Table 11.1 Main Use Display Content Options
Content
Separator
Dial
Setpoint Readout
Setpoint Bar
Sensor Bar
Shortcut
Alarms
Event Log
Run Hours
EconoPhase Diagram
EconoPhase Status

11.2.4 Removing Content

You can easily remove content from the main display.
1. Touch
2. Touch
3. Touch an object to select it (highlighted green), then touch

11.3 Customizing Parameter and Field Labels

You can customize header labels for parameters in the menus and you can customize field names.
NOTE: You can export labels for back up or to use a text editor to customize the labels. See
Text Editor on page 100
1. Before going to the customization panel, use the search box and on-screen keyboard to find the label(s) that you want to customize. Once
you know where they are, you'll be able to find them in the categories on the Customize Labels panel.
2. Touch
into categories that represent the names of menus, sub-menus, and screen panels.
3. Locate the category that contains the label(s) to customize that you determined in step 1 , and touch to expand it.
98
Description
Separating line to place between content sections. You can adjust the thickness and orientation of the separator.
Status dial. You can select the sensor readings displayed in the center of the status dial when you touch to scroll through
the readings.
Displays the current reading of a connected sensor, for example: return temperature at 72°F.
Displays a bar graph for a selected setpoint with customizable empty and full limits. For example, if a temperature
setpoint bar is empty at 60°F and full at 80°F, and the reading is 70°, the graph will be filled half way.
For remote sensors only, functions the same as the setpoint bar, but only offers connected remote sensors, and displays
the customer assigned name of the sensor next to the graph.
Shortcut opens panels directly instead of browsing through menus. You can select the destination of the shortcut,
whether or not an icon displays, and the size, label, and frame of the shortcut.
Alarms panel. You can select whether or not the information may be exported.
Event log panel. You can select whether or not the information may be exported.
Run hours panel. Summary of the component run hours and limits.
EconoPhase operating diagram.
Compressor/Econophase status bar. Indicates the operating mode and the percentage at which the component is
operating.
, then .
in the upper-right corner of the display and just below the control header.
.
, then > Display Options > Custom Labels. The CUSTOM LABELS panel opens. The labels are divided
