- Page 1 Meijer.com HUMANE CONTAIN Model HC-7000 Super Electronic Dog Fence INSTALLATION, OPERATING AND TRAINING MANUAL Please read this entire manual and study all illustrations before you begin installing your system...
- Page 2 Pulsed Proportional Stimulus System, a unique combination of progressively increasing sound and shock stimuli to train your pet quickly and safely. The HC-7000 is designed to be EFFECTIVE and most of all,...
-
Page 3: Table Of Contents
ACCESSORIES ......... 29 __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... -
Page 4: Part 1 - Introduction
KEY FEATURES: Pulsed Proportional Stimulus: Our unique Pulsed Proportional Stimulus System is what makes the HC-7000 system stand apart from all other systems made. A computer chip inside the RC-7 receiver collar actually detects the distance of your pet from the boundary wire by measuring the relative radio signal strength. - Page 5 The tone will drain the battery and stop when the battery runs down, letting the animal know it is now safe to escape!) The HC-7000 is not a zone type system. We apply a short shock stimulus at the very first correction along with the sound stimulus. This will discourage your dog from standing in the boundary field waiting for the tone to stop.
- Page 6 While we do not recommend full immersion the RC-7 collar is suitable for outdoor use in all weather conditions. For Dogs 10 lbs. to 200 lbs. The HC-7000 system is suitable for nearly all dog breeds. A common misconception is that larger dogs are more resistant to shock stimulus than smaller dogs.
-
Page 7: Part 2 - Detailed System Description
If there is a break in your boundary wire, the “BREAK” lamp will illuminate and the audible alarm will sound indicating that the boundary field is not. functioning and needs repair. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... - Page 8 5 feet. You can reduce the overall field width by turning the Field Width dial counter-clockwise. When you vary the effective field width of your system, the HC-7000’s unique Pulsed Proportional Stimulus System will automatically adjust to the new field strength setting.
-
Page 9: Ultra-Slim Receiver Collar
Test Lamp: This lamp illuminates whenever a shock pulse is being generated. Tone Speaker: Emits an audible training tone whenever a shock pulse is being generated. Shock Stimulus Probes: Contact the skin of the pet’s neck to administer the shock training stimulus. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... - Page 10 This is due to water on the outside of the speaker face. It does not mean that the inner works have gotten wet. Once the unit dries, the sound will return to normal. __________________________________________________________________________________________ www.hightechpet.com High Tech Pet Products, Inc.
-
Page 11: Installing/Replacing Rc-7 The Battery Pack
Where to Purchase Replacement Batteries Extra battery packs may be purchased online at www.hightechpet.com To locate the item go to www.hightechpet.com and search on the key words “High Tech Battery”. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... -
Page 12: Boundary Wire
Meijer.com BOUNDARY WIRE Even the boundary wire used on your HC-7000 system is unique. The copper alloy wire and insulating coating are all made specially to our custom specifications. We have designed it to be an efficient radio frequency broadcast conductor, with a mechanically strong core and an extra thick, extra tough, outdoor grade insulation that resists sunlight and moisture. -
Page 13: Part 3 - Step By Step Installation
Still, we recommend that you contact your utility companies to find out the location of all buried wires, mark them on your sketch and avoid running the boundary cable in these areas. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... - Page 14 Meijer.com TYPICAL LAYOUT FOR BOUNDARIES WITHIN BOUNDARY Twisted To Pond Twisted To Pool Pool Garage Boundary Wire Twisted Property Line Wire Transmitter Mounted in Garage Splice Splice Twisted Wire Cancels Field Figure 6 __________________________________________________________________________________________ www.hightechpet.com High Tech Pet Products, Inc.
- Page 15 Length of Field Wire = 15’ + 85’ + 220’ + 100’ + 190’ + 30’ = 640’ Length of Twisted Wire = 8’ x 2 = 16’ Total Wire Required 656’ Figure 7 __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com...
