USER MANUAL
This manual contains important information including safety and
installation instructions of the appliances. Please read it carefully before
use and follow all safety information & instructions. It is recommended
to keep this manual for easy reference so that you can be familiar with the
operation of the appliance.
V1/2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the STHLM STX60DRB-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Temptech STHLM STX60DRB-24

Summary of Contents for Temptech STHLM STX60DRB-24

  • Page 1 Wine Coolers USER MANUAL This manual contains important information including safety and installation instructions of the appliances. Please read it carefully before use and follow all safety information & instructions. It is recommended to keep this manual for easy reference so that you can be familiar with the operation of the appliance.
  • Page 2 --CONTENTS-- 01 ENERGY SAVING AND ECOLOGICAL PROTECTION 03 IMPORTANT SAFETY INFORMATION 05 SCRAPPING OLD APPLIANCES Conformity Energy Saving Service 07 DESCRIPTION OF APPLIANCE AND INSTALLATION STX30DRB-24 STQ38DRB-24 STX60DRB-24 ST2DX60DRB-24 For Sealed Kitchen ST120DRB-24 ST180DRB-24 Many Big Wine Coolers Stand Together 11 ACCESSORY INSTALLATION BEFORE OPERATING UNPACKING AND CLEANING THE WINE COOLER Adjusting the height and levelling off your wine cabinet...
  • Page 3 25 REVERSE THE DOOR SWING UNDERCOUNTER WINE COOLER ST120DRB-24/ ST180DRB-24 31 INSTALL REMOVABLE FRONT GRILLE 31 Includes models STX30DRB-24, , ST2DX60DRB-24, , STX60DRB-24 32 DOWNLOAD OTHER LANGUAGE USER MANAL...
  • Page 4 INSTRUCTION MANUAL Please removed all packaging, stickers and films from the products surface and clean the product’ s surfaces with a damp cloth and mild deturgent before using for the first time. • Let the appliance stand upright for approximately hours before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation.
  • Page 5 - Tropical: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging from 16 °C to 43 °C’; (o) How to find the model information in the product database: Please visit our website https://temptech.no/ to find the instruction about how to find production information in EU database. .02.
  • Page 6 INSTRUCTION MANUAL IMPORTANT SAFETY INFORMATION This appliance uses flammable refrigerants and flammable insulation blowing gases. Before using the appliance, please properly position and install it as described in this manual. To avoid the risk of fire, electrical shock, or injury when using the appliance, follow these basic precautions: ●...
  • Page 7 INSTRUCTION MANUAL You may adjust the appliance’s feet to level it. ● A wine cabinet CAN NOT be placed over an oven/heat drawer or equal other heat producing products due to heat exposure. If placed nearby a heat producing product, then place the wine cabinet under this unit. ●...
  • Page 8 INSTRUCTION MANUAL ● This appliance is intended to be used in household and similar applications such as: 1.staff kitchen areas in shops, offices and other working environments; 2. farmhouses and by clients in hotels, motels and other residential type environments; 3.bed and breakfast type environments;...
  • Page 9 INSTRUCTION MANUAL Individuals can play an important role in ensuring that WEEE does not become an environmental issue; it is essential to follow some basic rules: --WEEE should not be treated as household waste; --WEEE should be handed over to the relevant collection points managed by the municipality or by registered companies.
  • Page 10 INSTRUCTION MANUAL DESCRIPTION OF APPLIANCE AND INSTALLATION The following pictures only show description of appliance. The dimension and shelf quantity may differ among the models of the same series. „ STX30DRB-24 • Height Adjustable: 815-850mm „ STQ38DRB-24 • Height Adjustable: 853-878mm .07.
  • Page 11 INSTRUCTION MANUAL „ STX60DRB-24 • Height Adjustable: 815-850mm „ ST2DX60DRB-24 • Height Adjustable: 815-850mm .08.
