INSTALLATION
OPTIONAL
WALL ADAPTER
TUNNEL
OUTER
FRAME
INSTALLATION OVERVIEW
not including the frame. Dimensions of the frame you build should be
added to the opening size to determine the final size of the hole you cut
in your wall.

WALL INSTALLATION

OUTSIDE
FRAME
OPTIONAL WALL
ADAPTER TUNNEL
___________________________________________________________________________________________
6
POWER PET
DOOR
AC POWER ADAPTER
PLUGS IN HERE
www.hightechpet.com
MOUNTING YOUR POWER
PET DOOR
Your POWER PET door mounts flush
to any door or wall. The hardest
part of installing the POWER PET
door is cutting the hole. If the unit is
to be mounted in a door up to 1 ¾"
thick there is no framing necessary.
The pre-made Outer Frame that
came with your POWER PET door will
provide a finished look to the open-
ing. If you are installing your POWER
PET door in a wall, it is advisable to
build a frame around the opening or
order our convenient WALL ADAPT-
ER TUNNEL. The hole dimensions
given are for the finished opening

DOOR INSTALLATION

OUTSIDE
FRAME
