INSTALLATION, USE AND MAINTENANCE MANUAL

mod.

W9000/W12000/W18000/W24000

FAST9000MS

FAST 12000 MS

FAST 18000 MS

FAST 24000 MS

ENG

MADE IN ITALY

Fast

FAST FH20009P

FAST FH20012P

FAST FH20018P

FAST FH2024P

Table of Contents

Need help?

Do you have a question about the Easy 9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fintek Easy 9

Page 1 Easy Easy Fast Fast mod. mod. mod. mod. W9000/W12000/W18000/W24000 W9000/W12000/W18000/W24000 Easy 9 cod. W9000 Easy 9 cod. W9000 FAST9000MS FAST9000MS FAST FH20009P FAST FH20009P Easy 12 cod. W12000 Easy 12 cod. W12000 FAST 12000 MS FAST 12000 MS FAST FH20012P FAST FH20012P Easy 18 cod.
Page 2: Table Of Contents
Table of Contents Safety Precautions ....................03 Owner’s Manual Unit Speciﬁcations and Features ................07 1. Indoor unit display..............................07 2. Operating temperature............................08 3. Other features ...............................09 4. Setting angle of airflow............................10 5. Manual operation (without Remote)........................10 Care and Maintenance ..................11 Troubleshooting ....................13 Installation Manual Accessories ......................16...
Page 3: Safety Precautions
Safety Precautions Read Safety Precautions Before Operation and Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classiﬁed as either a WARNING or CAUTION. CAUTION WARNING This symbol indicates the possibility of This symbol indicates the possibility property damage or serious consequences.
Page 4 CAUTION Turn off the air conditioner and disconnect the power if you are not going to use it for a long time. • Turn off and unplug the unit during storms. • Make sure that water condensation can drain unhindered from the unit. •...
Page 5: Owner's Manual
Before opening doors and access panels bearing the ULTRAVIOLET RADIATION hazard symbol for the conducting USER MAINTENANCE, it is recommended to disconnect the power. 5. The UV-C lamp can not be cleaned, repaired and replaced. 6. UV-C BARRIERS bearing the ULTRAVIOLET RADIATION hazard symbol should not be removed. WARNING This appliance contains an UV emitter.
Page 6 WARNING for Using R32/R290 Refrigerant When flammable refrigerant are employed, appliance shall be stored in a well -ventilated area where the room size corresponds to the room area as specifiec for operation. For R32 frigerant models: Appliance shall be installed, operated and stored in a room with a floor area larger than 4m . For R290 refrigerant models, appliance shall be installed, operated and stored in a room with a floor area larger than: <=9000Btu/h units: 13m...
Page 7: Unit Specifications And Features
Unit Speciﬁcations and Features Indoor unit display NOTE: Different models have different front panels and display windows. Not all the display codes describing below are available for the air conditioner you purchased. Please check the indoor display window of the unit you purchased. Illustrations in this manual are for explanatory purposes.
Page 8: Operating Temperature
Operating temperature When your air conditioner is used outside of the following temperature ranges, certain safety protection features may activate and cause the unit to disable. Inverter Split Type FOR OUTDOOR UNITS COOL mode HEAT mode DRY mode WITH AUXILIARY 16°C - 32°C 0°C - 30°C 10°C - 32°C...
Page 9: Other Features
A guide on using the infrared remote is not Breeze Away (some units) • included in this literature package. Not all This feature avoids direct air flow blowing on the functions are available for the air the body and make you feel indulging in conditioner, please check the indoor display silky coolness.
Page 10: Setting Angle Of Airflow
Setting Angle of Air Flow • Setting vertical angle of air ﬂow While the unit is on, use the SWING/DIRECT button on remote control to set the direction (vertical angle) of airflow. Please refer to the Remote Control Manual for details. NOTE ON LOUVER ANGLES When using COOL or DRY mode, do not set louver at too vertical an angle for long periods...
Page 11: Care And Maintenance
Care and Maintenance Rinse the filter with fresh water, then shake Cleaning Your Indoor Unit off excess water. BEFORE CLEANING OR Dry it in a cool, dry place, and refrain from MAINTENANCE exposing it to direct sunlight. When dry, re-clip the air freshening filter to ALWAYS TURN OFF YOUR AIR CONDITIONER the larger filter, then slide it back into the SYSTEM AND DISCONNECT ITS POWER SUPPLY...
Page 12 Maintenance – CAUTION Long Periods of Non-Use Before changing the filter or cleaning, • If you plan not to use your air conditioner for an turn off the unit and disconnect its power extended period of time, do the following: supply.
Page 13: Troubleshooting
Troubleshooting SAFETY PRECAUTIONS If ANY of the following conditions occurs, turn off your unit immediately! The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •...
