Pump N Speed
Current pump speed, where N is the pump number.
Pump N Test Results
Results of board test, where N is the pump number.

10.7 Diagnosing Digital Output Issues

1. Touch
panel displays.
2. Refer to Diagnosing Digital Output Issues
NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may
not be available on your Vertiv™ Liebert® iCOM™ display.
10.7.1 Diagnostics—Digital Output Options
Alarm Relay
Enables/disables alarms during manual/diagnostic mode.
K11 Relay
Enables/disables warnings during manual/diagnostic mode.

10.8 Diagnosing Analog Output Issues

1. Touch
panel displays.
2. Refer to Diagnostics—Analog Output Options
NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may
not be available on your Vertiv™ Liebert® iCOM™ display.
10.8.1 Diagnostics—Analog Output Options
Analog Output N (Where N is the analog output number)
Controls analog outputs during manual/diagnostic mode.
Analog Output N Setting (Where N is the analog output number)
Use the slide control to modify the output for the output setting. Values range from 0% to 100%.
10 Performing Diagnostics
, then > Diagnostic/Service > Diagnostics > Digital Outputs in the Category list. The DIGITAL OUTPUTS
above for descriptions of diagnostic options.
, then > Diagnostic/Service > Diagnostics > Analog Outputs in the Category list. The ANALOG OUTPUTS
below , for descriptions of diagnostic options.
