05、 Electricity Supply - Microzone 8B-MINI Product Manual

DIGITAL PROPORTIONAL R/C
SYSTEM
Electricity Supply:
DC4-9V, can be installed into the battery compartment using four No. 5 batteries, as shown in the following
figure,
Alternatively, insert a 2S lithium battery into the battery compartment socket, as shown in the following
figure,
You can also use an external power supply to connect to the DC power socket on the right side of the remote
control, as shown in the following
from the remote control battery compartment first.
www.microzone.cn
详细说明
DETAILED DESCRIPTION
figure,When using an external power supply, please Remove the battery
This DC port is not a charging
port,Cannot charge, only
available External connection
to simulator teaching Power
usage This DC port is not a
charging port,Cannot charge,
only available External
connection to simulator
teaching Power usage
2.4GHz
FHSS
-07-
