Transmitter
The transmitter includes the battery,
memory for measurement values and
recognizes the probe type.
Ring
The ring is used to to connect the
transmitter and the probe. Slide the
ring onto the sensor end of the probe
and thread it onto the transmitter.
UNPACK THE BOX
Replaceable Probe
S
R
The replaceable probe includes the sensor and reference electrode. It is covered
with a protective cap.
The sensor is the metallic spot at the tip of the probe (S). The diaphragm of the
gel-filled reference electrode is the white spot in the tip (R).
Charger with USB Cable
The charger with USB cable charges
the probe wirelessly. The logo side of
the transmitter must be facing up.
Ring
Transmitter
Replaceable Probe
The brush is used to clean the probe.
Brush
3
