Summary of Contents for The Splash Lab TSL.C051
- Page 1 TSL.C051 channel sensor tap +"' +THE +"' SPLASH +"'...
- Page 2 Safety and Warnings Box Contents Technical Data Before You Install How to Install The Complete System Resetting the Sensor Maintenance & Cleaning Spare Parts Product Identification Troubleshooting Warranty Back Cover Contact Details 2 + TSL.C051 CHANNEL SENSOR TAP MANUAL...
- Page 3 TSL.C051 channel sensor Read and save these instructions & WARNING To reduce the risk of fire, electric shock or injury to persons, observe the following: Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
-
Page 4: Box Contents
Channel sensor tap head Mains power supply Solenoid valve Gasket Washer Fixing nut Flow restrictor Flex hose - 300mm 4 + TSL.C051 CHANNEL SENSOR TAP MANUAL... -
Page 5: Technical Data
technical data Finishes TSL. C 051.C Bright Polished TSL. C 051.CS Brushed Stainless TSL. C 051.CP Brushed Copper TSL. C 051.BK Brushed Black TSL. C 051.BR Brushed Brass TSL. C 051.BZ Brushed Bronze Material (body) 316 Stainless steel Operating pressure 7 - 87 psi dynamic pressure Flow rate 1.9 litres/minute... -
Page 6: Before You Install
50mmMAX 10mm MIN 236.5mm 050mm "'-, 028.6mm Sensor/ Range 12O±2Omm " 550mm 550mm installation depth 60mm MIN 6 + TSL.C051 CHANNEL SENSOR TAP MANUAL... - Page 7 Flow Rates Different flow rates may need to be achieved. The Splash Lab offers a number of flow regulators which can be used in conjunction with the Channel Tap. Contact The Splash Lab for more information. Water Temperature The Channel Tap does not come equipped with temperature control.
- Page 8 Basins The Splash Lab Monolith basin is recommended for use with the Channel range of products. If an alternative basin is used, please confirm with The Splash Lab that there will be no reflection or splash issue. Backplate The Splash Lab offers an optional backplate for the fixtures that means the fixtures can be mounted from the front and have simpler access.
-
Page 9: How To Install
how to install Drill hole 30mm diameter in wall Fit tap body into the 30mm hole in wall. 200-250mm above the bottom of the basin. TSL. C 051 CHANNEL SENSOR TAP MANUAL+ 9... - Page 10 Fasten the water inlet tube to the bottom connector of the solenoid valve. 10 + TSL.C051 CHANNEL SENSOR TAP MANUAL...
- Page 11 how to install solenoid cable power cable (Brown + Orange ire) ck + Red wire) Fasten the other end of the water inlet Connect the solenoid cable A to solenoid tube to the tri-valve on the wall. cable B. Connect the power cable C to power cable D.
- Page 12 Channel sensor tap head Mains power supply Solenoid and cable Flow restrictor 12 + TSL.C051 CHANNEL SENSOR TAP MANUAL...
- Page 13 resetting the sensor solenoid cable power cable (Brown + Orange wire) (Black+ Red wire) � First disconnect the Channel tap After connecting to power, immediately head from the Power unit. Wait a place your hand at about 50mm below the minimum of 4 seconds and reconnect sensor on the tap head and keep it there the power.
- Page 14 (min. 50mm seconds to complete setting up the max. 150mm) and keep your hands at desired sensor range. the desired position for 3 seconds. *Remove reflective clothing during installation. 14 + TSL.C051 CHANNEL SENSOR TAP MANUAL...
-
Page 15: Maintenance And Cleaning
maintenance & cleaning *Isolate the unit from the power supply before any servicing or maintenance work is carried out. How to clean the spout of tap and how regularly Please use a clean cloth to wipe away the dusts and/or water mark on the spout or use a damp cloth to clean it. -
Page 16: Spare Parts
Should a replacement mains power supply be required it is imperative that an identical type is used. Contact The Splash Lab for further information. product identification A unique product identification code can be found on the product tag attached to the water hose. -
Page 17: Troubleshooting
troubleshooting Corrective Actions for Initial Installation Failures Water does not flow/ Cannot hear valve open There is no power to valve or sensor Check that cables are connected Check that transformer is operating and supplying 6 volts Sensor range is incorrect Adjust sensor setting (see pages 12 and 13) Water does not flow / Valve can be heard to open Water supply is blocked to valve... - Page 18 Clean the solenoid valve filter. We are always looking to improve. If these did not solve your problem please contact us and we will endeavour to help. Tel: + 44 (0) 161 482 7000 Email: lnfo.uk@thesplashlab.com 18 + TSL.C051 CHANNEL SENSOR TAP MANUAL...
-
Page 19: Warranty
One year limited warranty + If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning will void the warranty. - Page 20 contact General information lnfo.uk@thesplashlab.com +44 (0) 161 482 7000 Technical support I nfo.uk@thesplashlab.com 1i2' For further contact information visit: ::::, www.thesplashlab.com LJ.J...
