06、 Initial Use; 07、 Couple Of Frequencies; 08、 Low Battery Alarm; 09、 Safe Shutdown Advice - Microzone 8B-MINI Product Manual

DIGITAL PROPORTIONAL R/C
SYSTEM
Initial use:
When you unpack the package for the first time, please pair the frequency of the remote control with the
receiver, after the frequency pairing is successful, the remote control and the receiver will be tested at a
short distance, holding the remote control 10 to 15 metres away from the receiver, and then shake the
remote control rocker to observe whether the model is controlled by the remote control, and if it is controlled,
it means that the remote control and the receiver are working properly.
Couple of frequencies:
After the remote control is turned off and the receiver is powered on, press the frequency control button on
the receiver, and the indicator light will flash quickly, the receiver will enter the frequency control mode, as
shown in the following figure, then, turn on the remote control, and the receiver indicator light will turn on,
the receiver will receive the signal normally.
Low Battery Alarm:
At 0% battery, a ticking sound will be made, and the remote control power indicator will blink, indicating that
the power is low and needs to be charged.
Safe Shutdown advice:
Safe Shutdown Advice:To ensure the safety of the model and yourself, turn off the power to the model first
and then the power to the remote control after the model motor stops running.
www.microzone.cn
详细说明
FM button
2.4GHz
FHSS
-08-
