TRONE Aquatina III A3ETBCERN-12.WH Instruction Manual

Hide thumbs Also See for Aquatina III A3ETBCERN-12.WH:
Table of Contents

Advertisement

Quick Links

Aquatina III Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aquatina III A3ETBCERN-12.WH and is the answer not in the manual?

Questions and answers

Related Manuals for TRONE Aquatina III A3ETBCERN-12.WH

Summary of Contents for TRONE Aquatina III A3ETBCERN-12.WH

  • Page 1 Aquatina III Instruction Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety precautions ................2 2. Signs and meanings ................2 3. Warnings ................... 3-6 4. Line drawings 4.1.Remote Control ................7 4.2.Bidet Toilet..................8 5. Automatic Functions ................9 6. Getting to know your remote ............10 7.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS Basic safety precautions must be followed when handling or using electrical products, especially those within the reach of children. Please make yourself aware of the following guidelines: This product should only be used by children who are 8 years and older or by persons with disabilities who have received supervision and instructions on the safe use and the hazards involved when using this product.

  • Page 4: Warnings

    WARNINGS WARNING CAUTION Please do not touch the electrical outlet with wet hands. Or it may cause electric shock FORBIDDEN Please do not pour liquids such as water or detergent on top of the electronic outlet and the toilet. Or it may cause fire, electric shock, heat or MUST short circuit Or it may cause injury and indoor water...
  • Page 5 Continuous use of the toilet despite of the damages and above-mentioned conditions may result to fire, electric shock, heat, short circuit, injury, and indoor water seepage. Please don't use seawater and other water except for tap water or potable well water (underground water) Or it may cause skin irritation or inflammation During thunderstorms, do not touch the electrical plug Or it may cause electric shock...
  • Page 6 WARNING Pay attention to the low temperature scalding CAUTION Improper use of warm seat may cause low temperature scalding FORBIDDEN If you sit for a long time, please turn the temperature setting to "off level. Please turn the seat temperature setting to "off level, warm air-dry temperature to "low"...
  • Page 7 WARNING WARNING CAUTION Please do not throw lighted cigarettes and other CAUTION flaming material into the toilet. FORBIDDEN Or it may cause fire FORBIDDEN MUST Do not install this product in a room where it may be frosted. The room temperature can’t be less than 39.2 MUST degree Fahrenheit.

  • Page 8: Line Drawings

    LINE DRAWINGS Remote Control...

  • Page 9: Bidet Toilet

    Electronic Bidet Cushion Pad Power Plug (Electronic Leakage Toilet Lid Protection) Damper Dryer Side Buttons Heated Seat Spray Wand Toilet Bowl Nozzle Foot Sensor...

  • Page 10: Automatic Functions

    AUTOMATIC FUNCTIONS Self-Cleaning Wand The spray wand cleans itself before and after every use by rinsing itself as it enters and exits. Deodorizer The deodorizer starts anytime the seat sensor has been activated. The deodorizer will stop automatically after a user leaves the seat for around 90 seconds.

  • Page 11: Getting To Know Your Remote

    GETTING TO KNOW YOUR REMOTE Level Indicator Light • The Level Indicator Light [ ] will display the current level. • The water pressure adjustment, spray wand position adjustment, and the temperature adjustments have four gear positions: Close, Low, Mid, and High. When you successfully change from one level to the other the light indicator changes position and you hear one beep.

  • Page 12: Opening And Closing The Seat

    automatically close on its own after no motion is detected for approximately 90 seconds. Note: You can activate or deactivate this feature. See instructions on this feature on page 12. Opening and Closing the seat There are four methods to open and close the seat. These methods include (1) by hand, (2) using the remote, (3) using the foot sensor, and (4) automatically.

  • Page 13: Getting To Know Your Bidet

    GETTING TO KNOW YOUR BIDET Stop • You can turn the toilet power on and off by pressing and holding the Stop button [ ] for approximately 2-3 seconds. • Press the Stop button [ ] to immediately end any of the following functions: rear wash, front wash, drying, strong &...

  • Page 14: Front Wash

    Adjustable Water Temperature • Press the Water Temp button [ ] until the desired water temperature is selected. There are four levels of temperature adjustment which can be seen on the level indicator light. Front Wash • When the user is seated, press the Front Wash button [ ] to start front washing.

  • Page 15: Lady Care

    Note: You cannot adjust the dryer position while using the dryer oscillating feature. Lady Care • While in idle mode, press the Lady Care button [ + ]. Lady care sets the temperature to the highest setting and water pressure to level 2.

  • Page 16: Eco Mode

    Note: Water temperature, water pressure, spray wand position selection, cannot be adjusted when this function starts. Note: Idle mode means rear wash, front wash, dryer, and flushing are not currently being used. Eco Mode • Press and hold the Close/Power save button [ to turn on/off...

  • Page 17: Troubleshooting Guide

    Toilet Fault Failure Analysis Solutions Clean the filter according to Angle valve filter blocked the manual Unclean flush Measure if the water Too low water volume is 10L per 30s or when the water pressure not (buy a booster pump) pressure is low Ensure that the water Bended water inlet...
  • Page 18 Power Switch Fault Failure Analysis Solutions Check whether the socket has power or not and if Check circuit the plug is loose. Check whether the toilet is Press the power on/off turned on or not (if the button until the side side button is on or not) button’s light is on Product Not...
  • Page 19 General Problems Fault Solutions Failure Analysis Wait for water supply Check if there’s no water supply to be back to normal Check if the angle valve is Open the angle valve No water coming closed or not out from the Check if the inlet water nozzle Clean the water filter...

  • Page 20: Cleaning And Care

    CLEANING AND CARE Note: Turn off the power, close the water supply angle valve, and stop the water supply before doing any maintenance work. DO NOT rinse this product with water during maintenance. Toilet Bowl Cleaning Please ensure that the electrical plug is taken out. Please use soft damp cloth to wipe the toilet shelf and seat.
  • Page 21 Cleaning the Steel Mesh Filter When the cleaning strength becomes weaker, clean the steel mesh or replace the filter on time. Close the water supply angle valve when disassembling the filter. Tighten the filter during installation to avoid water leakage. Unscrew the cover with a flathead screwdriver or coin to open the filter.
  • Page 22 Replacing the Remote Control Battery Remove the battery cover and recycle your old batteries. Replace with new batteries and slide on the cover. Note: Keep the battery out of reach of children. Please confirm the positive and negative of battery. Do not change, disassemble, or burn the battery.

  • Page 23: Product Specifications

    PRODUCT SPECIFICATIONS Model Number A3ETBCERN-12.WH Rated Voltage 120V-, 60Hz Rated Power 1200W Power Cable 1.5m Applicable Water 20 - 90 PSI Pressure Water Room temp to 102 °F Temperature Ambient 39.2 to 104 °F Temperature Net Weight 93lbs Waterproof Level IPX4 Cleaning Water 0.10 - 0.17 gpm (0.4 - 0.65L/min)
  • Page 24 support@troneplumbing.com www.troneplumbing.com...
