- Page 1 PRODUCT MANUAL Model 758 Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 order by phone 800.435.3866 order online SpartanTool.com © 2024 Spartan Tool LLC Part #7580F000...
-
Page 2: Table Of Contents
Contents WARNINGS ......................4 TECHNICAL INFORMATION . - Page 3 758 PUMP TORQUE SPECIFICATIONS ........
-
Page 4: Warnings
Warnings • Read the safety and operating instructions before using any Spartan Tool product . Drain and sewer cleaning can be dangerous if proper procedures are not followed and appropriate safety gear is not utilized . Read the engine owners’ manual for instructions and safety precautions on engine operation . -
Page 5: Technical Information
Technical Information GENERAL • Max Water Output: 12 .6 GPM • Max Temperature: 140° F • Pipe Sizes: up to 12" diameter • RPM: 1420 • Max Water Pressure: 3,000 psi • Plungers: 3 • Max Water Flow: 12 GPM FEATURES TRAILER •... - Page 6 Technical Information SKID-MOUNTED • Compact installation for vans, trucks, pick-ups, and flatbed vehicles • Adjustable pump pulsation for maximum cleaning distance • 90° pivoting multi-position hose reel TRAILER • Manual pump pulsation for maximum cleaning distance • Rear-mounted operator controls •...
-
Page 7: Jet Applications Areas
Jet Applications Areas There are a wide variety of uses for the Spartan Model 758 Water Jet . Here are just a few: • Apartments/Hotels Mains and garage drains, remove all grease and debris from main lines under the buildings . -
Page 8: Towing Instructions
Towing Instructions Before hitching and towing on public roads, check that the tow vehicle uses a 2" ball on a hitch rated class II minimum, make sure keeper engages ball to secure hitch . Adjust if necessary . Because of the inherent water tank sloshing when towing, pull your jet empty at all times . The following 2 rules may limit your vehicles towing capacity and the tank fill level when towed . -
Page 9: Towing
Towing Instructions The coupler will need to be adjusted up or down depending on vehicle hitch height to ensure the jetter is towed level . TOWING Check that ball size is same as coupler . Check that Ball Load Rating is the same or greater than Coupler Load Rating Safety Chains Open clamp on hitch coupler . -
Page 10: Pump And Pressure System
Pump and Pressure System The pump and relief valve are the heart of your jet . They have been specifically designed for use with cold water (140°F max) for pipe jetting but can provide useful water flow for many other cleaning jobs using the optional wash down gun and special attachments . -
Page 11: High Pressure Water Jetting
High Pressure Water Jetting High pressure water jetting is the utilization of high pressure water combined with sufficient water flow to remove debris in drain/sewer pipes . High pressure water jetting alone cannot do the job . You need proper flow to wash debris downstream where it can be collected and removed . -
Page 12: Operator Controls
Operator Controls Pressure Gauge Choke & Throttle Control Oil rewind final drive chain every 50 hours (SAE 30 or heavier) Ignition Switch Rewind Push Button Control... - Page 13 Operator Controls Water Supply Valve Pulsaton Control (See Pulsation section of manual) Air Blow Out Drain Valve Filter Cup...
-
Page 14: Start Up
Engine Operation Procedure START UP Check water tank level . This water jet is equipped with a low water shut-off switch that will prevent the engine from starting at low water levels . Check fuel level . • Note: Also check engine and pump oil levels per manufacturer specifications (attached) . Turn high pressure reel supply valve “off”... -
Page 15: Operation Set Up
Operation Set Up Always locate the jet in the driest and safest place possible . Avoid high traffic areas and use flashers and safety cones . Position the jet so that the hose can be pulled directly off of the reel for use . Remember that jetting is most effective when you jet against the water flow . See Fig . -
Page 16: To Rewind Hose On Reel
Power Rewind Operating Instructions TO REWIND HOSE ON REEL • Release reel lock . • Use panel mounted push button switch to energize rewind motor . NOTE: Avoid pushbutton switch when rewind is not in use to avoid accidently activating rewind . Reel Supply Pressure Gauge Valve... -
Page 17: Pulsation
Pulsation Pulsation is activated when control knob is turned “in” (see activating pulsator procedure below) . As control knob is turned in, the pulsator stem will force the inlet valve plate open, compressing the valve spring . With inlet valve held open, center plunger cannot develop pressurized flow . -
Page 18: Lubrication & Maintenance
Lubrication & Maintenance Engine Oil Level Check Air Cleaner Oil Fill See Periodic Maintenance Chart below . For fuel, oil, and coolant recommendations see page 21 . See Engine Owner’s Manual for additional information . - Page 19 Lubrication and Maintenance General Maintenance • Check entire unit daily for water, fuel, and oil leaks . • Inspect machine daily for loose or lost nuts, bolts, etc . Clean inlet filter daily . Check battery electrolyte level every week or 10 hours . Fill with distilled water if needed .
