- Page 1 PRODUCT MANUAL Model 100 Cable Machine Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800.435.3866 SpartanTool.com order by phone order online © 2024 Spartan Tool LLC Part # 02812203, 2812201K...
-
Page 2: Table Of Contents
MODEL 100 PU WITH 13/32 DRUM 02812201 ........ - Page 3 MODEL 100 DRUM 13/32” 02766401 ........
-
Page 4: Warnings
Warnings • Read the safety and operating instructions before using any Spartan Tool product . Drain and sewer cleaning can be dangerous if proper procedures are not followed and appropriate safety gear is not utilized . Read the engine owners’ manual for instructions and safety precautions on engine operation . -
Page 5: Technical Information
• Motor (Amp): 1 .4 • Extra-strength aluminum magnesium alloy construction • Drum Capacity: 75’ of 1/2” cable or 100’ of 13/32” or 5/16” cable • Retractable “Sure-Grip” handle • Cleaning Capacity: up to 100’ for 1-1/4” - 2” diameter line size SAFETY •... -
Page 6: Safety Instructions
-16 Ga . - for cords of less than 100 feet in length . -14 Ga . - for cords of 100 feet to 150 feet n length . If in doubt, use the next heavier gage . (The smaller the gage number, the heavier the cord .) When the machine is used outdoors, use... - Page 7 Safety Instructions Don’t assume that all three hole outlets are properly installed . Check the outlet and also the adapter, if used, with an outlet testing device which quickly indicates if a ground is connected . Correct a faulty test indication before proceeding . Don’t Abuse Cord .
- Page 8 Safety Instructions 20 . Do Not Over Torque Cables . Excessive and/or continued rotation of the drum once an obstruction has been encountered will over torque the cable . Kinking or breakage of cable may result . A worn cable can be identified as being very limber, kinked or as having flattened coils on the outside of cable .
-
Page 9: Machine Features
Tilt Ajustment Dial-A-Cable Power Feed Roll Aid FIG. 2 Assembly Instructions STUDY THESE INSTRUCTIONS CAREFULLY BEFORE YOU OPERATE YOUR EQUIPMENT The Model 100 consist of the following components (which are purchased separately): 1. Power Unit 3. Cable 5. Dial-A-Cable Power Feed (optional) 2. -
Page 10: Disassembling
Assembly Instructions DISASSEMBLING Position uncoupling stand at convenient distance from machine (2-3 feet) . Place coupling in groove, expansion pin up, on top of stand . Place tip of punch (provided with machine) in expansion pin . Drive the expansion pin down with a hammer . Note the shoulder on the tip of the punch which acts as a stop . -
Page 11: Operating
Operating WARNING: Never wear loose fitting clothing or jewelry when operating this machine . Always wear your Spartan riveted gloves when handling cable . Place your machine as close to the cleanout as possible . Do not allow more than 3 or 4 feet of cable between the machine and the cleanout . - Page 12 Operating NOTE: Kinkage and breakage of cable is caused solely by one thing: permitting the working end of the cable to get hung up in an obstruction while still twisting the other end of same with your motor, until something must give . Remember, the only way you can clean an obstruction from a line, or negotiate a bend in a line, is when your blades are rotating .
