What You Should Have Received
Please take a moment to make sure that you received everything that's included with your order. Each product is
described below.
RM500A-R3 (black), RM505A-R3 (beige):
(1) NetRack, 85"H x 26"W x 32"D (215.9 x 66 x 81.3 cm). It consists of a welded frame with two sets of adjustable
rails, a full-length steel rear door with a lock, and two perforated shelves. It also has vented, lift-off side panels, a
removable top panel, an open bottom for wire/cable access, and a locking plexidoor.
RM501-R3 (black), RM506-R3 (beige):
(1) Top fan panel. (For a complete list of the panels' included hardware, see page 6.)
RM502-R2 (black), RM507-R2 (beige):
(2) Bottom-mount tower shelves. (For a complete list of the shelves' included hardware, see page 3.)
RM503-R3 (black), RM508-R3 (beige):
(1) 12-gauge-steel caster base with four 3-inch (7.6-cm) non-locking casters.
RM314 (black, solid), RM315-R2 (black, vented), RM615-R2 (beige, vented):
(1) Extra stationary shelf. (For a complete list of the shelves' included hardware, see page 6.)
CUSTOMER
INFORMATION
NetRack
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
SUPPORT
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
DECEMBER 2002
RM500A-R3
RM507-R2
RM501-R3
RM508-R3
RM502-R2
RM314
RM503-R3
RM315-R2
RM505A-R3
RM615-R2
RM506-R3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Black Box NetRack RM500A-R3
Summary of Contents for Black Box NetRack RM500A-R3
- Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 SUPPORT Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 INFORMATION Web site: www.blackbox.com • E-mail: info@blackbox.com...
- Page 2 NETRACK The NetRack These fully welded and assembled racks (shown in Figure 1) are constructed of heavy 12-gauge steel. The mounting angles, also made of 12-gauge steel, are tapped with #10-32 thread in the EIA RS-310-D universal pattern. There’s ample space inside the frame sides for cabling, so large bundles of wire and cable fit without a problem.
- Page 3 NETRACK Bottom-Mount Tower Shelves (RM502-R2, RM507-R2) The following items are included with the RM502-R2 or RM507-R2: • (4) Support plates. • (8) ⁄ -20 x ⁄ " hexbolts. • (8) ⁄ -20 hexnuts. • (4) Slide-bracket assemblies. • (16) 10-32 x ⁄...
- Page 4 NETRACK Installing the Bottom-Mount Shelves 1. Attach the included support plates (item 1) to the cabinet base. Make sure that the flange is oriented as shown in Figure 2, and attach it using the included ⁄ -20 x ⁄ " hexbolts (item 2) and ⁄...
- Page 5 NETRACK 3. Extend the inner slide members of the slide assemblies you just installed as far as they’ll go, as shown in Figure 4. One at a time, take each shelf assembly (item 6) and slide it onto the the extended slide members, mating them with the slide members attached to the inside of the shelf.
- Page 6 NETRACK Extra Stationary Shelf (RM314, RM315, RM615-R2) The following items are included with the RM314, RM315, or RM615-R2: • (4) 10-32 x ⁄ " panhead screws. You must supply the following tools: • Phillips screwdriver To install the Extra Stationary Shelf, mount the shelf in the NetRack and secure it with the included 10-32 x ⁄...
- Page 7 © Copyright 2002. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