Page 14 Issue Possible Causes The outdoor unit The unit will make different sounds based on its current operating mode. makes noises Dust is emitted from The unit may accumulate dust during extended periods of non-use, which will be either the indoor or emitted when the unit is turned on.
Page 15 Problem Possible Causes Solution Wait for the power to be restored Power failure The power is turned off Turn on the power The unit is not The fuse is burned out Replace the fuse working Replace batteries Remote control batteries are dead The Unit’s 3-minute protection Wait three minutes after restarting has been activated...
Page 16: Accessories
Accessories The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and fire, or cause the equipment to fail. The items are not included with the air conditioner must be purchased separately.
Page 17: Installation Summary - Indoor Unit
Installation Summary - Indoor Unit 15cm (5.9in) 12cm 12cm (4.75in) (4.75in) 2.3m (90.55in) Attach Mounting Plate Select Installation Location Determine Wall Hole Position Drill Wall Hole Connect Piping Connect Wiring (not applicable for some locations in North America ) Wrap Piping and Cable Prepare Drain Hose (not applicable for some locations in North America ) STEP...
Page 18: Unit Parts
Unit Parts NOTE: The installation must be performed in accordance with the requirement of local and national standards. The installation may be slightly different in different areas. Air-break switch （1）（2） Piping for indoor units (individual insulation of the pipes) Functional Filter (On Back of Remote Controller Wall Mounting Plate...
Page 19 NOTE ON THE ILLUSTRATIONS The drawings and illustrations in this manual are illustrative in nature. The shape, size or appea- rance of the units marketed may differ from what is shown here volume. Functional Filter (On Back of Wall Mounting Plate Main Filter - Some Units) Front Panel Drainage Pipe...
Page 20 20 EASY | FAST...
Page 21: Indoor Unit Installation
Indoor Unit Installation NOTE ABOUT WALL HOLE: Installation Instructions – Indoor unit If there is no ﬁxed refrigerant piping: PRIOR TO INSTALLATION While choosing a location, be aware that you Before installing the indoor unit, refer to the should leave ample room for a wall hole (see label on the product box to make sure that the Drill wall hole for connective piping step) model number of the indoor unit matches the...
Page 22: Drill Wall Hole For Connective Piping
348.4mm(13.7in) Step 3: Drill wall hole for connective piping 179mm(7.1in) 101mm(4.0in) 136mm(5.4in) 1. Determine the location of the wall hole based on the position of the mounting plate. Refer Indoor unit outline to Mounting Plate Dimensions. 2. Using a 65mm (2.5in) or 90mm(3.54in) (depending on models )core drill, drill a Right rear wall Left rear wall...
Page 23: Prepare Refrigerant Piping
Step 5: Connect drain hose Step 4: Prepare refrigerant piping The refrigerant piping is inside an insulating By default, the drain hose is attached to the left- hand side of unit (when you’re facing the back sleeve attached to the back of the unit. You must prepare the piping before passing it of the unit).
Page 24: Connect Signal And Power Cables
WARNING BEFORE PERFORMING ANY ELECTRICAL WORK, READ THESE BEFORE PERFORMING ANY ELECTRICAL REGULATIONS OR WIRING WORK, TURN OFF THE MAIN POWER TO THE SYSTEM. 1. All wiring must comply with local and national electrical codes, regulations and must be Step 6: Connect signal and power cables installed by a licensed electrician.
Page 25: Wrap Piping And Cables
pen front panel of the indoor unit. 1. O NOTE ABOUT WIRING Using a screwdriver, open the wire box cover on the right side of the unit. This will reveal THE WIRING CONNECTION PROCESS MAY the terminal block. DIFFER SLIGHTLY BETWEEN UNITS AND Front view REGIONS.
Page 26: Mount Indoor Unit
Step 8: Mount indoor unit Connect drain hose and refrigerant piping (refer to Refrigerant Piping Connection If you installed new connective piping to the section of this manual for instructions). outdoor unit, do the following: Keep pipe connection point exposed to If you have already passed the refrigerant perform the leak test (refer to Electrical piping through the hole in the wall, proceed...
Page 27: Connect Signal And Power Cables
7. Insulate unused wires with PVC electrical tape. Step 4: Connect signal and power cables Arrange them so that they do not touch any The outside unit’s terminal block is protected by electrical or metal parts. an electrical wiring cover on the side of the unit. 8.
Page 28: Refrigerant Piping Connection
Refrigerant Piping Connection When connecting refrigerant piping, do not let substances or gases other than the specified refrigerant enter the unit. The presence of other gases or substances will lower the unit’s capacity, and can cause abnormally high pressure in the refrigeration cycle. This can cause explosion and injury.