- Page 20 Lubrication and Maintenance Pump Oil Rewind Drive Chain every 50 hours (SAE 30 or Heavier) .
-
Page 21: Fuel, Oil, & Coolant Recommendations
Fuel, Oil, & Coolant Recommendations FUEL Use only clean, fresh, unleaded regular grade gasoline . CAUTION: Do not mix oil with gasoline . Octane Rating The octane rating of a gasoline is a measure of its resistance to “knocking” . Use a minimum of 87 octane of the antiknock is recommended . -
Page 22: Operating Instructions
• The Model 758 will put out past 250’ feet but you will find the going slower due to the pressure loss from the extra hose length . Unless longer operation is common, we recommend the hose extensions be added only when needed . If moving the jet before the job is done, the hose can be disconnected from the jet to avoid pulling hose completely out of the pipe and restarting . -
Page 23: Operating Hints
• The Model 758 nozzles are designed to match the pressure and flow performance of your jet . They are key to efficient operation because they convert all of the engine and pump power to water speed for hose pull and for cleaning impact . -
Page 24: Encountering Obstructions
Operating Instructions ENCOUNTERING OBSTRUCTIONS • When obstruction or corners are encountered it may be necessary to manually rotate the hose (See Fig . 8) to enable feed through that area . The rotation will cause the jetting nozzle to jump over or around those areas . When it becomes necessary to manually rotate the hose to clear obstructions, any rotations in one directon must be followed by an equal number in the opposite direction to prevent kinks from building in the hose . -
Page 25: Optional Accessories
Optional Accessories 1/4” DRAIN HOSE The 1/4” hose and nozzle may be used to clean smaller dameter lines . Attach the 1/4” hose to the forward end of the wash down gun as described above . Use the 1/4” drain hose on lines 2”-4” similar to the reel hose . Again, use care not to discharge water unless the hose is in the pipe . On inside lines, use short bursts of the gun ot limit water backup . -
Page 26: Cold Weather Protection
Cold Weather Protection Winterize machine when stored below 32° F . Your machine can also be protected from freezing by using non alcohol based anti-freeze as follows: METHOD 1 • Use pressurized air to blow out any remaining water left inside pump and hose by using the air blow-out feature (see page 12) . METHOD 2 •... -
Page 27: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION Worn packng seals . Replace packng seals . Broken valve spring . Replace spring . Belt slippage . Tighten or Replace belt . Worn or Damaged nozzle . Replace nozzle . Fouled discharge valve . Clean valve assembly . - Page 28 Troubleshooting PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION No Fuel . Fill fuel tank . Fill water tank or Check low water float Low Water Level . switch . Engine will not run Low Oil Pressure . Check oil level . Check oil pressure switch . Check coolant level .
