*x*SAFETY INSTRUCTIONS
PRECAUTIONS DURING SERVICING
1. Parts identified by the 4\ (**) symbol are critical for
_ safety. Replace only with parts number specified.
2. In addition to safety, other parts and assemblies are spe-
cified for conformance with such regulations as those ap-
plying to spurious radiation.
These must also be replaced only with specified replace-
ments.
Examples: RF converters, tuner units, antenna selector
switches, RF cables, noise blocking capacitors, noise
blocking filters, etc.
3. Use specified internal wiring. Note especially:
1) Wires covered with PVC tubing
2) Double insulated wires
3) High voltage leads
4. Use specified insulating materials for hazardous live
parts. Note especially:
1) Insulation Tape
2) PVC tubing
3) Spacers (Insulating Barriers)
4) Insulation sheets for transistors
5) Plastic screws for fixing microswitch (especially in
turntable)
5. When replacing AC primary side components (trans-
formers, power cords, noise blocking capacitors, etc.),
wrap ends of wires securely about the terminals before
soldering.
to bo
6. Observe that wires do not contact heat producing parts
(heatsinks, oxide metal film resistors, fusible resistors,
etc.).
*xINFORMATION
7. Check that replaced wires do not contact sharp edged or
pointed parts.
8. Also check areas surrounding repaired locations.
9. Use care that foreign objects (screws, solder droplets,
etc.) do not remain inside the set.
SYMBOLS FOR PRIMARY DESTINATION
Alphabet indicates the destination of the units as listed below.
__Symbols _| —————— Destinations
| a
| CE) | Camda
[CE] | Europe (except UK)
| CS) | Australia
ee 2° W. Germany only
| (0) | UniversalArea Cd
Custom version
tJ
VOLTAGE CONVERSION ((U |Model only)
Before connecting power cord or assembling the platter. Set the
VOLTAGE SELECTOR on the top of the cabinet, to correct
voltage is indicated for your area.
110—120 V oS V
