ADJUSTING THE LEG LENGTH
The length of each leg section of the Hummingbird tripod
can be adjusted. To adjust the length of a leg section,
release the leg lock lever and extend the leg section to the
Leg
desired height. Press the leg lock lever back into position
lock levers
to secure it. Repeat the process for all leg sections. The
legs will extend to a maximum of four sections.
ADJUSTING THE LEG ANGLE
The legs of the Hummingbird tripod can be set at two different fixed angles as well as a fully
expanded position for laying flat on a surface. To change the angle, slightly push the leg in towards
the center column and pull out the leg angle adjustment latch. Pivot the leg outward until it reaches
the end of its travel to obtain the widest angle setting.
