Summary of Contents for The Splash Lab L-180 Series

  • Page 1 L-180 Series Wall Mounted Sensor Tap...
  • Page 2: Table Of Contents

    contents Box contents Exploded view Technical Data Before you install 7 - 9 How to install 10 - 11 Resetting the sensor 12 - 14 Changing + Cleaning Solenoid Valve 15 - 16 Settings adjustment - remote General Cleaning 18 - 19 Trouble shooting Warranty Warranty Info...
  • Page 3: Box Contents

    box contents L-180 Head Power Supply Solenoid Wall Rosette Fixing Nut Washer Solenoid Filter Solenoid Adapter Hex Key 3 + L-180 Walll Mounted Sensor Tap...
  • Page 4 4 + L-180 Wall Mounted Sensor Tap...
  • Page 5: Technical Data

    technical data Mains power supply 110 - 240 V, IP68 Battery power supply 9V (6 x 1.5V AA), IP67 Fuse 3A fused spur to be connected to power supply transformer. Pre-set sensor range 120mm Minimum sensor range 80mm Maximum sensor range 200mm Security time 90 seconds...
  • Page 6: Before You Install

    3.5m m Flow Rates 14.4mm Different flow rates may need to be achieved. The Splash Lab offeres number of flow regula- Ø 23-27m m tors (See page 5 and 23) which can be used in conjunction with L-180 tap system.
  • Page 7: How To Install

    how to install Assemble the wall rosette (D) to the base of the tap (A). Insert the flexible hose, the cable and the base of the tap through a 23-27mm hole in the wall. Ensure the anti rotation pin is inserted in to the 3.5mm hole so that the tap spout is an- gled pointing in the required...
  • Page 8 Ensure the filter (G) and sole- noid adapter (H) are assem- bled to the solenoid inlet with the filter between the adapter and the solenoid inlet Connect the solenoid to the mains water supply. Turn on the water supply and check for any leaks Before powering on the sys- tem remove the sensor pro-...
  • Page 9 Connect the male connector from the tap to the battery pack or transformer box de- pendant on your power sup- ply type. If you have a trans- former box supply, connect this to the main power supply and turn on the power. Wait 5 seconds before acti- vating the tap sensor to avoid entering the sensor range...
  • Page 10: Resetting The Sensor

    resetting the sensor Firstly shut off the water supply, Dis- connect the power supply, battery or transformer, from the sensor. Activate the sensor 3-4 times while the power is off. Alternatively, while the power is off make a short circuit between POWER SUPPLY the positive and negative pins of the sensor connector using a suitable...
  • Page 11 Changing the batteries When the battery weakens the red indicator light inside the sensor will blink at a constant rate when the us- ers hands are within the sensor range. The battery must be replaced within 2 weeks. Battery operated systems utilise 6 x 1.5V AA batteries.
  • Page 12 changing and cleaning the solenoid and filter Changing the Solenoid 1. Firstly shut off the water supply. 2. Disconnect the solenoid cable from the sensor. 3. Disconnect the flexi-hose and the solenoid adaptor (H) from the solenoid. Make sure you remove the filter (G) from the faulty solenoid.
  • Page 13 TO SENSOR 13 + L-180 Walll Mounted Sensor Tap...
  • Page 14 Changing the Solenoid Valve First shut off the water supply. Unplug the solenoid from the mains power supply. Use spanner to remove the solenoid valve Take the new solenoid valve and re- assemble. Restore the incoming water supply. Check that there is no water leakage.
  • Page 15: Settings Adjustment - Remote

    settings adjustment - remote control Detection Range Delay In Time Delay Out Time RANGE Security Time Reset 24 Hour Hygiene Flush Lock Out Time The remote control can be purchased separately if required to adjust a wider range of set- tings.
  • Page 16 Detection Range Delay Out Time The detection range can be adjusted with- This button allows modifying the water flow out a remote control, see page 12. Only if time after the user removes his hands from necessary, use the remote control to adjust the tap.
  • Page 17: General Cleaning

    general cleaning Cleaning Care and cleaning of chrome and special finishes. DO NOT use steel wool or cleansing agents containing alcohol, acid, abrasives or the like. Use of any prohibited cleaning or maintenance products or substances could damage the surface of the tap. For surface cleaning of the tap use ONLY soap and water, then wipe dry with a clean cloth or towel.
  • Page 18: Troubleshooting

    troubleshooting SY MP TO M IS SU E No water coming out of the tap , sensor Low Battery. flashes continuously when use r’s hands are within the sensor ’s range. Range is too short . Range is too long . Battery is completely used up.
  • Page 19 We are always looking to improve. If these did not solve your problem please c ontact us and we will endeavour to help. Tel: +44 (0)161 482 7000 Email: technical@lovair.com SOLUTION Replace batteries (see page 1 4). Increase the sensor range (see page 12). Decrease the sensor range (see page 12).
  • Page 20: Warranty

    L+180 Wall Mounted Sensor Tap 1 year limited warranty If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replace- ment part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty.
  • Page 21: Warranty Info

    warranty information 1.1 The Supplier warrants that on deliver y, and for limitation the inst allation guide for the Goods a period of 24 months fr om the date of delivery provided by the Supplie r, or (if the re are none) good (Warranty Period), the Goods sha ll: trade prac tice regarding the sam e;...
  • Page 22: Spare Parts

    spare parts L7500002 Solenoid Valve L07221009 Solenoid valve complete with housing L07220144 Sensor kit for L 180 series sensor taps pr e-set L09510053 L06530021 Transformer for sensor taps - IP67 – Fema le Transformer for sensor taps - IP68 – Fema le L230285 Battery Box for sensor taps - IP67 - Fem ale - L06530020...
  • Page 23 L09510073 L0710005 Remote Control for sensor ta p L08510012 Aerator - 1.89 lit res per minute ( 0.5 GPM(US )) Aerator - 6 litres per minute (1.59 GPM (US) ) L08510034 Aerator - 4 litres per minute (1.0 GPM (US) ) L08510037 23 + L-180 Walll Mounted Sensor Tap...
  • Page 24: Contact

    contact General information info.uk@thesplashlab.com +44 (0)161 482 7000 Unit 34, Meadow Industrial Estate, Water Street Stockport SK1 2BU United Kingdom Technical support info.uk@thesplashlab.com For further information visit: www.thesplashlab.com/uk 24 + L-180 Wall Mounted Sensor Tap...
