StarTech.com 145B-USBC-HDMI4K-AOC Quick Start Manual

USB-C to HDMI 2.0b Optical Adapter Cable - HDR - 4K 60Hz
Product ID
145B-USBC-HDMI4K-AOC
146B-USBC-HDMI4K-AOC
1
3
Component
1 USB-C Connector
2 HDMI Connector
3 USB Power Cable
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Function
Connect to a USB-C Source Device
•
USB-C Source Device must support DP Alt
•
Mode
Connect to an HDMI Display
•
Connect to an available USB Port or USB Wall
•
Charger
Product Information
For the latest technical specifications and declarations of conformance, please visit:
www.StarTech.com/145B-USBC-HDMI4K-AOC
www.StarTech.com/146B-USBC-HDMI4K-AOC
Requirements
2
USB-C DP Alt Mode Source Device x 1
•
HDMI Display Device x 1
•
USB Port or USB Wall Charger x 1
•
Package Contents
USB-C to HDMI Cable x 1
•
Quick-Start Guide x 1
•
Installation
Installing the USB-C to HDMI Cable
Connect the HDMI Connector of the Cable to an available HDMI Input Port on the
1.
Display.
Connect the attached USB Power Cable, located on the HDMI End of the Cable, to
2.
an available USB Port or USB Wall Charger.
Connect the USB-C Connector of the Cable to an available USB-C Port on the Host
3.
Device.
Note: The Host Device's USB-C Port must support DP Alt Mode.
Quick-Start Guide
Manual Revision: July 12, 2023 9:23 AM
