- Page 1 Zendoro Installation Manual...
-
Page 3: Installation Preparation
INSTALLATION PREPARATION Before installation begins, please confirm that you have the materials indicated below: Included... -
Page 4: Recommended Tools
Recommended Tools Precautions Before Installation Please give enough allowance for the installation. Ensure that there is room enough for the opening and closing of the bathroom door. Please see diagram below for product placement measurements. Please confirm the location of the sewage outlet and the wax ring as indicated below before installation. - Page 5 Installation Requirements Minimum static water pressure: 20 psi Maximum static water pressure: 80psi Minimum water flow: 4 Gal/Min 115 V power GFCI receptacle within 4’ Installation Drawings...
- Page 6 #1 INSTALLING THE WATER VALVE Option #1: Copper Stubbed Out of Wall (easiest method) 1. Shut off water to the house. 2. Remove existing stop valve from the copper 3. Replace with Valve #1 (see page 1) 4. Install Braided Hose (included) onto valve. Option #2: Using pex water line (new construction, remodels, and plumber installation.
-
Page 7: Installing The Battery
#2 INSTALLING THE BATTERY 1. Take the battery box and insert the batteries for emergency battery backup. 2. Connect the battery box to the toilet using the DC connector. 3. Place the battery box at the bottom inside of toilet. #3 CARDBOARD OUTLINE 1. -
Page 8: Mounting Bracket Installation
#4 CONNECT BRAIDED HOSE 1. Connect the Braided Hose to the water inlet on the back of the toilet. #5 MOUNTING BRACKET INSTALLATION 1. Assemble the mounting bracket with bolts and then install them to the pre-installed flange plate on the ground and lock tight with nuts. - Page 9 #6 TOILET INSTALLATION 1. Install wax ring into drain 2. Install toile ton corresponding position according to contour line Note: The toilet should be lifted/carried by two people. Make sure toilet sits perfectly on drain outlet. #7 SCREW INSTALLATION 1. Put the screw through the fixing sleeve and then install it through the holes located on both sides of the toilet and into the mounting bracket.
-
Page 10: Remote Installation
Caulk Application Caulk the bottom edge of the toilet with a mildew-resistant caulk designed for indoor bathroom applications. This will help to keep the bowl in place and give the closet bolts added security and strength. Remote Installation Option #1: 1. - Page 11 Option #2: 1. Drill a 6mm hole in the wall to a depth of 1.25 inch. 2. Peel the double-sided adhesive at the back of the bracket and stick it to the selected dry tile or glass and then secure with screws. 3.
- Page 12 support@troneplumbing.com www.troneplumbing.com...
