Summary of Contents for TRONE Zendoro ZETBCDER-12.WH
- Page 1 Zendoro Instruction Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety precautions ................2 2. Signs and meanings ................2 3. Warnings ................... 3-6 4. Line drawings 4.1.Remote Control ................7 4.2.Bidet Toilet..................8 5. Automatic Functions ................9 6. Getting to know your remote ............10 7. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Basic safety precautions must be followed when handling or using electrical products, especially those within the reach of children. Please make yourself aware of the following guidelines: • This product should only be used by children who are 8 years and older or by persons with disabilities who have received supervision and instructions on the safe use and the hazards involved when using this product. -
Page 4: Warnings
WARNINGS Please do not touch the electrical outlet with wet hands. • Or it may cause electric shock Please do not pour liquids such as water or detergent on top of the electronic outlet and the toilet. • Or it may cause fire, electric shock, heat or short circuit •... - Page 5 Continuous use of the toilet despite of the damages and above-mentioned conditions may result to fire, electric shock, heat, short circuit, injury, and indoor water seepage. Please don't use seawater and other water except for tap water or potable well water (underground water) •...
- Page 6 Pay attention to the low temperature scalding Improper use of warm seat may cause low temperature scalding If you sit for a long time, please turn the temperature setting to "off level. Please turn the seat temperature setting to "off level, warm air-dry temperature to "low" level under the following situations •...
- Page 7 Please do not throw lighted cigarettes and other flaming material into the toilet. • Or it may cause fire Do not install this product in a room where it may be frosted. The room temperature can’t be less than 39.2 degree Fahrenheit.
-
Page 8: Line Drawings
LINE DRAWINGS Remote Control... -
Page 9: Bidet Toilet
Electronic Bidet... -
Page 10: Automatic Functions
AUTOMATIC FUNCTIONS Self-Cleaning Wand The spray wand cleans itself before and after every use by rinsing itself as it enters and exits. Deodorizer The deodorizer starts anytime the seat sensor has been activated. You can stop the deodorizer by pressing the DEODORIZER button { } in idle mode. -
Page 11: Getting To Know Your Remote
GETTING TO KNOW YOUR REMOTE Level Indicator Light • The Level Indicator Light [ ] will display the current level. • The spray wand position adjustment, and the temperature adjustments have five levels. When you successfully change from one level to the other the light indicator changes position and you hear one beep. -
Page 12: Opening And Closing The Seat
• Method 4: The lid will automatically open when you are close to it if the automatic lid function is active. The lid will automatically close on its own after no motion is detected for approximately 3 minutes. Note: You can activate or deactivate this feature. See instructions on this feature on page 12. -
Page 13: Getting To Know Your Bidet
GETTING TO KNOW YOUR BIDET Stop • Press the Stop button [ ] to immediately end any of the following functions: rear wash, front wash, and drying. Rear Wash • When the user is seated, press the REAR/MOVE button [ ] to start rear washing. -
Page 14: Front Wash
Front Wash • When the user is seated, press the FRONT/MOVE button [ to start front washing. Press the FRONT/MOVE button again to start the oscillating function which increases the cleansing area. Note: It will stop cleaning and start the drying function automatically after continuous cleaning for about 120 seconds. -
Page 15: Automatic Flush
Automatic Flush Factory Settings: OFF • Press and hold the FULL FLUSH button [ ] to turn this function on/off. PAIRING THE REMOTE 1) Press and hold the STOP button [ ] and then press the REAR/MOVE button [ ]. All five level indicator lights being flashing. -
Page 16: Troubleshooting Guide
TROUBLESHOOTING GUIDE Fault Solutions Failure Analysis Check if supply hose is Unbuckle supply hose buckling No Flushing Turn on angle valve Angle valve is off Connect water supply Water supply is cut off Unbuckle the supply Water supply hose buckling hose Completely open angle Angle valve is not fully... -
Page 17: Cleaning And Care
CLEANING AND CARE Note: Turn off the power, close the water supply angle valve, and stop the water supply before doing any maintenance work. DO NOT rinse this product with water during maintenance. Toilet Bowl Cleaning • Please ensure that the electrical plug is taken out. •... - Page 18 Cleaning the Steel Mesh Filter Note: Turn off the power and close the water supply angle valve. If your toilet is poorly flushing, please clean filter. • Unscrew angle valve nut • Remove filter net • Use a brush and warm water to clean filter net •...
-
Page 19: Product Specifications
PRODUCT SPECIFICATIONS Model Number ZETBCDER-12.WH Rated Voltage 120V, 60Hz Rated Power 1170W Power Cable Flush Volume 1.6/1.1 GPF Rough-in 12” Distance Water Pressure 0.09MPa (dynamic water pressure, flow rate Range 3.96Gal/min or more) Warm Air Volume Over .2m³/min Net Weight 99.2 lbs Waterproof Level IPX4... - Page 20 support@troneplumbing.com www.troneplumbing.com...
