Specifications
Product Name
Network Attached Storage
Operating System
UGOS Pro
Processor
Intel 8505 5-Core
Max Turbo Frequency
4.40GHz
Memory Types
SODIMM DDR5
Memory Capacity
8GB/64GB (max memory size)
System Storage
SSD 128GB
Internal: ext4/Btrfs
External: Btrfs/ext2/ext3/ext4/VFAT/exFAT/FAT16/FAT32/NTFS/XFS
File System
Internal non-"UGREEN NAS" storage pool:
Btrfs/ext2/ext3/ext4/VFAT/exFAT/FAT16/FAT32/NTFS/XFS
Storage Mode
JBOD/Basic/RAID 0/RAID 1/RAID 5/RAID 6/RAID 10
4×2.5-inch/3.5-inch SATA hard drive
Supported Drive
2×M.2 NVMe 2280 SSD
Video Port
1×HDMI, Up to 4K
1×2.5GbE
Support 10Mbps/100Mbps/1000Mbps/2.5Gbps auto-negotiation
RJ45 Ethernet Port
1×10GbE
Supports 10M/100M/1000M/2.5Gbps/5Gbps/10Gbps auto-negotiation
1×USB 3.2 Gen 2, supports theoretical transfer rate of up to 10Gbps
1×Type-C USB 3.2 Gen 2, supports theoretical transfer rate of up to 10Gbps
USB Port
1×USB 3.2 Gen 1, supports theoretical transfer rate of up to 5Gbps
2×USB 2.0, supports theoretical transfer rate of up to 480Mbps
SD Card Slots
1×SD 3.0, supports theoretical transfer rate of up to 104MB/s
Power Source Specification
DC 19V/7.9A
Phone: Android 7.0/iOS 15 or later
Compatible Systems
Computer: Windows 7 SP2 or later/macOS High Sierra 10.13.6 or later
Working Environment
Temperature: 0℃~40℃/32℉~104℉
Product Dimensions
L257.5×W178×H178 (mm)/L10.1×W7.0×H7.0 (inch)
Humidity: 5% to 95%
