Summary of Contents for TRONE Nobelet NETBCDER-12.WH
- Page 1 bidets reimagined Nobelet Installation Manual...
-
Page 2: Installation Preparation
INSTALLATION PREPARATION Before installation begins, please confirm that you have the materials indicated below: Included bidets reimagined Nobelet Installation Manual Electronic Bidet Remote Control Installation Manual Wax Ring Valve Stop Battery Back Up Batteries 1/4” Pex Adapter 3/8” x 1/2” Supply Line Washers Filter... -
Page 3: Recommended Tools
Recommended Tools Pencil Masking or Tape measure 7/16” ratchet box Carpenter’s painters tape or ruler wrench or deep socket square or other ratchet wrench straight edge Precautions Before Installation Please give enough allowance for the installation. Ensure that there is room enough for the opening and closing of the bathroom door. -
Page 4: Installation Requirements
Installation Requirements Minimum static water pressure: 40 psi Maximum static water pressure: 80psi Minimum water flow: More than 1.4 gallons per flush (5.28 liters) 115 V power GFCI receptacle within 4’ Installation Drawings 15” + Wax Ring Finished Floor Sewage Outlet... - Page 5 INSTALLING THE WATER VALVE Note: The valve supplied with Trone toilets is not a tapered thread and will need one of the two options listed below. Option #1: Retro fit with water supply line (easiest method) 1. Turn off toilet supply stop.
-
Page 6: Installing The Toilet
INSTALLING THE TOILET 1. Place the wax ring over the closet flange making sure it is centered, with the flange down. Install the closet bolts. 2. Remove the electronic bidet seat by pulling upwards firmly on the back of the seat until it releases (see Figure 1 below). 3. - Page 7 5. Line up the holes in the bottom of the bowl with the closet bolts previously installed in the closet flange and set the bowl gently in place (see Figure 2 below). 6. Place the included closet washers over the closet bolts and hand tighten the nuts in place.
- Page 8 8. Double check all water lines are properly connected. 9. Double check the battery backup is hooked together. It is recommended to replace the battery backup with a new battery. 10. Replace the bidet seat by lining it up and pushing down gently on the top part of the seat.
-
Page 9: Connecting The Water Supply
Connecting the Water Supply... -
Page 10: Connecting The Power Cord
Caulk Application Caulk the bottom edge of the toilet with a mildew-resistant caulk designed for indoor bathroom applications. This will help to keep the bowl in place and give the closet bolts added security and strength. Caulk Caulk Connecting the Power Cord Open the angle valve and connect the power cord plug to the power outlet. -
Page 11: Battery Installation
Battery Installation 1. Take the cable out as illustrated below. It is attached to the back of the product; peel it off gently. 2. Connect the waterproof DC power plug and tighten the waterproof cap. 3. Place the battery case in its position as shown below. Remote Installation 1. - Page 12 support@troneplumbing.com www.troneplumbing.com...