  • Page 12 INSTRUCTION MANUAL „ For Sealed Kitchen Notes:If you would like to install the wine cabinet in a place where the kitchen cabinet is entirely close,there should be a ventilation grill on the top of the kitchen cabinet for ventilation „ ST120DRB-24 .09.
  • Page 13 INSTRUCTION MANUAL „ ST180DRB-24 „ Many Big Wine Coolers Stand Together .10.
  • Page 14 INSTRUCTION MANUAL ACCESSORY INSTALLATION BEFORE OPERATING „ UNPACKING AND CLEANING THE WINE COOLER • Remove the exterior and interior packing materials. • 24 hours Let the appliance stand upright for approximately before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation.
  • Page 15 INSTRUCTION MANUAL „ Installing The Handle Gasket Handle Washer Handle Screws Remove the door Gasket slightly to expose the two screw holes. ● Fix the Handle by screwing the two Handle Screws tightly, the Handle Screws ● with Washers are pre-installed inside the screw holes, pls.do not unscrew the Handle Screws too much in case the Washers fell off.
  • Page 16 INSTRUCTION MANUAL extreme cold or hot conditions may cause interior temperatures to fluctuate, and the temperature set 5-20°C may not be reached sometimes. „ WINE STORAGE • The standard shelves are designed perfectly for Bordeaux bottle storage. The maximum loaded bottles may vary subject to the different size or dimension wine bottles you store.
  • Page 17 INSTRUCTION MANUAL „ CONTROL PANEL • For Dual Zone Includes STX30DRB-24, , STQ38DRB-24, , STX60DRB-24, -24, ST120DRB-24, -24, ST180DRB-24 and Upper Zone A. Power B. Lighting D. Temp. Plus E. Temp.Minus Display Window Lock/ Function Function G. ºC/ºF Lower Zone K.
  • Page 18 INSTRUCTION MANUAL „ POWER ON/OFF CONTROL For models STX30DRB-24, , STQ38DRB-24, , STX60DRB-24, -24, ST120DRB-24, -24, ST180DRB-24 and • When the appliance is plugged in to a power outlet, it powers on automatically. • Touch the power mark and hold for 10 seconds to turn off (or turn on) the appliance.
  • Page 19 INSTRUCTION MANUAL • Under the locked condition, the control panel will not react to any touching order for Lighting On/Off and Temperature Setting. „ INTERIOR LIGHTING ON/OFF CONTROL • Under the unlocked condition, touch the lighting mark to turn on (or turn off ) the interior cool LED lighting.
  • Page 20 INSTRUCTION MANUAL For ST2DX60DRB-24 • The default temperature setting range is : 5-20 ºC (41-68 ºF ) for both zone • to increase the set temperature by 1 ºC (or by 1ºF) . On the Touch the mark to decrease the set temperature by 1 ºC (or by 1ºF) . contrary, touch the mark „...
  • Page 21 INSTRUCTION MANUAL „ LIGHTING ON/OFF BUTTONS BACKLIT AND DISPLAY WINDOW o All buttons backlit will light on when plugged; o All buttons backlit except the Power button will light off automatically if no more touching on the Control Panel within 15 seconds from the final operation; o If the Display Window is set to Power Saving Mode, the window will be light off automatically if no more touching on the Control Panel within 60 seconds from the final operation;...
  • Page 22 INSTRUCTION MANUAL CARE AND MAINTENANCE „ CLEANING THE WINE COOLER • Clean regularly surfaces of the wine coolerto avoid contamination of wines. • Turn off the power, unplug the appliance, and remove all items including shelves. • Wipe the inside surfaces with a sponge and baking soda solution. The solution should be about 2 tablespoons of baking soda to 1 quart (approx.
  • Page 23 INSTRUCTION MANUAL Stopper Locating Pin „ Carbon Filter Change (Option) A good ambient air quality is important for wine maturing. The Carbon Filter is very helpful to absorb odor and improve air quality.For the models with Carbon Filter, we suggest to replace it once a year.Pls.contact your dealer to get the filter.
