...
− The entire system could be damaged by the wrong connection of a single wire. Connectors on the Gateway back The connectors on the back panel permit the realisation of the connections between the Gateway, the Carel network and the supervisory system that talks with the Carel 999 protocol.
It is possible to connect the Gateway up to 16 addresses of Carel peripherals. The communication management takes place according to a master-slave structure in polling, where the master is the Gateway and the slaves are the Carel peripherals. The transmission protocol between Gateway and peripherals is the Carel private standard. For each peripheral it is possible to manage up to: •...
Page 20
F3 function button (paste) the alarms are loaded from the internal buffer to the display mask. This functionality is convenient in order to assign the same alarm configuration to several machines. Gateway 999 Cod.: +030221130 rel. 2.1 - 11/02/99...
5 Generalities on the Carel 999 protocol The Carel 999 protocol which we will be referring to below is the one defined in the official specifications, version 1.1 dated from 26August 1996. The configuration is of the point-point type in RS232.
Page 22
Answer of the Gateway999 in case of non correct reception. <NAK> Notice that, due to the variety of Carel machines, no distinction is made between input variables (only reading) and output variables (reading/ writing) so that the database knowledge and its management is entrusted to the supervisor.
6.1.1 Gateway - Carel peripherals, case RS422 The RS422 configuration towards the peripherals is selectable via the C jumper described in the paragraph Jumpers. The RS422 connection cable between the Gateway and the Carel peripherals has the following pin arrangement: Gateway Box deriv.
RS485 at the RS422/485 enables the communication towards the Carel instrument “C” in position 1-2 network (output from the carel net. port) in RS485 mode enables the communication towards the Carel instrument “C” in position 2-3 network (output from the carel net. port) in RS422 mode signalling relay is in “Normally Open”...
7 Mechanical dimensions Below the Gateway framing dimensions (in mm) are shown: 105.4 stud hole Upper view Front view the features of Carel reserves the right to modify its products without prior notice. Gateway 999 Cod.: +030221130 rel. 2.1 - 11/02/99...
