Technical Specifications

Standards:
Data Transfer Rate:
Media Interface Exchange:
DC inputs:
Power Adapter:
Power Consumption:
Operating Temperature:
Operating Humidity:
Storage Temperature:
Dimensions:
Weight:
EMI:
Safety:
DSL-300G ADSL Ethernet Modem User's Guide
General
ITU G.992.1 (G.dmt) Annex A
ITU G.992.2 (G.lite) Annex A
ITU G.994.1 (G.Hs)
ANSI T1.413 (Issue 2)
IEEE 802.3
IEEE 802.3u
IEEE 802.1d
RFC 2684 (displaces RFC 1483)
Supports RFC 1213 (MIB II for IP)
G.dmt full rate: Downstream up to 8 Mbps
Upstream up to 640 Kbps
G.lite: Downstream up to 1.5 Mbps
Upstream up to 512 Kbps
RJ-11 port ADSL telephone line connection
RJ-45 port for 10/100BASE-TX Ethernet connection
RJ-14 port for console serial connection
Physical & Environmental
Input: 100V ~ 240V AC 50 ~ 60Hz
Output: 7.5V DC 1.5A
10 Watts (Max)
5° to 40° C (41° - 104° F)
5 to 95% (non-condensing)
-20° to 70° C
176 mm x 135 mm x 27.2 mm
360 gm
FCC Class B CE
CSA
13
A
