Defender 3
Online Emergency Central Lighting Inverter (CLI)
Technical Specifications
PART 1 GENERAL
1.1 SUMMARY
A. This specification describes a three phase, on-line, double conversion, solid state Lighting Inverter System
utilizing Patented ECM Technology here after referred to as the CLI. The CLI shall operate in conjunction with
the existing building electrical system to provide high quality power conditioning, back-up power protection
and distribution for Lighting loads and other critical loads. The system shall consist of a solid-state inverter, a
temperature compensated rectifier/battery charger, a 100% rated for continuous duty static switch, an inter-
nal maintenance bypass switch, battery plant, status/control panel, and synchronizing circuitry as described
1.2 STANDARDS
A.
The CLI shall meet the requirements of the following standards:
1.
IEEE 587-1980/ANSI C62.41 1980 Standards for Surge Withstand Ability
2.
FCC rules and regulations of Part 15, Subpart J, Class A
3.
Listed under UL 924, Standards for Lighting Inverter Equipment
4.
NEMA PE 1 (National Electrical Manufacturers Association) - Lighting Inverter Systems
5.
NEMA 250 (National Electrical Manufacturers Association) – Enclosures for Electrical Equipment
(1000 Volts Maximum)
6.
NFPA 70 – National Electrical Code
7.
ISO 9001
8.
Occupational Safety & Health Administration (OSHA)
Title: Micro
01
Doc No.: 018-1000-02
Description: Emergency Lighting Inverter User's Manual
Phone :
Fax:
Rev: NR
Website:
Date: 07/26/2016
E-Mail:
1.877.DSPM.POWER
-
1.877.377.6769
909.930.3335
www.dspmanufacturing.com