  • Page 24 INSTRUCTION MANUAL o Remove all items from the Wine Cooler. o Securely tape down all loose items such as the shelves inside of the appliance. o Turn the adjustable foot up to the base to avoid damage. o Tape the door closed. o Ensure the appliance stays secure in the upright position during transportation.
  • Page 25 INSTRUCTION MANUAL For STX30DRB-24, STQ38DRB-24, STX60DRB-24 and ST180DRB-24 o Under unlock condition, touch lighting + zone select keys for 5 seconds,and with a bee sound to enter the demo mode: o The compressor, heater, fan won’t work, only light and display is working o All alarm will be invalid o C/F indicator is flashing For ST2DX60DRB-24...
  • Page 26 INSTRUCTION MANUAL TROUBLESHOOTING If you feel the appliance is not working properly, follow these instructions to try to see if you can solve the problem simply by yourself before calling for service. PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Not plugged in. The wine cooler does not operate The appliance is turned off.
  • Page 27 INSTRUCTION MANUAL REVERSE THE DOOR SWING Remarks: The following operations are available for a model with control in cabinet only and ● with Right Door Hinge installed. All removed parts must be saved in order to do the door reinstallation. ●...
  • Page 28 INSTRUCTION MANUAL Unscrew the Upper Right Hinge and Bottom Right Hinge from the cabinet. Keep them well for door re-installation. Upper Right Hinge Bottom Right Hinge Pull out the 6 Plastic Caps at the front left corner of the cabinet. And move them all to the right side.
  • Page 29 INSTRUCTION MANUAL For a unit without lock, please turn the door by 180° (upside down). For a unit with lock, keep the door upright and remove the lock hold cover from top to bottom, then turn the door by 180° (upside down). Insert the Pivot Hinge into the bottom hinge hole of the door.
  • Page 30 INSTRUCTION MANUAL Install the door to the left hinge side by tightening the Pivot Hinge with the 2 screws. Bottom Left Hinge Pivot Hinge Screws (2pcs) „ ST120DRB-24/ ST180DRB-24 IMPORTANT INFORMATION We recommend that you secure the racks in place using adhesive tape to prevent causing damage when handling the appliance and store all removed parts carefully.
  • Page 31 INSTRUCTION MANUAL Remove the Bottom Hinge Cover by prying it off gently with small flat screwdriver. Remove the Bottom Hinge by unscrewing the Hex Head Screw (4pcs). Unscrew the Pan Head Screw (4pcs) from bottom left side. Now move the Bottom Hinge to the bottom left side and screw it tightly with the Hex Head Screws (4pcs).
  • Page 32 INSTRUCTION MANUAL Hold the Door carefully with your assistant and place it on the top of Bottom Hinge , make sure the Pivot Hinge is at correct place through the Hinge Washer. Insert the pin of the Upper Hinge into the Bushing on the top right and fix it with Hex Head Screw (4pcs). Cover the Upper Hinge and Bottom Hinge with Upper Hinge Cover and Bottom Hinge Cover.
  • Page 33 INSTRUCTION MANUAL INSTALL REMOVABLE FRONT GRILLE Includes models STX30DRB-24, , ST2DX60DRB-24, , STX60DRB-24 The Front Grille is packed as accessary, pls.unpack and remove it from cabinet inside. Place the unit on a soft and flat floor, lay it down to a suitable angle; Fig.
  • Page 34 Front Grille. DOWNLOAD OTHER LANGUAGE USER MANAL You can find Norwegian, Swedish, Finnish and Danish user manual from below website. You can download Norwegian user manual at https://temptech.no/manualer-og- installasjon/ You can download Swedish user manual at https://temptech.se/manualar-och- installation You can download Finnish user manua at https://temptech.fi/kayttoohjeet-ja-...
