Summary of Contents for The Splash Lab The Ribbon Sink TSL.NANO.R

  • Page 1 The Ribbon Sink TSL.NANO.R...
  • Page 2: Table Of Contents

    contents The Ribbon Sink Components List Technical Data Before you Install 8-10 Installation Operation & Maintenance Cleaning & Repairs Damage Prevention Warranty THE RIBBON SINK MANUAL...
  • Page 3: The Ribbon Sink

    The Ribbon Sink The Ribbon Sink The Splash Lab Ribbon Sink is a small and compact single-user basin, constructed from solid surface material, well suited to any washroom. THE RIBBON SINK MANUAL...
  • Page 4: Components List

    Fixing nuts Washers (M6) Please check that all components are included and contact The Splash Lab if any parts are missing. Wall attachment hardware is not included for fastening the brackets to the wall as the requirements of each location is different. The Splash Lab recommends that you consult a licensed contractor for the most appropriate method for your project.
  • Page 5: Technical Data

    The Ribbon Sink technical data 30” Material Solid Surface Weight (lb) 40.5 Overall Dimensions (in) 30" x 20" x 5" Waste Connections P-Trap to be installed by licensed plumber. THE RIBBON SINK MANUAL...
  • Page 6: Before You Install

    The Ribbon Sink before you install Metal or wood studs need to be capable of supporting the weight of the sink. See the table on page 18 for stud spacing. Allow a space of at least 3 1/2" - 4" behind the wall for easy access to plumbing connections.
  • Page 7 The Ribbon Sink before you install THE RIBBON SINK MANUAL...
  • Page 8: Installation

    The Ribbon Sink installation Mark the bracket attachment points on the wall. Drill where marked for attachment. POINT B POINT A POINT C Attach the bracket through point A first and then, Ensure the bracket is level along its length so that with sink level through point B the water properly drains out of the trough.
  • Page 9 The Ribbon Sink installation With the Ribbon Sink placed face-down, fit the Place the Ribbon Sink over the front of the waste funnel to the funnel adapter plate on the mounting tabs onto the wall brackets. underside of the basin. Ensure that the sealing gasket is correctly fitted into the recess on the funnel and tighten the 4 bolts.
  • Page 10 The Ribbon Sink installation Plumber to fit P-Trap to drain funnel and connect to waste pipe previously installed. THE RIBBON SINK MANUAL...
  • Page 11 operation The user will activate an automatic sensor faucet or a manual faucet, allowing the water to flow and wash their hands in the normal manner. maintenance The Ribbon Sink should be periodically inspected for any damage. The Ribbon Sink should be tested to ensure that the water drains out of the basin, and that the drainage waterways are not blocked with any debris.
  • Page 12 The Splash Lab Ribbon sinks are finished in a matte / satin finish, unless otherwise specified. The surface can be cleaned with a mild solution of soapy water, ammonia-based cleaners or most commercially available solid-surface cleaners. These will remove most dirt and other residue from the surface.
  • Page 13: Damage Prevention

    Some chemicals are not compatible with The Splash Lab solid surface. Contact should be avoided with the following chemicals: Strong chlorinated solvents Chloroform Ketones Methylene chloride (paint removers) Very strong acids such as concentrated sulphuric and hydrochloric acids Acid drain cleaners should not be used.
  • Page 14: Warranty

    The Splash lab will replace necessary parts, free of charge, if they are defective from the manufacturer. The Splash Lab guarantees all of its products against manufacturing defects under the terms and conditions listed below Sinks TSL backs every sink with a lifetime guarantee against material defect.
  • Page 15 contact General information info.usa@thesplashlab.com 310 410 5008 20809 Higgins Ct Torrance, CA 90501 Technical support info.usa@thesplashlab.com For further information visit: www.thesplashlab.com/usa...