Page 29: Remove Burrs
Step 2: Remove burrs PIPING EXTENSION BEYOND FLARE FORM Burrs can affect the air-tight seal of refrigerant Outer Diameter of A (mm) piping connection. They must be completely Max. Pipe (mm) Min. Max. removed. Ø 6.35 (Ø 0.25”) 0.7 (0.0275”) 1.3 (0.05”) Hold the pipe at a downward angle to prevent Ø...
Page 30 Tighten the flare nut as tightly as possible by hand. Using a spanner, grip the nut on the unit tubing. While firmly gripping the nut on the unit tubing, use a torque wrench to tighten the flare nut according to the torque values in the Torque Requirements table below.
Page 31: Air Evacuation
Air Evacuation If there is a change in system pressure, refer Preparations and Precautions to Gas Leak Check section for information Air and foreign matter in the refrigerant circuit can on how to check for leaks. If there is no cause abnormal rises in pressure, which can damage change in system pressure, unscrew the cap from the packed valve (high pressure valve).
Page 32: Note On Adding Refrigerant
Note on Adding Refrigerant Some systems require additional charging depending on pipe lengths. The standard pipe length varies according to local regulations. For example, in North America, the standard pipe length is 7.5m (25’). In other areas, the standard pipe length is 5m (16‘). The refrigerant should be charged from the service port on the outdoor unit’s low pressure valve.
Page 33: Electrical And Gas Leak Checks
Electrical and Gas Leak Checks Before Test Run WARNING – RISK OF ELECTRIC SHOCK Only perform test run after you have completed ALL WIRING MUST COMPLY WITH LOCAL the following steps: AND NATIONAL ELECTRICAL CODES, Electrical Safety Checks – Conﬁrm that •...
Page 34: Test Run
Test Run DOUBLE-CHECK PIPE CONNECTIONS Test Run Instructions During operation, the pressure of the You should perform the Test Run for at least 30 refrigerant circuit will increase. This may minutes. reveal leaks that were not present during your Connect power to the unit. initial leak check.
Page 35: Packing And Unpacking The Unit
Packing and unpacking the unit Instructions for packing and unpacking the unit: Unpacking: Indoor unit: 1.Cut the sealing tape on the carton with a knife, one cut on the left, one cut in the middle and one cut on the right. 2.Use the vice to take out the sealing nails on the top of the carton.
Page 36 ENERGY EFFICIENCY STATEMENT We certify that the products listed below meet the requirements of article 9 paragraph 2 bis - Annex H - of the Ministerial Decree of 19 February 2007, already amended by the Ministerial Decree of October 26, 2007 and coordinated with Ministerial Decree of 7 April 2008, implementing the 2008 Financial Law (“Building Decree”) referred to by Law 220 of 13 December 2010 as well as by Legislative Decree 63 of 4 June 2013, Legislative Decree 90 of 3 August 2013, L 147 of December 27, 2013, L 208 of December 28, 2015, L 232 of December 11, 2016, L 205 of December 27, 2017, L 145 of December 30, 2018, L 160 of...
Page 37 External Unit Configuration (Nominal Internal Unit Capacity Kbtu/h) E.E.R. C.O.P. Unit A Unit B Unit C Unit D Unit E 2.64 2.64 3.29 3.82 2.64 3.52 3.29 3.81 2.64 5.28 3.25 3.73 3.52 3.52 3.24 3.79 MCAS 327 FH20 327 3.52 5.28 3.25...
Page 38 EN 60335-2-40:2003 + A1:2006 + A2:2009 + A11:2004 + A12:2005 + A13:2012 EN 62233:2008 ELECTROMAGNETIC COMPATIBILITY: EN 55014-1:2006 + A1:2009 + A2:2011 EN55014-2:1997 + A1:2001 + A2:2008 EN 61000-3-2:2014 EN 61000-3-3:2013 PERFORMANCE COMMISSION REGULATION (EU) EN14511 206/2012 626/2011 FINTEK SRL Ing. Chinaglia Nicola...
Page 39 For the lack of conformity manifested in the first 6 months of the date of the product, Fintek srl undertakes to repair the defect at no cost to the consumer. * From the seventh to the twenty-fourth month, the consumer will have to bear the cost of the fixed home call fee.
Page 40 REGULATIONS ON CONDENSED WATER UNITS AND U.E.S. SERIES Fintek srl guarantees assistance on products branded by Fintek srl or distributed by it for brands it owns installed on the national territory including Italy, RSM and Vatican City, for manufacturing defects if they are defective in materials or manufacturing. The guarantee consists in carrying out technical interventions with the customer or at our service centers, hereinafter referred to as C.A.T.,...
Page 41 In the event of a refusal, Fintek srl may exercise the right of retention pursuant to art. 2756 of the Italian Civil Code until complete satisfaction.
Page 42 Don’t miss the video presentations of our air-conditioning units and much more on our YouTube channel via Tonso di Gualtiero, 46 47896 Faetano RSM +378 0549 901 950 commercialeitalia@finteksrl.com www.finteksrl.com WWW.FINTEKSRL.COM WWW.FINTEKSRL.COM...
