Page 1
VI-H460W Network Indoor Station User Manual...
Page 2
● Products described in this Document, which may include licenses obtained from third parties. Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part ● of this Document may be excerpted, copied, translated, or modified in whole or in part by any means without written permission.
Page 3
VI-H460W Network Indoor Station User Manual PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY ● RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS;...
Page 4
VI-H460W Network Indoor Station User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...
Page 5
VI-H460W Network Indoor Station User Manual Regulatory Information EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, RE Directive 2014/53/EU,the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
Page 6
VI-H460W Network Indoor Station User Manual Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...
VI-H460W Network Indoor Station User Manual Contents Chapter 1 Activation ........................1 1.1 Activate Indoor Station ......................1 1.2 Activate via Guarding Vision ....................2 Chapter 2 Configuration on Device ..................... 3 2.1 Quick Operation (For Normal Device) ..................3 2.2 Basic Settings .........................
Page 8
VI-H460W Network Indoor Station User Manual 2.8 Output Settings ........................29 2.9 Device Information ......................30 Chapter 3 Other Operations on Device ..................31 3.1 Leave Message ........................31 3.2 Call Settings .......................... 31 3.2.1 Add Contact ........................ 31 3.2.2 Call Resident ....................... 32 3.2.3 Call Indoor Extension/Indoor Station ................
Page 9
VI-H460W Network Indoor Station User Manual 4.5 Receive Call from Indoor Station/Door Station ..............65 4.6 View Live Video of Door Station and Outer Door Station ............ 66 4.7 View Call Logs ........................67 4.8 Release Notice ........................67 4.9 Search Video Intercom Information ..................70 4.9.1 Search Call Logs ......................
VI-H460W Network Indoor Station User Manual Chapter 1 Activation 1.1 Activate Indoor Station You can configure and operate the indoor station after creating a password for the device activation. Steps 1. Power on the device. It will enter the activation page. Figure 1-1 Activation Page 2.
VI-H460W Network Indoor Station User Manual 1.2 Activate via Guarding Vision You can only configure and operate the indoor station after creating a password for the device activation. Before You Start Default parameters of indoor station are as follows: Default IP Address: 192.0.0.64. ●...
VI-H460W Network Indoor Station User Manual Chapter 2 Configuration on Device 2.1 Quick Operation (For Normal Device) After device activation, the wizard page will pop up. The description is for other indoor stations. Steps 1. Choose language and tap Next. Figure 2-1 Language Settings 2.
Page 13
VI-H460W Network Indoor Station User Manual Figure 2-2 Password Reset Methods 3. Set network parameters and tap Next. - Edit Local IP, Subnet Mask and Gateway parameters manually. - Enable Auto Get IP address, the device will get network parameters automatically. Figure 2-3 Network Parameters...
Page 14
VI-H460W Network Indoor Station User Manual 4. Configure the indoor station. 1) Select Device Type as Indoor Station or Indoor Extension. 2) Set Floor No.. 3) Set Room No.. 4) Configure advanced settings. Set Comminity No., Building No. and Unit No. 5) Set Registration Password.
Page 15
VI-H460W Network Indoor Station User Manual Figure 2-5 Wi-Fi 6. Set time and tap Next. 1) Select the Time Zone. 2) Tap Date Format and Time Format to set the time format. 3) Tap Time to set time manually. 4) Enable DST.Set the DST start time, end time and bias time.
Page 16
VI-H460W Network Indoor Station User Manual Figure 2-6 Time Settings 7. Configure the Hik-Connect service settings. 1) Enable Hik-Connect service. 2) Edit verification code or use the activation password by default. 3) View Hik-Connect Server Status. 4) Scan the first QR Code to download the APP of Hik-Connect. Scan the second QR Code to add your device to the APP.
Page 17
VI-H460W Network Indoor Station User Manual Figure 2-7 Guarding Vision Service Settings 8. Link related devices and tap Next. If the device and the indoor station are in the same LAN, the device will be displayed in the list. Tap the device or enter the serial No. to link. Figure 2-8 Related Device 1) Tap the door station in the list to link.
VI-H460W Network Indoor Station User Manual Note If the door station is inactive, the system will pop up the dialog to activate the door station. 2) Edit the network parameters of the door station manually. 3) Tap Next. 9. Optional: Enable Indoor Station and link related indoor extension devices. Tap Finish. If the indoor extension and the indoor station are in the same LAN, the device will be displayed in the list.
