Summary of Contents for The Splash Lab TSLP.120045
- Page 1 Thermostatic Mixing Valve TSLP.120045...
- Page 2 Damage prevention Warranty Thermostatic Mixing Valve TSLP.120045 The Thermostatic Mixing Valve (TMV) is designed for use with TSL’s full range of faucets to provide mixed hot and cold water for a pleasant hand-washing temperature. The valve prevents the flow of water discharging from the mixed water outlet in the event of the failure of hot or cold supply, thus protecting the user from the danger of scalding.
- Page 3 Temperature gauge attachment point Water Act, certified by ICC-ES,files PMG-1360 Lower spring Please check that all components are included and advise The Splash Lab if any parts are missing. 4 + THERMOSTATIC MIXING VALVE MANUAL 5 + THERMOSTATIC MIXING VALVE MANUAL...
- Page 4 before you install before you install Read and save these instructions WARNING + This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
- Page 5 how to install how to install Connect the hot water inlet to the male inlet Connect the cold water inlet to the male inlet port marked “H.” port marked “C.” Use the temperature adjustment cap to Do another step but what is it. calibrate the hot to cold flow ratio to desired water temperature.
- Page 6 + Debris obstructing valve operation; clean debris or scale from valve internals Should the valves still not function correctly, it or its constituent parts may need replacing. Please contact The Splash Lab at info.usa@thesplashlab.com for assistance. Valve does not shut off when tested Spare parts available upon request.
- Page 7 Thermostatic Mixing Valve 1 year limited warranty If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replace- ment part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty.
