Temptech SKX6070DRB User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wine Coolers
USER MANUAL
SKX6070DRB
SKX6070DKF
This manual contains important information including safety and
installation instructions of the appliances. Please read it carefully before
use and follow all safety information & instructions. It is recommended
to keep this manual for easy reference so that you can be familiar with the
operation of the appliance.
V1 /2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKX6070DRB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Temptech SKX6070DRB

Summary of Contents for Temptech SKX6070DRB

  • Page 1 Wine Coolers USER MANUAL SKX6070DRB SKX6070DKF This manual contains important information including safety and installation instructions of the appliances. Please read it carefully before use and follow all safety information & instructions. It is recommended to keep this manual for easy reference so that you can be familiar with the operation of the appliance.

  • Page 2: Table Of Contents

    05 SCRAPPING OLD APPLIANCES Conformity Energy Saving Service 06 INSTALLATION SKX6070DKF SKX6070DRB 07 ACCESSORY INSTALLATION BEFORE OPERATING UNPACKING AND CLEANING THE WINE COOLER Adjusting the height and levelling off your wine cabinet 09 BOTTLE LOADING DRAWING SKX6070DRB/DKF 10 OPERATING THE WINE COOLER...
  • Page 3 19 TROUBLESHOOTING 20 WOOD PANEL INSTALLATION 20 WOOD PANEL DIMENSION INSTALL THE PANEL 22 INSTALL REMOVABLE FRONT GRILLE...

  • Page 4: Energy Saving And Ecological Protection

    INSTRUCTION MANUAL • Please removed all packaging, stickers and films from the products surface and clean the product’ s surfaces with a damp cloth and mild deturgent before using for the first time. • Let the appliance stand upright for approximately hours before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation.

  • Page 5: Important Safety Information

    16 °C to 43 °C’; (o) How to find the model information in the product database: Please visit our website https://temptech.no/ to find the instruction about how to find production information in EU database. IMPORTANT SAFETY INFORMATION...
  • Page 6 INSTRUCTION MANUAL We recommend that you follow the following regulations so as to avoid situations dangerous to you: Before performing any operation, unplug the power cord from the power socket. ● The refrigeration system positioned behind and inside the Wine Coolers contains refrigerant.
  • Page 7 INSTRUCTION MANUAL built-in structure, free of obstruction. ● Do not place objects and/or containers filled with water on the top of the appliance. ● Do not perform repairs on this Wine Coolers. All interventions must be performed solely by qualified personnel. ●...

  • Page 8: Scrapping Old Appliances

    INSTRUCTION MANUAL SCRAPPING OLD APPLIANCES This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). WEEE contains both polluting substances (which can cause negative consequences for the environment) and basic components (which can be re-used).

  • Page 9: Service

    INSTRUCTION MANUAL „ Service ● You should not attempt to repair the appliance yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Customer Care Department INSTALLATION he following pictures only show description of appliance. The dimension and shelf quantity may differ among the models of the same series.

  • Page 10: Skx6070Drb

    INSTRUCTION MANUAL „ SKX6070DRB • Height Adjustable: 800-880mm ACCESSORY INSTALLATION BEFORE OPERATING „ UNPACKING AND CLEANING THE WINE COOLER • Remove the exterior and interior packing materials. • 24 hours Let the appliance stand upright for approximately before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation.
  • Page 11 INSTRUCTION MANUAL o The height must be adjusted prior to building the appliance into the housing unit and it should be set at such a height that the top panel of the appliance fits exactly below the kitchen worktop. o Tilt the appliance approximately 60° to allow access to the adjustable feet.

  • Page 12: Bottle Loading Drawing

    INSTRUCTION MANUAL BOTTLE LOADING DRAWING The following pictures only show description of appliance. „ SKX6070DRB/DKF .09.