VI-H460W Network Indoor Station User Manual 2.2.1 Set Indoor Station Network Parameters Network connection is mandatory for the use of the indoor station. Set the network parameters after activating the indoor station. Only when the IP address of the indoor station is in the same network segment as other devices, it can work properly in the same system.
VI-H460W Network Indoor Station User Manual 2.2.2 Set Linked Device IP Linked network parameters refers to the network parameters of devices (like door station, doorphone, main station, center, etc.), to which the indoor station is linked. Linked devices for the indoor station refers to door station, center, main station, and doorphone.
VI-H460W Network Indoor Station User Manual 3. Select a device to link. Edit the following parameters. Name You can edit the name of the device. Language Select a language from the drop-down list for the device. Network Enable Auto Get IP Address and the system will assign IP address, subnet mask, and gateway automatically.
VI-H460W Network Indoor Station User Manual Tap Settings → to enter the Wi-Fi Settings page. Enable Wi-Fi. Select a Wi-Fi from the list and enter the password of the Wi-Fi, and the indoor station can connect to the Wi-Fi. Figure 2-13 Wi-Fi Settings 2.2.4 Set Indoor Station No.
Page 23
VI-H460W Network Indoor Station User Manual Figure 2-14 Set Indoor Station No. 2. Select Indoor Station to set the room information, live view duration, SIP parameters and password. Room Information You can set room name, floor No., and room No. Tap Advanced Settings to set community No., building No.
VI-H460W Network Indoor Station User Manual Room Information You can set room name and No. Tap Advanced to set the community No., building No., and unit No. if you need. When calling the indoor station and the two devices are in the same building, you can call the room No.
VI-H460W Network Indoor Station User Manual 3. Set SIP registration password. 1) Tap Registration Password. 2) Create a new SIP registration password and confirm the password. 3) Tap OK. 4. Optional: Enable Compatible with SIP 1.0 Indoor Station and the indoor station (SIP 2.0) can be compatible with SIP 1.0 indoor station.
VI-H460W Network Indoor Station User Manual Enter the device name, IP address, user name and the password of the camera. Edit port No. and channel No. Exit the page to save the settings. - Select Open Network Video Interface to add the camera. Enter the device name, IP address, user name and the password of the camera.
Page 27
VI-H460W Network Indoor Station User Manual 2. Press a zone to pop up the zone editing dialogue box. 3. Set the zone type, alarm type, status of arming status, entering delay, and exiting delay. 4. Tap OK to save the settings. Note 7 zone types are selectable: Panic Button, Door Magnetic, Smoke Detector, Active Infrared, ●...
VI-H460W Network Indoor Station User Manual Figure 2-18 Arming Mode Settings 3. Arm the selected zone. Note Zones are configurable on the arming mode page. ● 24H alarm zone including smoke detector zone and gas detector zone will be triggered even if ●...
VI-H460W Network Indoor Station User Manual Steps 1. Tap Settings → → Configuration , to enter the Admin Password page. 2. Tap Forgot Password. 3. Download the APP of Guarding Vision and run Guarding Vision client software. 4. Scan the QR code via Guarding Vision. 5.
Page 30
VI-H460W Network Indoor Station User Manual Figure 2-19 Arm/Disarm Password Settings 2. Create the indoor station's arm/disarm password. You should enter the arm/disarm password to enable or disable the function. Figure 2-20 Create Password...
VI-H460W Network Indoor Station User Manual 3. When you slide to disable Scene Password, there is no needs to enter password during scene mode switching. 2.3.4 Modify Unlock/Duress Code You can create and edit the duress code and unlock password of the indoor station. Steps 1.
VI-H460W Network Indoor Station User Manual 2.4 Synchronize Time Steps 1. Tap Settings → → Time and Date to enter the time synchronization page. 2. Tap Date Format and Time Format to set the time format. 3. Optional: Tap Time to set time manually. 4.
VI-H460W Network Indoor Station User Manual 2.5.1 Call Settings You can set the ringtone, ring duration, call forwarding time on call settings page. Steps 1. Tap Settings → to enter the call settings page. Figure 2-23 Call Settings 2. Set corresponding parameters. Ringtone There are 3 ringtones by default, and you can custom and import at most 4 ringtones via Batch Configuration Tool or Guarding Version Client Software.