- Page 16 However it does work and the dog will learn that the sound of the alarm means the containment field is off. __________________________________________________________________________________________ www.hightechpet.com High Tech Pet Products, Inc.
- Page 17 This concept, shown in Figure 10. TIP: The amount of twist and the direction of the twist is of little importance, as long as the wires are touching each other along the entire “gate” section. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com...
- Page 18 Figures 9 and 10 above. SECTION 1 SECTION 2 Section 1 & 2 Twisted Together Figure 11 __________________________________________________________________________________________ www.hightechpet.com High Tech Pet Products, Inc.
-
Page 19: Assembling The Required Tools
The base station transmitter can be mounted to any wall near a 110 volt household wall outlet. Use the four screws provided with your system to mount the unit in a dry and protected area. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... -
Page 20: Testing The Receiver Collar Radio Function
Wind the 15 inch slack into a 5 inch diameter coil and bury it with the wire. Choose locations for the slack that are easily identified by a terrain feature and make a map of them. __________________________________________________________________________________________ www.hightechpet.com High Tech Pet Products, Inc. -
Page 21: Testing Your System
You should avoid running the wire near such structures. If your neighbor has an electronic dog fence you should bury the wire at least ten feet away. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... -
Page 22: Placing The Boundary Flags
Place the wire in the slit and seal with outdoor silicone caulk of matching color. Use asphalt sealant for asphalt driveways. Another option is High Tech Pet’s new optional Driveway Traverse Strip, which easily crosses driveways and walks with your electronic fence wire. -
Page 23: Part 4 - Training Your Dog
B. The instant your dog reacts, utter the retreat command and escort your dog into the safe zone. Use encouraging words, praise and pet your dog and give the animal a treat as before. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... - Page 24 If your dog shows the slightest sign of confusion or stubborn behavior, continue the training program using the lead. It’s okay to return to Stage 1 training if you think it is appropriate. __________________________________________________________________________________________ www.hightechpet.com High Tech Pet Products, Inc.
-
Page 25: Part 5 - Important Caution Notices
Also, make sure that your dog does not suffer from heart disease or any other chronic condition and be assured that your pet is in generally good health before using this product. __________________________________________________________________________________________ High Tech Pet Products, Inc. www.hightechpet.com... -
Page 26: Part 6 - Warranty & Customer Support
Meijer.com PART 6 – WARRANTY & CUSTOMER SUPPORT Your Humane Contain Model HC-7000 is the best made electronic fence you can buy and it’s covered by the best warranty. If anything goes wrong with your product within one year of purchase, you may return it to us for a free replacement. -
Page 27: Part 7 - Troubleshooting Procedures
PART 7 – TROUBLESHOOTING PROCEDURES If any part of the system is not working use the following troubleshooting procedure to isolate the failed component. Then contact High Tech Pet Products Customer Support to get it repaired or replaced. 1) Test Base Station Transmitter... -
Page 28: Testing The Containment Loop
Meijer.com • If you have a friend who also owns a High Tech Pet Humane Contain system that is working, test your collar(s) on their operating system by holding your collar next to their collar in the yard. As you move both collars toward the wire loop both collars should beep at about the same rate. -
Page 29: Repairing A Broken Or Intermittent Containment Loop
Extra Collar: Model RC-7, Extra Radio Collar. Got extra dogs? You may add an unlimited number of extra collars to your HC-7000 system. Extra Collar Battery Pack: Model BPK-3V8. It’s a good idea to keep several of these inexpensive battery packs handy to ensure that your system is always working. - Page 30 Meijer.com...
- Page 31 Meijer.com 2476 Palma Drive, Suite A Ventura, CA 93003 info@hightechpet.com www.hightechpet.com See our complete line of ingenious pet products at Humane Contain is a trademark of High Tech Pet Products, Inc. Manufactured in China Engineered in the USA!
- Page 32 Meijer.com High Tech Pet Products, Inc. 2476 Palma Drive, Suite A Ventura, CA 93003 www.hightechpet.com Rev. II – 4/27/2012 HC-7000-manual...
