PACKAGE CONTENTS
A –Deck Lights x 1
B – Male Plug x 1 (with 12 in. wire)
Per assembly and Installation
Installing the fixture with the wire routed behind the
1
mounting surface
NOTE: This document provides two different methods for routing
the lead wire. You can choose which method best fits your needs.
Place the cardboard template (G) on the mounting surface and mark
□
where the holes should be for the male plug (B) and the self-threading
screws (E).
Use at least a 7/16 in. drill bit to drill a hole on the surface large
□
enough
Insert the male plug (B) through the hole on the mounting surface.
□
Insert the male plug (B) into the female plug (D).
□
Place the d eck lights (A) against the mounting surface.
□
Use a Phillips screwdriver to screw the self-threading screws (E)
□
through the two holes on the d eck lights (A) to secure the d eck lights (A)
to the mounting surface.
C – Wire Connector (with 36 in. wire) x 1
D –Female Plug x 1
E – Self-Threading
F– Plastic Anchor
Screw (45 mm) x 2
Installing the fixture with the wire in front of
2
the mounting surface
Place the cardboard template (G) on the mounting surface and
□
Mark where the holes should be for the self-threading screws
□
(E).
Insert the male plug (B) into the female plug (D).
□
The wire plugs may be retained inside the back of the d eck
□
(A) by coiling the wire and plugs and dropping the wire
lights
through the notch in the bottom of the d eck lights (A).
The wire plugs may be left outside the d eck lights (A) by
□
dropping the wire through the notch in the bottom of the d eck
lights
(A) with the plugs outside the back plate when the fixture
is mounted. The connected plugs are waterproof.
Place the d eck lights (A) against the mounting surface.
□
Use a Phillips screwdriver to screw the self-threading screws
□
(E) through the two holes on the d eck lights (A) to secure the
d eck lights (A) to the mounting surface.
1
Item # 1008 555 927
Model # LBW2601LX-01
Use and Care Guide
LED DECK LIGHTS
G – Cardboard
(25 mm) x 2
Template x1
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY LBW2601LX-01
Summary of Contents for HAMPTON BAY LBW2601LX-01
- Page 1 Item # 1008 555 927 Model # LBW2601LX-01 Use and Care Guide LED DECK LIGHTS PACKAGE CONTENTS A –Deck Lights x 1 C – Wire Connector (with 36 in. wire) x 1 E – Self-Threading F– Plastic Anchor G – Cardboard B –...
- Page 2 Assembly and Installation (continued) Installing the fixture on a surface using plastic anchors Connecting the wires If installation requires the plastic anchors (F), then place the cardboard □ WARNING: The wire connector (C) contacts have sharp edges for template (G) on the mounting surface and mark where the holes should piercing the main low voltage cable.
-
Page 3: Troubleshooting
Troubleshooting Problem Possible Cause Solution □ □ Check the outlet and ensure that a breaker or GFCI circuit has not been tripped. The fixture will There is no power. □ □ Follow the wires from the fixture and ensure a continuous connected path back to the not light. - Page 4 Artículo # 1008 555 927 Modelo # LBW2601LX-01 GUÍA DE USO Y MANTENIMIENTO LED LUCES DE CUBIERTA PACKAGE CONTENTS Conector Cable (con un cable de 36 pulgadas) x1 Tornillos Autorroscantes( 45 mm ) x2 A –Luz de Cubierta x 1 C –...
- Page 5 Montaje e Instalación (continuación) Instalación de la luminaria en una superficie con Conectando los cables anclajes de plástico ADVERTENCIA: Los contactos del cable conector (C) tienen Si la instalación requiere los anclas de plástico (F), coloque la plantilla de bordes filosos para atravesar el cable principal de bajo voltaje. No □...
-
Page 6: Solución De Problemas
Solución de Problemas Problem Possible Cause Solution □ □ Verifique el tomacorriente y asegúrese que no esté apagado el interruptor o circuito GFCI. El accesorio no No hay corriente. □ □ Siga los cables desde el accesorio y asegúrese que esté en buen estado bien conectado al enciende. -
Page 7: Fcc Warning
FCC Warning Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