Page 34
VI-H460W Network Indoor Station User Manual Auto-answer Enable Auto-answer. After enabling, the call from door station/villa door station will be answered by the indoor station automatically. The caller from door station/villa door station can leave voice messages. After the message is left, you can check it from Message on the main page of the device.
VI-H460W Network Indoor Station User Manual Note Indoor extension does not support the ring duration settings, call forwarding settings, or auto- answer function. 2.5.2 Volume Settings Set the microphone volume, prompt sound volume, call volume, and enable touch sound. Steps 1.
VI-H460W Network Indoor Station User Manual 2.6.2 Unlink the Account Remove the account from the mobile client. Steps 1. Tap Settings → → Configuration , and enter the admin (activation) password. 2. Tap to enter the system maintenance page. 3. Tap Unlink App Account, and follow the steps on the page. 2.7 System Settings You can format or install TF card, clear the screen, view the version information of the indoor station and reboot the system on the settings page.
Page 37
VI-H460W Network Indoor Station User Manual Note Make sure your device is connected with the network or the NTP function will not available. ● For details, see Synchronize Time . ● System Language Tap System Language to change the system language. Note The indoor station supports 19 languages.
VI-H460W Network Indoor Station User Manual Tap Restore All to restore all parameters to factory settings and the system will reboot automatically. Wizard Tap Wizard and set the language, network, indoor station type, device No., and select a device according to the wizard. Refers to Quick Operation (For Normal Device) for the details. Preference Tap Settings →...
VI-H460W Network Indoor Station User Manual You can change the relay's name. Note 1 to 32 characters are allowed. Supports uppercase letters, lowercase letters, numerics, and special characters. Remain Open Enable the function, the relay remains open. Disabled the function, and you can set the remain open duration. Note By default, the function is disabled.
VI-H460W Network Indoor Station User Manual Chapter 3 Other Operations on Device 3.1 Leave Message You can set leave message, and view the messages. Tap Settings → → Shortcut Settings , and enable Leave Message. Set Leave Message Time as 1 day, 7 days or 30 days. Tap Message →...
VI-H460W Network Indoor Station User Manual 3. Enter contact information. If you adopt private SIP protocol, enter the contact name and the room No. ● If you adopt standard SIP protocol, enter the contact name and the phone number of VOIP ●...
VI-H460W Network Indoor Station User Manual Note Community No., building No., and unit No. can be omitted if there is no such information. ○ If there are two indoor stations that are in the same building, and should call each other, ○...
VI-H460W Network Indoor Station User Manual Figure 3-3 Call Logs 2. Tap a piece of call logs in the list to call back. Note Indoor extension does not support this function. ● The indoor station saves call logs from door station, outer door station, management center ●...
VI-H460W Network Indoor Station User Manual Figure 3-4 Live View 2. Tap to enter the live view page of door station. Note On the Call from Door Station page, there are 2 unlock buttons: Unlock 1, and Unlock 2. When ●...
VI-H460W Network Indoor Station User Manual 1. Back to the home page, tap Settings → → Scene Settings to enter the arming mode settings page. 2. Tap Stay Mode, Away Mode, Sleeping Mode, or Custom to enter the page. Figure 3-5 Arming Mode Settings 3.
VI-H460W Network Indoor Station User Manual 3.5.1 Arm Room Steps 1. Tap → One-Push to Arm to enable the scene. 2. Tap to enter the scene page. Figure 3-6 Arm Settings page 3. Select Stay, Away, Sleeping or Custom. 4. Enter the arm/disarm password to enable the scene. 5.
VI-H460W Network Indoor Station User Manual Figure 3-7 Disarm Room 2. Enter the arm/disarm password. 3. Tap OK. 3.6 Call Elevator The indoor station supports calling the elevator. Before You Start Enable call elevator via Guarding Vision Client Software. Steps 1.
VI-H460W Network Indoor Station User Manual Figure 3-8 Call Elevator 2. Tap on the home page of the indoor station to start calling the elevator. 3. When the device communicates with door station, tap unlock icon to start calling the elevator. 3.7 Relay Settings After you set the output parameters and display the relay button on the main page, you can control the relay manually.
Page 49
VI-H460W Network Indoor Station User Manual Figure 3-9 Alarm Logs Delete a Log: Hold the item, you can delete it. Clear Logs: Hold the item, you can clear all logs. See Details: Hold a alarm log, you can see the alarm details. Note Indoor extension only supports alarm log and capture log.
