OZ90DB-24 OZ90DX-24
200cm² Min.
(Hot Air Outlet)
To fix the appliance with Cabinet, pls. screw the 3 screws
(ST4.2*12mm) through the Top Bracket. The Top Bracket is pre-
installed on top of appliance.
200cm² Min.
(Cool Air Inlet)
Top Bracket
.18.
A
8
A
8
Screws
(ST4.2*12mm)
