4. ELECTRONIC PINOUTS AND SCHEMATICS

4.1 SPIKE-2 CPU NODE 0

509-1003-01
DIRECT SWITCH MAPPING (CN25)
The coin-door diagnostic switches are connected directly to the CPU node via the Cabinet Node. Note that both the CPU and
Cabinet nodes are required for diagnostic switch operation.
ID Name Conn.
C1 DIP 1 -
C2 DIP 2 -
C3 DIP 3 -
C4 DIP 4 -
C5 DIP 5 -
C6 DIP 6 -
C7 DIP 7 -
C8 DIP 8 -
C9 Service Select CN25
C10 Service Plus CN25
C11 Service Minus CN25
C12 Service Back CN25
CONNECTORS
ID ConnectorType Description
CN1 5-Pin .156" Header Backbox 2-channel amplified speaker out
CN2 3-Pin .100" Header Console Port
CN3 7-Pin .100" Header Headphone connector
CN4 2-Pin .156" Cabinet 1-channel amplified speaker out
CN5 7-Pin .100" Header Line In/Out
CN6 34 Pin 2.00mm Header LCD display connector
CN7 5-Pin .156" Header 48V supply from main power supply
CN8 6-Pin .100" Header SPI Serial
CN9 USB USB connector - for software updates,
audit dumps, and expansion modules
CN9 USB USB connector - for software updates,
audit dumps, and expansion modules
CN10 HDMI HDMI Out
CN11 RJ45 SPIKE node bus - to cabinet node N1
CN12 RJ45 SPIKE node bus - To Topper accessory Kit
CN13 SD CARD SD Card connector
CN14 5-Pin .100" Header LCD Backlight
CN15 3-Pin .100" Header Backbox Light
CN16 4-Pin .100" Header 3.3v / 5v / 12v
CN17 ETHERNET ETHERNET connector
CN21 SATA Header SATA connector
CN22 RJ45 SPIKE node bus - to playfield node
CN25 12-Pin .100" Header Dedicated switch inputs - service, volume
switches
™/© Netflix, Inc. 2019. Used with permission.
Input InputWire GND GroundWire
Pin Pin
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
- - - -
1 LGN-GRY 11 BLK-WHT
2 LGN-VIO 11 BLK-WHT
3 LGN-BLU 11 BLK-WHT
4 LGN-BLK 11 BLK-WHT
COMPONENTS
ID
S1
S2
SD CARD (CN13)
BT1
STATUS LEDS
LEDID
48V
3.3V
5V
12V
VA
VNB
5V (CPU)
SDIO ACT
STATUS
μSD ACT
D23
STRANGER THINGS PRO MANUAL 500-55Y1-01
ELECTRONICPINOUTSANDSCHEMATICS
Location Type
CPU Node
CPU Node
CPU Node
CPU Node
CPU Node
CPU Node
CPU Node
CPU Node
Coin Door
Coin Door
Coin Door
Coin Door
Name
DIP Switches
Reset Switch
For system SD card. Note: only to be removed if instructed to
by Stern Service.
BR1225 3V Lithium battery for game clock between power
cycles
Name Color
+48V Supply In Red
+3.3V Logic Red
+5V Logic Red ON: Logic power supply is good. OFF: Logic
power supply bad, call tech support.
+12V Backbox Red ON: Back box LED power good. OFF: Back-
Illumination
+30V Audio Red
+9V Node Bus Red
+5V Logic Red
Not Used Red Should remain unlit as it is not currently used.
CPU Heartbeat, Red Double blink ~1/2 second: Good, Processor
System Status running. OFF: Processor not running, call
tech support.
Activity indicator Red Should blink rapidly when reading or writing
for micro SD Card to micro SD card.
Netbridge Status Red Should blink once every ~1/2 second.
Address PartNumber
0-SW-0 -
0-SW-1 -
0-SW-2 -
0-SW-3 -
0-SW-4 -
0-SW-5 -
0-SW-6 -
0-SW-7 -
0-SW-9 180-5192-04
0-SW-10 180-5192-02
0-SW-11 180-5192-02
0-SW-12 180-5192-00
Description
ON: Main system power is connected. OFF:
No 48V system power. Check power supply
connections, cables, and fuses.
ON: Logic power supply is good. OFF: Logic
power supply bad, call tech support.
box LED power bad, call tech support.
ON: Audio power supply is good. OFF: Audio
power supply off, call tech support.
Power for the Node bus. ON: Power for
node bus good. OFF: Power to node bus not
detected, call tech support.
ON: Logic power supply is good. OFF: Logic
power supply bad, call tech support.
