- Page 1 PRODUCT MANUAL Model 717 Mini Jet Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 order by phone 800.435.3866 order online SpartanTool.com © 2023 Spartan Tool LLC Part #71700000...
-
Page 2: Table Of Contents
Contents CONTENTS ......................2 WARNINGS . - Page 3 Contents ASSY, MOTOR 71706100 ....................24 PUMP, GIANT P221 (MODIFIED) 71705900 .
-
Page 4: Warnings
Warnings • Read the safety and operating instructions before using any Spartan Tool product. Drain and sewer cleaning can be dangerous if proper procedures are not followed and appropriate safety gear is not utilized. Read the engine owners’ manual for instructions and safety precautions on engine operation. -
Page 5: Technical Information
Technical Information GENERAL • Patented pulse technology reduces friction, continuously moves hose down the line and improves hose retrieval • Pipe Sizes: 1-1/4” to 6" diameter • Dual hose reel • Max Water Pressure: 1,500 psi • Easy-ride 10” pneumatic tires •... -
Page 6: High Pressure Water Jetting
High Pressure Water Jetting High pressure water jetting is the utilization of high pressure water combined with sufficient water flow to remove debris in drain/ sewer pipes. High pressure water jetting can also be used to remove debris on surfaces. A high pressure water jet consists of a pump, a motor or engine, a hose reel, a given length of hose and a various assortment of nozzles. -
Page 7: Jetting Applications
Jetting Applications There are a wide variety of uses for the Spartan Model 717 Water Jet. Here are just a few: • Apartments/Hotels • Mains and garage drains, remove grease and debris from main lines under the buildings. • Factories •... -
Page 8: Safety Procedures
(or grounding lug) to a known ground such as a cold water pipe. A three-prong adapter is provided and available through Spartan Tool. Never cut off the grounding prong for use in a two hole outlet receptacle. - Page 9 Safety Procedures • The Spartan Model 717 is equipped with a ground fault interrupter (GFI) to guard against shock. • Extension cords are not to be used with the Spartan Model 717. CAUTION: Always locate drain/sewer cleaning machine as close as possible to opening the pipe. Do not locate machine more than 3 feet from the opening of the pipe.
-
Page 10: Pre-Operation Checklist
Pre-Operation Checklist Before using the operational instructions for the “Mini Jet”, follow this checklist. Check the ground fault interrupter (GFI) before each use. (See instructions located on the GFI.) Do NOT use the GFI if the indicator light does not go on when reset or if the indicator light remains on when the test button is pushed in. Do NOT use extension cord with GFI. The inlet screen must be cleaned before each use to avoid damage to the pump or pulsator. -
Page 11: Operating Instructions
Operating Instructions WARNING: A minimum of 19 AMPS must be available on the electrical circuit at all times for the “Mini Jet” to function properly. CAUTION: - 20 AMP CIRCUIT - MAX PRESSURE 1500 PSI Make sure the Pre-Operation Checklist has been followed before opening the “Mini Jet”. Position the “Mini Jet”... - Page 12 Operating Instructions Turn on the water faucet. Prime the system by turning on the water inlet valve (see Fig. 5). Allow the water to flow until the air is purged from the system. Flip the motor switch “on”. Fig. 5 Allow the water jet hose to enter the pipe a few feet by holding the hose and pushing it into the pipe.
- Page 13 Operating Instructions PULSATION CONTROL 12. On pipes with minimum stoppage problems, it may not be necessary to engage the pulsator when using the “Mini Jet”. However, there are times when a pipe cannot be cleaned without the use of the pulsator. 13.
- Page 14 Operating Instructions WARNING: Be sure to re-adjust pressure control to 1,500 PSI by turning control knob left (counterclockwise) before stopping unit, this will make it easier to re-start the unit. (The fuse or breaker may trip repeatedly if the unit is operated over 1,500 PSI due to the higher current being drawn by the motor.) 14.
-
Page 15: Removal Of "Power Pak
Removal of “Power Pak” The minijet is actually “two water jets in one”. It can be operated as a complete long line unit or the “power pak” can be removed from the main reel frame and used as an independent portable unit in conjunction with shorter water jet hose assemblies. To remove the “power pak”... -
Page 16: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION Clean. Use adequate size. Clogged inlet filter or improper size. Check more frequently. Worn or damaged nozzle. Replace nozzle of proper size. Worn or damaged hose. Repair or replace. Inadequate water supply. Check flow available to pump. Broken Valve Spring. - Page 17 Troubleshooting PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION Damaged or worn plungers. Replace plungers. Abrasive material in the fluid being Install proper filtration on pump inlet pumped. plumbing. Check pressures and fluid inlet Frequent or premature failure of the Excessive pressure and/or temperature of temperature.