-
Page 13: Operating The Power Cable Feed
Operating the Power Cable Feed The adjusting knob on the top controls the tension on the cable . It should be set so that the cable feeds freely in-an-out of the drum . Tension can be increased by turning the handle to the right . Don’t apply too much tension - just enough to keep the cable moving is sufficient . -
Page 14: Changing Motor Brushes
Maintenance Instructions WARNING: Make sure the machine is unplugged from the electrical system before making any adjustment . CHANGING MOTOR BRUSHES With the motor uncovered, unsrew the brush cap . Remove brush, mark the top of the brush . Note the condition of brush end and brush length . -
Page 15: How To Install Cable Into Drum
Maintenance Instructions HOW TO INSTALL CABLE INTO DRUM Position external drum in a vertical position so that the cable can be inserted into the drum horizontally through the distributor arm . Rotate the external drum until the heads of the cable clamp screws on the back of the drum indicate that the clamp is at the top of the drum . -
Page 16: Model 100 Pu With 13/32 Drum 02812201
Model 100 PU with 13/32 Drum 02812201 Item Part Number Description 02812200 Model 100 Power Unit 02766401 Model 100 Drum 13/32” 44276700 Model 100 Roll-Aid... -
Page 17: Model 100 Pu With 1/2 Drum 02812202
Model 100 PU with 1/2 Drum 02812202 Item Part Number Description 02812200 Model 100 Power Unit 02766402 Model 100 Drum 1/2” 44276700 Model 100 Roll-Aid... -
Page 18: Model 100 Pu With 5/16 Drum 02812203
Model 100 PU with 5/16 Drum 02812203 Item Part Number Description 02812200 Model 100 Power Unit 02766403 Model 100 Drum 5/16” 44276700 Model 100 Roll-Aid... -
Page 19: Model 100 Power Unit 02812200
Model 100 Power Unit 02812200 DETAIL A 16 20... -
Page 20: Model 100 Power Unit 02812200
Model 100 Power Unit 02812200 Item Part Number Description Qty. 02767100 Base Assembly Mod 100 04674200 100 Trunnion Assy 44221500 Forward Reverse Switch 44295200 Model 100 PM Motor w/Gearbox 44225800 Air Bulb & Hose Assembly 44002600 Pressure Switch 44290700 Jumper Wire, 5in Brown... -
Page 21: Base Assembly 02767100
Base Assembly 02767100 Item Part Number Description Qty. 02761100 Base Side Plate 03443600 Bumper Assembly 00113901 Screw, Hex Head 1/4-20 x 1 02825100 Washer, Flat 1/4 01950800 Nut, Hex Kep 1/4-20 02767300 Base Casting... -
Page 22: Trunnion Assembly 04674200
Trunnion Assembly 04674200 Item Part Number Description Qty. 02829300 Box Connector 02765100 100 Trunnion Only 02761800 Pawl Bearing 02761900 Latch 02825500 Thumb Screw, 1/4-20 x 3/4 04645000 100 Switch Box 02825600 Scr, Bndg 12 x 1/2 Type B 02829500 Washer, Lock Split #12 Zinc... -
Page 23: Forward Reverse Switch 44221500
Forward Reverse Switch 44221500 Item Part Number Description Qty. 44221550 Toggle, ON/OFF/On Switch 44110500 Rubber Boot 44038900 Assy Jumper Wire-UL 2-1/2” Air Foot Switch 44225800 Item Part Number Description Qty. 04576900 Pressure Transmitter 04577100 Neoprene Air Hose 8’ Lg x 7/16 04652700 Clamp, Stepless Ear 1/2”... -
Page 24: Model 100 Drum 13/32" 02766401
Model 100 Drum 13/32” 02766401 Item Part Number Description Qty. 03449500 Outer Drum & Cover M-100 04204200 Clutch Assembly - 13/32 03446900 Inner Drum Assembly (100) 02759800 Bearing 02822500 Retaining Ring - Small 02822700 Retaining Ring - Large 02761300 Decal, Drum Model 100, 13/32... -
Page 25: Model 100 Drum 1/2" 02766402
Model 100 Drum 1/2” 02766402 Item Part Number Description Qty. 03449500 Outer Drum & Cover M-100 04204200 Clutch Assembly - 1/2 03446900 Inner Drum Assembly (100) 02759800 Bearing 02822500 Retaining Ring - Small 02822700 Retaining Ring - Large 02761300 Decal, Drum Model 100, 13/32... -
Page 26: Model 100 Drum 5/16" 02766403
Model 100 Drum 5/16” 02766403 Item Part Number Description Qty. 03449500 Outer Drum & Cover M-100 04204200 Clutch Assembly - 5/16 03446900 Inner Drum Assembly (100) 02759800 Bearing 02822500 Retaining Ring - Small 02822700 Retaining Ring - Large 02761300 Decal, Drum Model 100, 13/32... -
Page 27: Outer Drum 02766500