VI-H460W Network Indoor Station User Manual Chapter 4 Remote Operation via Client Software 4.1 Device Management Device management includes device activation, adding device, editing device, and deleting device, and so on. After running the Guarding Version, video intercom devices should be added to the client software for remote configuration and management.
Page 51
VI-H460W Network Indoor Station User Manual Figure 4-1 Add the Device 4. Optional: Click Online Device, the active online devices in the same local subnet with the client software will be displayed on the Online Device area.
VI-H460W Network Indoor Station User Manual Note To add online devices to the software, you are required to change the device IP address to the same subnet with your computer first. 1) You can click Refresh Every 60s to refresh the information of the online devices. 2) Select the devices to be added from the list.
VI-H460W Network Indoor Station User Manual Note You should enter the admin password of the device in the Password field of the pop-up window to modify the parameters. 4.2 System Configuration You can configure the video intercom parameters accordingly. Steps 1.
Page 54
VI-H460W Network Indoor Station User Manual Device Information Click Device Information to enter device basic information page. You can view basic information (the device type, and serial No.), and version information of the device. Figure 4-2 Device Information General Click General to enter device general parameters settings page. You can view and edit the device name and device ID, and select overwrite record file.
Page 55
VI-H460W Network Indoor Station User Manual Figure 4-4 Time Settings Page Select Time Zone, Enable NTP, Enable DST, or SDK Synchronization. Click Save to save the time settings. Time Zone: Select a time zone from the drop-down list menu. ● NTP: Click Enable NTP, and enter the server address, NTP port, and synchronization interval.
Page 56
VI-H460W Network Indoor Station User Manual Figure 4-5 System Maintenance Reboot: Click Reboot and the system reboot dialog box pops up. Click Yes to reboot the system. ● Restore Default Settings: Click Restore Default Settings to restore the default parameters. All ●...
Page 57
VI-H460W Network Indoor Station User Manual Note The device supports 19 languages: English, French, Brazilian Portuguese, Spanish, Russian, ○ German, Italian, Polish, Arabic, Turkish, Vietnamese, Ukrainian, Hungarian, Dutch, Romanian, Czech, Bulgarian, Croatian, Serbian. Rebooting the device is required after you change the system language. ○...
Page 58
VI-H460W Network Indoor Station User Manual RS-485 Click RS485 to enter the RS-485 settings page. You can view and edit the RS-485 parameters of the device. Figure 4-7 RS-485 Settings Note For indoor station and main station, there are 3 choices for the working mode: transparent channel, disable, and custom.
VI-H460W Network Indoor Station User Manual Figure 4-8 Security 4.3.2 Video Intercom Click Video Intercom on the remote configuration page to enter the video intercom parameters settings: Time Parameters, Password, Zone Configuration, IP Camera Information, Volume Input and Output Configuration, Ring, Arming Information, Calling Linkage, Relay, and SIP No. Time Parameters Steps 1.
Page 60
VI-H460W Network Indoor Station User Manual Figure 4-9 Time Parameters 2. Configure the calling duration, live view duration, call forwarding time, and the ringtone duration. 3. Click Save. Note Calling duration is the maximum duration of indoor station when it is called without being ●...
Page 61
VI-H460W Network Indoor Station User Manual Figure 4-10 Permission Password For indoor station, you can change the arm/disarm password. Zone Alarm Steps 1. Click Zone Alarm to enter the zone settings page.
Page 62
VI-H460W Network Indoor Station User Manual Figure 4-11 Zone Alarm 2. Select Area No. 3. Select Zone Type from the drop-down list. 4. Select Alarm Type from the drop-down list. 5. Set the NO/NC status. 6. Set Entering Delay and Exiting Delay. 7.
Page 63
VI-H460W Network Indoor Station User Manual When the zone type is set to be 24H Alarm, the indoor station will receive alarm message ● when the detector is triggered no matter it is under arming mode or disarming mode. When the zone type is set to be Delay Alarm, only under arming mode, the indoor station will ●...
Page 64
VI-H460W Network Indoor Station User Manual Figure 4-13 Import Added Device Information Volume Settings Steps 1. Click Volume Input/Output to enter the configuring the volume input or output page.
Page 65
VI-H460W Network Indoor Station User Manual Figure 4-14 Volume Input or Output 2. Slide the slider to adjust the input volume, output volume and speak volume. 3. Click Save to enable the settings. Ring Import Steps 1. Click Ring Import to enter the ring configuration page. Figure 4-15 Ring Import 2.