-
Page 18: Final Assembly - 71700000
Final Assembly - 71700000 Item Part Number Description Qty. Item Part Number Description Qty. 44245700 Assembly, Frame 71108700 Bushing, Reducer 3/8 NPT x 1/4 NPT 71709000* 71132900 Assembly, Power Pak Hose, Ultra Light w/Nozzle 25’ 71702600 Assembly, Reel 71108200 Nozzle, 20 Deg Closed 71110200 Assembly, Hose 21”... -
Page 19: Frame Assembly - 44245700
Frame Assembly - 44245700 Item Part Number Description Qty. 44245250* Weldment, Frame 717 44245000 Handle 44245400 Weldment, Handle Wrap 44245600 Cap, Protective 00116900 Screw, Hex Head 3/8-16 x 1-3/4” 82001030 Nut, Nylock 3/8-16 71100700 Tire, 10” Pneumatic 02994400 Screw, Hex Head 5/8-18 x 4” 02820800 Nut, Jam 5/8-18 77737100... -
Page 20: Pump Assembly - 71706300
Pump Assembly - 71706300 15 16 11 12 Item Part Number Description Qty. 71705900 Pump, Giant P221 71705955 Unloader 71136300 Elbow, 90 Deg. Female 3/8 71108700 Bushing, Reducer 3/8 MNPT x 1/4 FNPT 77721300 Coupler, Quick - Female 71705954 Thermal Relief Valve 544001-01* Gauge, 2000 PSI - 1/4 NPT 71106000... -
Page 21: Assy Reel 717 - 71702700
Assy Reel 717 - 71702700 Item Part Number Description Qty. 71702600 Reel, 717 71703100 Handcrank 71703200* Brake 71703300 Brake Knob 71703400* Bearing, 1” 71703500 Swivel, Replacement 717 3/8 Brass 71703600* Collar, Shaft 44052700 Decal, Drum Model 200 & 300 71108700 Bushing, Reducer 3/8M x 1/4 F Brass 542012-03* Nipple 3/8 x 1/4... -
Page 22: Assy, Motor & Pump 71705800
Assy, Motor & Pump 71705800 11 12 13 15... -
Page 23: 717 Pump Torque Specifications
Assy, Motor & Pump 71705800 Item Part Number Description Qty. 71706100 Assembly, Motor - 2 HP 71706300 Assembly, Pump 44244700 Assembly, Handle (includes 4, 5, & 6) 44245500 Weldment, Cord Holder 71102500 Grip, Foam 44245600 Cap, Protective 77759900 Screw, Hex Head 3/8-16 x 1-1/4” 79920150* Screw, Hex Head 3/8-16 x 1-1/2”... -
Page 24: Assy, Motor 71706100
Assy, Motor 71706100 Orange MTR Black White Yellow Item Part Number Description Qty. Item Part Number Description Qty. 71706000 Motor, Marathon 2 HP 71107000* Connector Twist-On Wire 71135003* 71125700* Cover, Motor (Machined) Wire, Black - 14 AWG THNN 4” 44005200* Guard, Toggle Switch (Black) 44244300* Assy, Motor Plate (incl. - Page 25 Assy, Motor 71706100 16 17 18...
-
Page 26: Pump, Giant P221 (Modified) 71705900
Pump, Giant P221 (Modified) 71705900 Item Part Number Description Qty. Item Part Number Description Qty. 71705905* Crankcase (Giant P221) 71705928* Wrist Pin (Giant P221) 71705906* 71705929 Oil Dipstick (Giant P221) O-Ring (Giant P221-07770) 71705907* Crankcase Cover, Short 71705930 Oil Seal (Giant P221) 71705908 Drain Plug &... -
Page 27: Pump- Exploded View 71705900
Pump- Exploded View 71705900 717 Pump Repair Kits PLUNGER PACKING KITS (71705950) OIL SEAL KIT (71705952) Part Number Description Qty. Part Number Description Qty. 71705933 71705930 V-Sleeve, Weep Oil Seal 71705934 V-Sleeve, Brown 71705935 Pressure Ring VALVE ASSEMBLY KIT (71705951) Part Number Description Qty. -
Page 28: Handgun Vnozzle Assy - Small 77799900
Handgun Vnozzle Assy - Small 77799900 Item Part Number Description Qty. 553006-01* Lance, Insulated Grip 18” 71126100 Nozzle, Vari- 77720100 Gun, Hand 77721300 Coupler, Quick Gun, 1/4” NPT Male 77721400 Coupler, Quick Gun, Male *May not be available on website. Call customer service for price and availability. -
Page 29: Unloader (Giant P221) 71705955
Unloader (Giant P221) 71705955 Item Part Number Description Qty. Item Part Number Description Qty. 71705964* Adjusting Spring Cap 71705977* Piston Rod 71705965 71705978* Pressure Spring Support Ring 71705966* 71705979* O-Ring 71705929 O-Ring 71705944 O-Ring 71705967* Support Ring 71705980* Kick Back Valve Spring 71705968* 71705981 O-Ring, Piston... -
Page 30: Standard Accessories
Standard Accessories Part Number Description 71108200 20° Nozzle (Closed) 1/4” I.D. Hose 71108300 30° Nozzle (Closed) 1/4” I.D. Hose 71108400 45° Nozzle (Closed) 1/4” I.D. Hose 71108500 20° Nozzle (Open) 1/4” I.D. Hose 71129200 20° Trap Hose Nozzle (Closed) 3/16” I.D. Hose 71137500 20°... -
Page 31: Optional Accessories
Optional Accessories Part Number Description 71129002* 1/4” I.D. x 50’ High Pressure Hose w/Couplings 71129003* 1/4” I.D. x 75’ High Pressure Hose w/Couplings 71129004* 1/4” I.D. x 150’ High Pressure Hose w/Couplings 71129101* 3/16” I.D. x 25’ Trap Leader Hose w/Couplings 71129103* 3/16”... -
Page 32: Warranty Information
Warranty Information For our terms and conditions, including warranty, please visit https://spartantool.com/pages/terms- and-conditions. For warranty assistance, please contact us at (800) 435-3866 or customerservice@ spartantool.com. CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800.435.3866 SpartanTool.com... - Page 33 Notes...
- Page 34 CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800.435.3866 SpartanTool.com...
