Instruction manual
Dishwasher
DWFSE126W /
DWFSE126B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWFSE126W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bush DWFSE126W

Summary of Contents for Bush DWFSE126W

  • Page 1 Instruction manual Dishwasher DWFSE126W / DWFSE126B...
  • Page 2 We’re here to help you get the most from your Dishwasher. Should you require any guidance, a simple solution can often be found online at: www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

  • Page 3: Table Of Contents

    Programme Table Using your Dishwasher First use of dishwasher Water softener setting Salt and detergent use Rinse-aid usage Loading your dishwasher or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

  • Page 5: Safety Information

    Safety information Icon Type Meaning WARNING Serious injury or death risk RISK OF ELECTRIC SHOCK Dangerous voltage risk FIRE Fire risk CAUTION Injury or property damage risk IMPORTANT / NOTE Operating the system correctly...
  • Page 6 Safety information Important - Please read these instructions fully before installing or operating. Keep this manual for future reference. 1.1 General Safety Warnings Check that the indoor electrical fuse system is connected in line with safety regulations. Please check the packaging of your All electrical connections must match the machine before installation and the outer surface of values on the plate.
  • Page 7 You must make sure that the electric cable is positioned safely. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Safety information...

  • Page 9: Getting To Know Your Dishwasher

    Getting to know your Dishwasher...

  • Page 10: Ready? Let's Begin

    Getting to know your Dishwasher You’ll be up and running in no time Ready? Let’s begin... Please read these instructions carefully. They contain important information which will help you get the best from your dishwasher and ensure safe and correct installation and operation.

  • Page 11: Product Overview

    If you still require further assistance, call one of our experts on 0345 257 7271. Getting to know your Dishwasher...

  • Page 12: Technical Specifications

    Getting to know your Dishwasher You’ll be up and running in no time Technical Specifications Capacity place settings Dimensions 845mm Height 598mm Width 600mm Depth Net weight 41,2 kg Operating 220-240V~ 50 Hz voltage / frequency Total power 1760-2100W Water supply Maximum:1.00MPa pressure Minimum:0.04 MPa...

  • Page 13: Product Dimensions

    598mm Depth (D1) 600mm (with the door closed) Depth (D2) 1175mm (with the door opened 90°) or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Getting to know your Dishwasher...

  • Page 15: Installing Your Dishwasher

    Installing your Dishwasher...
  • Page 16 Installing your Dishwasher Bringing it all together 3.3 Water inlet hose 3.1 Positioning your Machine When installing the machine, the mains plug of the power cord and the water tap must be freely accessible. When positioning the machine, place it in an area where dishes can be easily loaded and unloaded.
  • Page 17 The waste connection must be at a height less than 1000 mm(maximum) from the bottom of the dishwasher. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Installing your Dishwasher...

  • Page 18: 3.7 Fitting The Machine Undercounter

    Installing your Dishwasher Bringing it all together 3.7 Fitting The Machine Undercounter 2. If dishwasher is installed at the corner of the cabinet, there should be some space when the door is opened. In most modern fitted kitchens there is only one single work top under which cabinets and electrical appliances are fitted.

  • Page 19: Functions

    Functions...

  • Page 20: Control Panel

    Functions Simple everyday use 4.1 The Control Panel Operation (Button) Press this button to turn on your dishwasher, the screen Rinse Aid Power lights up. When pressing this button, corresponding If the “ ” indicator is lit, it means the dishwasher is indicator will be lit.
  • Page 21 3. You can change the program to the desired cycle setting. 3 sec WARNING It is dangerous to open the door mid-cycle, as hot steam may scald you. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Functions...

  • Page 22: Programme Table

    Functions Simple everyday use Programme Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. Consumption values and program duration are only indicative except for ECO program. ) indicates that the program uses rinse aid in the last rinse.

  • Page 23: Using Your Dishwasher

    Using your Dishwasher...
  • Page 24 Using your Dishwasher Using your Dishwasher Getting the most fr tting the most from y om your applianc our appliance e 5.3. Fill the salt 5.1. Preparing your dishwasher for first use Please follow the steps below for adding dishwasher salt: •...
  • Page 25 To find out the hardness level of your tap water, contact your water company or use a test strip (if available). or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Using your Dishwasher...
  • Page 26 Using your Dishwasher Using your Dishwasher Getting the most from your appliance Getting the most from your appliance Adjusting salt consumption 5.9. Filling the detergent 5.7. The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of the water used.

  • Page 27: 5.11. Rinse-Aid Usage

    The Low Rinse Aid indicator ( ) will be lit when more rinse aid is needed. Do not overfill the rinse aid dispenser. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Using your Dishwasher...

  • Page 28: Loading Your Dishwasher

    Using your Dishwasher Getting the most from your appliance Loading your dishwasher Upper Basket Height adjustment For best results, follow these loading guidelines. The height of the upper basket can be easily adjusted to Loading the household dishwasher up to the accommodate taller dishes in either the upper or lower basket.
  • Page 29 Position of the upper basket: lower position Program: ECO Gravy ladle Rinse aid setting: Max Softener setting: H3 or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Using your Dishwasher...

  • Page 31: Care And Maintenance

    Care and maintenance...

  • Page 32: Cleaning

    Care and maintenance Looking after your appliance 6.2. Spray arms Cleaning Make sure that the spray holes are not clogged and that no Cleaning your dishwasher is important to maintain food waste or foreign object is stuck to the spray arms. If the machine’s service life.

  • Page 33: Product Support

    Product support...

  • Page 34: Troubleshooting

    Product support Help is always at hand Troubleshooting Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. start circuit break tripped.
  • Page 35 The dishes were not are not clean loaded correctly. Dishes”. The program was not Select a more intensive program. powerful enough. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
  • Page 36 Product support Help is always at hand Troubleshooting Problem Possible Causes What To Do The dishes Not enough detergent Use more detergent, or change your are not clean. was dispensed. detergent. Items are blocking the Rearrange the items so that the spray movement of the spray can rotate freely.
  • Page 37 Self-repair or non-professional repair may cause serious risks to the safety of the user of the appliance and impact warranty. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
  • Page 38 Product support Help is always at hand AUTOMATIC FAULT WARNINGS AND WHAT TO DO If there is a malfunction the dishwasher will display an error code. The following table shows possible error codes and their causes. Codes Meanings Possible Causes Faucets is not opened, or water intake is Longer inlet time.

  • Page 39: Product Information Sheet

    The model information can be retrieved using the QR-code reported in the energy label. The label also includes the model identifier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support...

  • Page 40: Help And Assistance

    Lines open 8am-7pm Monday to Saturday and 10am-4pm Sunday. *Calls to Bush enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tariff. Mobile and other providers costs may vary, see www.bt.com/pricing for details.

  • Page 41: Declaration Of Conformance To Product Standards

    • Contact a relevant recycling centre to obtain information about disposal of different materials. or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
  • Page 42 Help is always at hand Call us now and activate your 12 month guarantee Thank you for choosing Bush. Your new product is guaranteed against faults and breakdowns for 12 months. Don’t forget to register it with us today so we can provide you with our best possible after-sales service and useful updates.
  • Page 43 If you still require further assistance, call one of our experts on 0345 257 7271. Product support...
  • Page 44 Produced in China. Argos Limited, London, EC1N 2HT, UK. Argos (N.I.) Ltd., Forestside Shopping Centre, Upper Galwally, Belfast, BT8 6FX, UK. www.argos.co.uk/bush Contact: www.bush-support.com Helpline: 0345 257 7271...
