This instruction booklet covers model:
CEL-148D/2/RO, CEL-148D/2/SQ, ELE-148D/2, LIF-148D/2, MIX-148D/2,
NOT-148D/2, ORI-148D/2, PHA-148D/2, PHO-148D/2.
CEL-148D/3/RO, CEL-148D/3/SQ, ELE-148D/3, LIF-148D/3, MIX-148D/3,
NOT-148D/3, ORI-148D/3, PHA-148D/3, PHO-148D/3.
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel 01934 744466.
aftersales @ vado.com
www.vado.com
Version 2, 1-7-23
Vado
fax 01934 744345
Installation Guide
TRIM-KIT
Keep for future reference
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VADO CEL-148D/2/RO
Summary of Contents for VADO CEL-148D/2/RO
- Page 1 Installation Guide TRIM-KIT This instruction booklet covers model: CEL-148D/2/RO, CEL-148D/2/SQ, ELE-148D/2, LIF-148D/2, MIX-148D/2, NOT-148D/2, ORI-148D/2, PHA-148D/2, PHO-148D/2. CEL-148D/3/RO, CEL-148D/3/SQ, ELE-148D/3, LIF-148D/3, MIX-148D/3, NOT-148D/3, ORI-148D/3, PHA-148D/3, PHO-148D/3. Vado Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466.
- Page 2 Important - please read Operating specifications Conditions of use for Type 2 valves Please read these instructions carefully before starting installation and keep for future reference. High Pressure Remove all packaging and check the product for missing parts or damage before Maximum Static Pressure (Bar) starting installation.
- Page 3 Operating Specifications Contents of Packaging For illustrational purposes, the Celsius plate In-service testing: COVER BOX and handles are shown. It is a recommended that all TYPE 2 approved valves are tested and evaluated against the commissioning setting results once a year. Whilst this is a recommendation in user / owner domestic dwellings, a duty of care obligation should be considered in commercial bathroom or subletting situations.
- Page 4 Dimensions Dimensions 40mm 40mm 40mm 47mm 130mm 130mm 130mm CEL-148D/2 CEL-148D/2 MIX-148D/2 NOT-148D/2 40mm 40mm 40mm 65mm 146mm 130mm ELE-148D/2 LIF-148D/2 ORI-148D/2 PHA-148D/2...
- Page 5 Dimensions Commissioning Please check the following: 40mm 1. The designation of the thermostatic mixing valve matches the application. 2. The supply pressures are within the valves operating range. 3. The supply temperatures are within the valves operating range. 4. Isolating valves (and strainers preferred) are provided. If all these conditions are met, proceed to set the temperature as stipulated within these installation instructions.
- Page 6 Installation Handle installation NOTE: For illustrative purposes only the Celsius handles and cover plate is shown below. Please follow the same procedure to install the other handles. Cover plate Flow control handle (top). Carefully slide the flow control handle onto the splines of the top valve, with the lever at 12 o’clock.
