- Page 1 ROBE FAZE 850 FT PRO USER MANUAL Version: 1.0 ROBE Lighting s.r.o. Czech Republic www.robe.cz...
-
Page 3: Table Of Contents
ROBE FAZE 850 FT PRO Table of contents 1. Introduction..........................4 2. Safety information........................4 3. Unpacking and Inspection......................4 4. Product overview........................5 5. Setting Up........................... 5 6. Language setting........................5 7. Operation............................ 5 8. Fluid............................. 8 9. Service and maintenance......................8 10. -
Page 4: Introduction
1. Introduction Thank you for choosing the ROBE FAZE 850 FT PRO. You now own a rugged and powerful state-of-the-art machine. Prior to use, we suggest that you carefully read all of the instructions. By following the suggestions found in this user manual, you can look forward to the reliable and satisfactory performance of your ROBE FAZE 850 FT PRO machine for years to come. -
Page 5: Product Overview
Step 1: Place the machine on a flat surface and in a suitable large area with at least 50 cm open space around the machine. Step 2: Fill the fluid tank with Robe approved fluid. Step 3: Connect the machine to suitable rated power supply.To determine the power requirement for the machine refer to the label on the back of the machine. - Page 6 Button Function [MENU] Scroll through setting menu [UP]/[TIMER] Up/Activate Timer function [DOWN]/[VOLUME] Down/Activate Volume function [STOP] Deactivate Timer/Volume function Or to select and memorize the setting. Hold seconds to start self-cleaning process Control menu Timer Interval XXX Sec Set interval from 1 to 300 seconds Timer Duration XXX Sec Set duration from 1 to 120 seconds...
- Page 7 Air Pump Sensor Turn On/Off air pump sensor Run Last Setting Turn On/Off run last setting function DMX Connector Pin Assignment The machine provides a - or 5-pin XLR connector for DMX connection. The diagram below indicates pin assignment information. Function Ground Data -...
-
Page 8: Fluid
8. Fluid Only use Robe water-based liquid for the Faze 850 FT PRO. The machine is tested and calibrated with this liquid to get the best output performance. Warranty will be void if any other type of liquid is used, improper use of liquid may lead to machine failure and malfunction. -
Page 9: Status Messages
minute (approx.) Fluid tank capacity: 2.8 L Fluid consumption: ml per minute Recommended Fluid: Robe water-based fog fluid for the best effect Control options: LCD Menu, DMX 512, Wireless DMX Adjustable output volume and fan speed DMX channels: 2 channels...
