Technical Data (cont'd)
Pre-requisites:
Permissible sash weight:
Sash rebate width (SRW):
Sash rebate height (SRH):
IMPORTANT:
The drive can be used without additional protective device up to protection class 3 (as per VFF leaflet KB.01
"Force-powered windows").
More information on the leaflet at: www.window.de, www.zvei.de and www.rwa-heute.de
The e-hardware is not suitable for use in smoke-heat extraction systems (RWA)!
The e-hardware must never be mounted in windows marked as an escape route!
36
Window type:
Window material:
Profile system:
single-sash, rectangular, tilt-and-turn element
timber, PVC or aluminium
12 mm rebate gap system with 13 mm hardware axis
max. 60 kg with open central locking
max. 80 kg with circumferential central locking
735 ... 1400 mm
470 ... 1600 mm
