Kärcher BR 35/12 C BP Pack Quick Start

Q U I C K S T A R T
BR 35/12 C BP Pack
Start up
1
A
2
A
3
A
D
Warning
These are only brief instructions! Please read and comply with these instructions prior to using or servicing your
appliance.
The non-compliance of the operating and safety instructions may lead to damage of the appliance and to risks for
the operator and other persons.
B
B
B C
A Check battery charge indicator.
Green Battery charged
Orange: Battery almost empty
Red Appliance swithces off: Load battery
Charge the battery if required.
B Insert the mains plug into the socket.
Warning
Risk of damage. Only use the recommended de-
tergents. With respect to different detergents the
operator bears the increased risk regarding the
operational safety and danger of accident. Only
use detergents that are free from solvents,
hydrochloric acid and hydrofluoric acid.
Follow the safety instructions for using deter-
gents.
Note
Do not use highly foaming detergents.
Observe the dosing notes.
A Swivel up the carrying handle of the
wastewater tank.
Lift out the waste water reservoir and put it
aside.
B Open the cover of the fresh water reservoir.
Pour in water/detergent mixture. Maximum
temperature of the liquid 50 °C.
Close the cover of the fresh water reservoir.
Place the wastewater tank on the appliance.
A Release the star knob for the height adjust-
ment of the steering wheel.
Adjust the steering wheel to the desired
height.
Tighten the star handle.
B Adjust the dosing of the cleaning solution in
accordance with the soiling and the type of
the flooring material.
C Adjust the rotary handle of the brush contact
pressure to the desired value.
Only adjust the brush contact pressure when
the cleaning head is raised.
Note
If the appliance pulls forwards too strongly during
operation, reduce the contact pressure.
D Bring the Eco mode switch into the desired
position.
Normal operation: The appliance works at the
maximum brush speed and the highest suc-
tion performance.
Eco: The appliance works at reduced brush
speed and suction performance. This also re-
duces the energy consumption. The possible
action time with one charging cycle increas-
es.
5.966-232.0 06/13