  • Page 13: Operating The Wine Cooler

    INSTRUCTION MANUAL OPERATING THE WINE COOLER „ WORKING CLIMATE • The appliance is designed for operating from SN to N climate (see below climate class chart). It is recommended to maintain the ambient around 22-25°C which helps the appliance working with low power consumption. Klimaklasse Romtemperatur 10 - 32 °C (50 ºF-90ºF)

  • Page 14: Control Panel In Cabinet

    INSTRUCTION MANUAL Wine Type Recommender Temp. Red Wines 15 - 18ºC (59ºF-64ºF) Dry/White Wines 9 - 14ºC (48ºF-57ºF) Rose Wines 10 - 11ºC (50ºF-52ºF) Sparkling Wines 5 - 8ºC (41ºF-46ºF) CONTROL PANEL IN CABINET „ Dual zone control panel A. Power B.

  • Page 15: Temperature Setting

    INSTRUCTION MANUAL Under the locked condition, the control panel will not react to any touching order for Lighting On/Off and Temperature Setting. „ TEMPERATURE SETTING • The default temperature setting ranges for dual zone are : 5-12 ºC (41-54 ºF ) for the upper zone and 12-20 ºC (54-68 ºF ) for the bottom zone.

  • Page 16: Interior Lighting Color Choose

    INSTRUCTION MANUAL lights on/off. • Note: each light mode is independent. „ INTERIOR LIGHTING COLOR CHOOSE • Under the unlocked condition, press the lightnning mark and holds for 3 seconds to enter the light color choose, press temp plus or temp minus key to choose the light color between "A"...

  • Page 17: Demo Mode

    INSTRUCTION MANUAL „ DEMO MODE For Dual Zone • Under the unlocked condition, press the lightning and zone select mark together and holds for 3 seconds to enter/exit the demo mode. • Under the demo mode, the icon will light up. The compressor, fans and heaters will be stopped, only light is working.

  • Page 18: Error Code

    INSTRUCTION MANUAL „ ERROR CODE For Dual Zone .15.

  • Page 19: Care And Maintenance

    INSTRUCTION MANUAL CARE AND MAINTENANCE „ CLEANING THE WINE COOLER • Turn off the power, unplug the appliance, and remove all items including shelves. • Wipe the inside surfaces with a sponge and baking soda solution. The solution should be about 2 tablespoons of baking soda to 1 quart (approx. 1 litre) of warm water. •...

  • Page 20: Defrosting

    INSTRUCTION MANUAL Removing the Carbon Filter: o Hold the Carbon Filter and turn it 90° to the left or right to Remove it; Reinstalling the Carbon Filter: o Hold the Carbon Filter and turn it 90° to the left or right until it clicks into place.

  • Page 21: Vacation Time

    INSTRUCTION MANUAL temperature rise. IMPORTANT: If the appliance is unplugged, the power is lost or turned off you must wait 5 minutes before restarting the Wine Cooler. If you attempt to restart before this time delay, the compressor could be damaged. „...

  • Page 22: Troubleshooting

    INSTRUCTION MANUAL TROUBLESHOOTING If you feel the appliance is not working properly, follow these instructions to try to see if you can solve the problem simply by yourself before calling for service. PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Not plugged in. The wine cooler does not operate The appliance is turned off.

  • Page 23: Wood Panel Installation

    INSTRUCTION MANUAL WOOD PANEL INSTALLATION „ WOOD PANEL DIMENSION • Please cut the wood panel oexactly the same as below drawing „ INSTALL THE PANEL • Remove the gasket from the door .20.
  • Page 24 INSTRUCTION MANUAL • RInstall the 4 side screws in half • Hang the wood panel on the door, and move it up or down to its correct position. • Fasten tight the top and bottom screws. .21.

  • Page 25: Install Removable Front Grille

    INSTRUCTION MANUAL • Install back the gasket. INSTALL REMOVABLE FRONT GRILLE The plinth/grille for this appliance comes packaged inside and can be fitted if desired Follow these steps to do so: 1. Locate the plinth (packaged inside the appliance) 2. Remove the four screws from (two on each side of ) the plinth section, but take care to support both sections to prevent the adjustable section from falling away.
  • Page 26 INSTRUCTION MANUAL will help to secure the plinth to the underside of the wine cooler. 8. Adjust the wine cooler feet so that you achieve the desired height for the cooler. If needed, re-attach the extendable plinth section with the four screws that were removed in step 2.
  • Page 27 INSTRUCTION MANUAL --END-- .24.

This manual is also suitable for:

Skx6070dkf