-
Page 29: How To Use Parts & Accessories
How To Use Parts & Accessories Spartan Tool will supply all parts or accessories you require as quickly as possible . In order to do so, we must have informaton from you, including machine serial number and part numbers . -
Page 30: Special Note
Special Note Though much of your Model 758 Jet is user serviceable, trained professional mechanics may be needed with pump, plumbing, engine, lights, hitch and axle experience . • Engine repair is best performed by your local engine repairman . -
Page 31: Wash Down Accessory Package - 73817300
Wash Down Accessory Package - 73817300 Item Part Number Description Qty. 73816500 Adapter, Swivel 3/8 M x 3/8 F 77719500 Hose, 1/4” x 75’ 77721400 Coupler, Quick Gun Male 77799800 Handgun Lance Vnozzle Assembly 77815800 Nozzle, 1/4” Domed (6) HandGun Lance Vnozzle Assembly - 77799800 Item Part Number... -
Page 32: 758 Pump - Exploded View
758 Pump - Exploded View... -
Page 33: 758 Pump Parts List
758 Pump Parts List Item Part Number Description Qty. Item Part Number Description Qty. 75800505 75800535 Crankcase Rear Support Ring 75800506 Oil Filler Cap 75800536 Rear V-Sleeve 75800507 O-Ring, Filler Cap 75800537 Rear Pressure Ring 75800508 Cover, Crankcase 75800538 Snap Ring... -
Page 34: Discharge Valve Assy . Kit (75800568)
758 Pump Torque Specifications Item Part Number Description Torque Amount 75800519 Hex Screw, Bearing Cover 125 in . - lbs . 75800526 Hex Screw, Connecting Rod 250 in . - lbs . 75800531 Bolt, Plunger 300 in . - lbs . -
Page 35: Unloader - 75802800
Unloader - 75802800 Item Part Number Description Qty. 75802801 Connection 75802802 Spring 75802803 Piston Housing 75802804 Seat 75802805 Ball 75802806 Spring 75802807 Inlet Fitting 75802808 O-Ring 75802809 O-Ring 75802810 Valve Housing 75802811 Plug 75802812 Back Ring 75802813 O-Ring 75802814 O-Ring 75802815 Back Ring 75802816... -
Page 36: Assy, Hand Crank - 79827300
Assy, Hand Crank - 79827300 Item Part Number Description Qty. 79827400 Weldment, Hand Crank 79827800 Plastic Handle w/Bolt & Nut 77763500 Decal, Crank Assembly, 3/8” Anti-Turn Around 75866500 Item Part Number Description Qty. 75866510 Nipple, 3/8” x 9” Long 73818400 Coupler, Female 3/8 Hose... -
Page 37: 758 Accessories
758 Accessories Part Number Description Part Number Description 75800900 Model 468 Accessories Nozzle, Open 75800800 Nozzle, Closed *44236800 4” Tri-Blade Cutter 77724000 Reducer 1/2 x 3/8 *44236900 6” Tri-Blade Cutter 73808600 *44237000 3/8 x 250 ft . Hose 8” Tri-Blade Cutter 73808601 3/8 x 75 ft . -
Page 38: Tire Safety Information
Tire Safety Information This porton of the User's Manual contains tire safety information as required by 49 CFR 575 .6 . The National Traffic Safety Administration (NHTSA) has published a brochure (DOT HS 809 361) that discusses all aspects of Tire Safety, as required by CFR 575 .6 . - Page 39 . If they appear even with the outside of the tread, the tire should be replaced . • Replacement tires should be the same size as the Warrior’s original tires . To prevent error and maintain safety, it is recommended that all replacement parts be purchased through Spartan Tool LLC .
- Page 40 Tire Safety Information Tire Balance and Wheel Alignment • Tires must be properly balanced to avoid vibrations and shaking of the trailer . A wheel alignment adjusts the angles of the wheels to position them correctly relative to the trailer's frame . Such adjustments can maximize the life of the tires, but should be performed by a qualified technician .
-
Page 41: Safety Information
If you believe that your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Spartan Tool LLC . If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign . -
Page 42: Warranty Information
Spartan Tool warrants its equipment to be free from defects in material and workmanship for two years from the date of purchase . To obtain warranty service, a purchaser should notify Spartan Tool in writing, at the address provided below, within the warranty period, and Spartan Tool will direct where to take or send the equipment for service . - Page 43 Notes...
- Page 44 CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800 .435 .3866 SpartanTool.com 7580F000...
