- Page 1 INITAL OPERATION INSTRUCTION OmniCycle Connect ® Before initial operation the dealer needs to observe this instruction! Art. No.: A009-389_Rev 01 Art. Nr.: A003-983_Rev 05 Last edit: CW27/2024 Letzte Bearbeitung: KW30/2023...
- Page 2 OmniCycle Connect ® Initial operation instruction OVERVIEW Therapy grips Crank (application part Type BF) Upper body exerciser Control and display unit USB-interface Locking-pin for height adjustment of safety handle/upper body exerciser Adjustment of inclination for safety handle/upper body exerciser Foot fixing Foot rest (application part Type BF) (10) Base unit...
- Page 3 OmniCycle Connect ® Initial operation instruction 2 DELIVERY The OmniCycle Connect comes with individual options. This instruction describes all steps that ® are required for initial operation. Additional information on how to use, cleaning and disinfection etc. are described in the user manual OmniCycle Connect.
- Page 4 OmniCycle Connect ® Initial operation instruction ADJUSTING DEVICE BASE To increase stability of the OmniCycle Connect adjust the t-bar device base as follows (e.g. ® device base with transport castors adjustment works the same for all device bases): Tilt OmniCycle ®...
- Page 5 OmniCycle Connect ® Initial operation instruction 4 ADJUSTING 2-STEPPED RADIUS ADJUSTMENT The crank radius can be adjusted depending on the mobility of the user. The foot rest with 2-stepped radius adjustment can be adjusted to 75 mm or 110 mm. Note: The crank radius needs to be adjusted only as needed.
- Page 6 OmniCycle Connect ® Initial operation instruction 6 INSTALLATION OF CONTROL AND DISPLAY UNIT WITH 7‘‘- COLOR SCREEN In order to assemble the control and display unit with 7” color screen: Open screw 2 with a suitable tool. Remove service cover 1. Plug cable 3 into control and display unit.
- Page 7 OmniCycle Connect ® Initial operation instruction Fix service cover 1 in control and display unit (make sure that the cable gets not clamped). Screw 2 service cover 1 with suitable tool. Fix control and display unit 3 to the holder 4 on the upper body exerciser/safety handle. Scew control and disply unit with three knurled nuts 5.
-
Page 8: Connecting The Main Cable
OmniCycle Connect ® Initial operation instruction 7 CONNECTING THE MAIN CABLE Material damage due to incorrect installation! Make sure that plug is plugged in correctly when connecting cables. Observe position of plug. Caution Use exclusively power plug supplied by the manufacturer. Open protective lid 2. -
Page 9: Setting Language
OmniCycle Connect ® Initial operation instruction 8 SETTING LANGUAGE Language can be set in the sub menu of the control and display unit. In order to access the sub menu: Press STOP-button and Minus-button of the resistance adjustment at the same time. The sub menu opens. - Page 10 OmniCycle Connect ® Initial operation instruction 10 SETTING MOTOR POWER The motor power is adjustable individually for every training program and every user. has a stronger effect on the user's legs/arms with a small crank radius than with a large crank radius.
- Page 11 OmniCycle Connect ® Initial operation instruction low motor power: – low exercising resistance – early spasm detection – for sensitive joint systems Example on how to use the diagram: A user with a body weight of 80 kg and a chosen (therapeutic) crank radius of step 3 should exercise with a motor power of 15 Nm.
- Page 12 Manufacturer: THERA-Trainer medica Medizintechnik GmbH Blumenweg 8 88454 Hochdorf Germany Tel.: +49 7355-93 14-0 Fax: +49 7355-93 14-15 E-Mail: info@thera-trainer.com Internet: www.thera-trainer.com Art. No.: A009-389_Rev 01 Last edit: KW27/2024 For declaration of conformity visit www.thera-trainer.com...