Outer Drum 02766500 Item Part Number Description Qty. 03414600 Cable Clamp 00162600 Washer, Flat 5/16” USS Zinc 00167100 Internal Tooth Lockwasher 02765600 Drive Stud 02820700 Nut, Heavy Hex Jam 5/16-18 02765700 Drum Hub Assembly (100) -
Page 28: Inner Drum 03446900
Inner Drum 03446900 Item Part Number Description Qty. 00167000 Washer, Lock - Internal Tooth 02759900 End Bracket Assembly (100) 02760100 Mainshaft Assembly (100) 02827200 Screw, Cap 1/4-20 x 7/8 02822500 Retaining Ring... -
Page 29: Pm Motor Assembly 44295200
PM Motor Assembly 44295200 Item Part Number Description Qty. 44295200 PM Motor M100 04231300 Brush Kit, 100-300-1065-2001... -
Page 30: Clutch Assembly 13/32 04204200
Clutch Assembly 13/32 04204200 Item Part Number Description Qty. 03414200 Clutch Hub & Bearing Assy 02760300 Plate Drive Mod 100 02760400 Clutch Facing, Scan-Pac 02760800 Plate, Friction 04237000 Spacer 1 .50 x 3 .00 16 GA 02760500 Spring Clutch 02866300... -
Page 31: Clutch Assembly 1/2 04203200
Clutch Assembly 1/2 04203200 Item Part Number Description Qty. 03414200 Clutch Hub & Bearing Assy 02760300 Plate Drive Mod 100 02760400 Clutch Facing, Scan-Pac 02760800 Plate, Friction 04237000 Spacer 1 .50 x 3 .00 16 GA 02760500 Spring Clutch 02866300... -
Page 32: Clutch Assembly 5/16 04204300
Clutch Assembly 5/16 04204300 Item Part Number Description Qty. 03414200 Clutch Hub & Bearing Assy 02760300 Plate Drive Mod 100 02760400 Clutch Facing, Scan-Pac 02760800 Plate, Friction 04237000 Spacer 1 .50 x 3 .00 16 GA 02760500 Spring Clutch 02866300... -
Page 33: Wiring Diagram
Wiring Diagram Item Part Number Description Qty. 44221500 Forward Reverse Switch 44002600 Pressure Switch 44290700 Assy . Jumper Wire 5” Brown 44290800 Assy . Jumper Wire 5” Yellow 04647800 Assy . Jumper Wire 5” Black 44216100 Disconnect, .250 Female 16-14 44290500 Bridge Rectifier PM Motor 44290501... -
Page 34: Roll-Aid (Optional) 44276700
Roll-Aid (Optional) 44276700 Item Part Number Description Qty. 44120700 Assy, Roll-Aid Wheel & Support 44276800 Assy, Locking Pin-Model 100 44287200 Assy, Toolbox Model 100 44276100 Handle-Model 100... -
Page 35: Wheel & Support Assembly 44120700
Wheel & Support Assembly 44120700 Item Part Number Description Qty. 02811900 Wheel 02829700 Casting, Machined 00760400 Washer, Flat 5/8 00114800 Screw, Hex Head 5/16-18 x 5/8 00165600 Washer, Lock 02820800 Nut, Hex Jam 5/8-18 03818400 Thumb Screw 02826300 Screw, Hex Head 5/8-18 x 3-1/4... -
Page 36: Maintenance Instructions
13/32 inch diameter x 75 feet 03449006 5/16 inch diameter x 75 feet 03449106 13/32 inch diameter x 100 feet 03449007 5/16 inch diameter x 100 feet Parts for 13/32” Inner-Core Cable #6 end Parts for 5/16” diameter Inner-Core Cable... -
Page 37: Model 100 Cables
Model 100 Cables 5⁄16" Multi-Purpose Inner-Core Cable. Designed for rodding 1 1⁄ 4 " to 13⁄32" Inner Core Cable. With Interchangeable Cutters and 1 1⁄2" lavatory, sink line waste and for light duty in 2" lines .Includes: Hooks for rodding 11⁄2" to 2" sink lines . Includes: Blade, 1"... -
Page 38: Cable Ends And Accessories
Cable Ends and Accessories 04220300 02878100 44113000 44120600 0279500 1/2" male Coupling 5/8" male Coupling .55" male Coupling .66" male Coupling 3/4" Male Coupling 04220400 02878000 44113100 44120500 02788300 1/2" Female Coupling 5/8" Female Coupling .55" Female Coupling .66" Female Coupling 3/4"... -
Page 39: Service Information
Service Information All requests for information, service or parts should include machine serial number . Additional copies of this Owner’s Manual can be downloaded free of charge from the Spartan Tool website, www .spartantool .com . For more information contact: Customer Service, Spartan Tool L .L .C . -
Page 40: Warranty Information
For our terms and conditions, including warranty, please visit https://spartantool .com/pages/terms- and-conditions . For warranty assistance, please contact us at (800) 435-3866 or customerservice@ spartantool .com . CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800 .435 .3866 SpartanTool .com... - Page 41 Notes...
- Page 42 CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800 .435 .3866 SpartanTool.com...