Page 66
VI-H460W Network Indoor Station User Manual Note The ring to be imported should be in the wav format, and the size of the ring cannot be larger ● than 300k. Up to 4 rings can be added. ● Arming Information Click Arming Information to enter the configuring arming informaton page and view the arming information.
Page 67
VI-H460W Network Indoor Station User Manual Figure 4-17 Extension Settings 2. Click Add.
Page 68
VI-H460W Network Indoor Station User Manual Figure 4-18 Add SIP Info 3. Select Device Type as Indoor Extension.
VI-H460W Network Indoor Station User Manual 4. Enter the required information. Serial No. Enter the device's serial No.. The serial No. is on the rear panel of the device (A fixed-length number with 9 digits). IP Address Enter the device's IP address. Gateway Enter the device's gateway.
Page 70
VI-H460W Network Indoor Station User Manual Figure 4-19 Local Network Configuration 2. Enter the Local IP Address, IP Address Subnet Mask, Gateway, Port No. and HTTP Port No. 3. Click Save to enable the settings. Note The default port No. is 8000. ●...
Page 71
VI-H460W Network Indoor Station User Manual Figure 4-20 SIP Server Configuration 2. Click Enable. 3. Set the parameters according to your needs. Note Up to 32 characters are allowed in the Register User Name field. ● Registration password should be 1 to 16 characters in length. ●...
Page 72
VI-H460W Network Indoor Station User Manual Figure 4-21 DNS Settings Configure Mobile Client Connection Configure Guarding Vision server parameters before viewing videos via mobile client. Before You Start Make sure the indoor station connects to the network. Steps 1. Click Guarding Vision to enter the configuring the settings page. 2.
VI-H460W Network Indoor Station User Manual Figure 4-22 Group Network Settings Device No. Settings Select the device type from the drop-down list, and set the corresponding information. Note Device type can be set as indoor station or indoor extension. ● When you select indoor extension as device type, the device No.
VI-H460W Network Indoor Station User Manual Figure 4-23 Calling Indoor Station 3. After answered, you will enter the In Call window. Click to adjust the volume of the loudspeaker. ● Click Hang Up to hang up. ● Click to adjust the volume of the microphone. ●...
VI-H460W Network Indoor Station User Manual Figure 4-24 Incoming Call from Indoor Station 2. Click Answer to answer the call. Or click Hang Up to decline the call. 3. After you answer the call, you will enter the In Call window. Click to adjust the volume of the loudspeaker.
VI-H460W Network Indoor Station User Manual 4.7 View Call Logs You can check all the call logs, including dialed call logs, received call logs and missed call logs. You can also directly dial via the log list and clear the logs. Steps 1.
Page 77
VI-H460W Network Indoor Station User Manual Figure 4-26 Release Notice 3. Click Add on the left panel to create a new notice.
Page 78
VI-H460W Network Indoor Station User Manual Figure 4-27 Create a Notice 4. Edit the notice on the right panel. 1) Click ... on the Send To field to pop up the Select Resident dialog. 2) Check the checkbox(es) to select the resident(s). Or you can check the All checkbox to select all the added residents.
VI-H460W Network Indoor Station User Manual 5) Click in the Type field to unfold the drop-down list and select the notice type. 6) Optional: Click View to add a local picture to the notice. Note Up to 6 pictures in the JPGE format can be added to one notice. And the maximum size of one picture is 512KB.
Page 80
VI-H460W Network Indoor Station User Manual Figure 4-28 Search Call Logs 3. Set the search conditions, including call status, device type, start time and end time. Call Status Click to unfold the drop-down list and select the call status as Dialed, Received or Missed. Or select All to search logs with all statuses.
VI-H460W Network Indoor Station User Manual 4.9.2 Search Notice Steps 1. On the main page, click Access Control → Video Intercom to enter the Video Intercom page. 2. Click Notice to enter the Notice page. Figure 4-29 Search Notice 3. Set the search conditions, including notice type, subject, recipient, start time and end time. Recipient Input the recipient information in the Recipient field to search the specified notice.
Page 82
VI-H460W Network Indoor Station User Manual 6. You can view and edit the notice details, check the sending failed/sent succeeded/unread users, and resend the notice to sending failed/unread users. 7. Optional: Click Export to export the notices to your PC.
