This instruction booklet covers these models:
CAM-109S, CAM-209S
(All finish options)
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel 01934 744466.
aftersales @ vado.com
www.vado.com
Version 1, 1-1-24
Vado
fax 01934 744345
CAMEO
Installation Guide
Wall mounted mono basin mixer
CAM-109S
CAM-209S
CAM-109S
Cleaning Instructions
If these instructions are not followed, your guarantee may
be invalidated.
- Clean only with water and a soft damp cloth
- Do not use any aggressive/corrosive cleaning products
- Do not use abrasive cloths
Due care needs to be taken to ensure the appearance is retained.
For further cleaning instructions, please consult this product's user guide.
Keep for future reference
CAM-209S
Advertisement
Related Manuals for VADO CAMEO CAM-109S
Summary of Contents for VADO CAMEO CAM-109S
- Page 1 - Do not use abrasive cloths tel 01934 744466. fax 01934 744345 Due care needs to be taken to ensure the appearance is retained. aftersales @ vado.com For further cleaning instructions, please consult this product's user guide. www.vado.com Keep for future reference...
- Page 2 Please read these instructions carefully before starting installation and keep for future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee.
- Page 3 79mm 220mm Cartridge shroud 53-73mm 53-73mm 123mm 100mm 39mm 39mm 1/2” 1/2” 100mm 1/2” 1/2” 58mm...
- Page 4 220mm 53-73mm 115mm 39mm 39mm 1/2” 1/2” 100mm...
- Page 5 Min - 1 Bar* Max - 5 Bar * 0.2 bar for Low Pressure variant 53-73mm...
- Page 6 Spout shroud Spigot Wall plugs Spout Valve Outlet Grub screws Make sure that the O-ring is in place in the back of the shroud. Slide the spout over the spigot until the shroud is in contact with the wall. Cold inlet Secure the spout using the two grub screws on the underside, tighten with the Screws supplied hex key.
